  1. Column Buckling Analysis By: Anthony Beeman

  2. Euler’s Fundamental Buckling Problem x P • Assumptions: • Straight Column • Homogeneous Material • Boundary Conditions: • Pinned-Pinned • Governing Equations: y N M L v v A n=mode L= Original Column Length E= Young’s Modulus I= Moment of Inertia P P

  3. Other End Conditions x P P y Modified Euler Buckling Formula: L L= Original Column Length Le= Effective Column Length E= Young’s Modulus I= Moment of Inertia Le=L Le=2L P P

  4. Problem Analyzed P Mechanical Properties r=0.5 M A A Cross Section A-A L=10 M Calculated Critical Load [N]

  5. Comsol Results Case 1 2,904 DOF Case 2 12,723 DOF Case 3 73,623 DOF

  6. Abaqus Results Case 1 285 DOF Case 2 490 DOF Case 3 48,145 DOF

  7. Abaqus Results: First 6 Modes

  8. ANSYS Results Case 1 2,904 DOF Case 2 12,723 DOF Case 3 73,623 DOF
