Presentation Transcript

  1. Igneous Rocks Matt Cortright, Claire Hilton, Margot Sweeney, Caylee Waters, Tommy Watters

  2. Igneous rocks • What is the definition of an igneous rock? • One that has crystallized from a molten material (magma). • What are some examples of igneous rocks? • Granite can be used for architectural construction, ornamental stone, flooring, • paving, facing stones, worktops, gravestones and monuments. Pumice which can be • used as an abrasive material in hand soaps, soaps, cleansers, and dental products, • emery board, etc. Basalt is a commonly used in floor tiles and in construction • projects. The crushed form of this rock is used for concrete aggregate, asphalt • sidewalk aggregate, railroad ballast, and filter stone in drain fields.

  3. Igneous rocks • How common is an igneous rock? • The most common igneous rock Basalt makes up most of the oceanic plates • and is founds at divergent plate boundaries. Felsic igneous rocks are most commonly • found along continental margins. • Where can they be found? • An intrusive rock is one that has formed below the surface, and extrusive rock is • one that crystallized on Earth’s surface.

  4. Formation • Where do they form? • Extrusive – made when magma flows on the earth's surface. • Intrusive - produced when magma solidifies deep beneath the earth. • How do they form? • Extrusive rocks cool faster than intrusive. Some rocks are shot into the air and cool pretty fast, others into waterways (also fast cooling). • Some rocks however are underneath the crust so they cool more slowly. • What can affect their formation? • Typically, the melting is caused by one or more of three processes that can all affect their formation: an increase in temperature, a decrease in pressure, or a change in composition.

  5. Features • Igneous features? • Batholiths- The largest rock formations in the crust of the Earth. They consist of granitic forms that cover tens of thousands of square kilometers and extend forward for up to 60km. • Sills-Structure produced by the flow of basaltic magma associated with a volcano. • Types of magma? • Felsic- An igneous rock that is high in feldspar and silica. (e.g. Rhyolite and granite) • Mafic- Magma or lava that is rich in iron and magnesium. (e.g. Basalt and Gabbro)

  6. Plutons & Volcanic landorms http://www.indiana.edu/~geol105/images/gaia_chapter_5/dike&sill.jpg

  7. features • What can they be changed into or from? How? • Magma can be changed to igneous rocks by cooling under or above ground. Igneous rocks can also be changed into metamorphic rock through heat and pressure. When an igneous rock is weathered and eroded, it turns into sediments. Those sediments can be compacted to make sedimentary rock. Igneous rocks can melt and cool to form new igneous rocks. • Are there different types of igneous rocks? • Igneous rock can be both intrusive and extrusive. Intrusive igneous rocks form within Earth's crust. Extrusive igneous rocks form when the magma or molten rock pours out onto the Earth's surface or erupts at Earth's surface from a volcano. If the rock cools underground, it will take a longer time to cool due to the warmer temperatures, whereas if it cools above ground, it will take less time to cool due to lower temperatures. The slower the rocks cool, the bigger they will be.

  8. Rock Cycle http://www.cotf.edu/ete/images/modules/msese/earthsysflr/EFCycleP2.gif

  9. characteristics • How are they classified? • They are classified by texture, mineralogy, and chemistry. Whether they are extrusive and Intrusive rocks or if they are fine grained/glassy or large grained. • What can they be used for? • Igneous rocks can be used for flooring, landscaping, and construction • Projects. The most commonly used igneous rock is granite.

  10. characteristics • What are characteristics of igneous rocks? • Characteristics of igneous rocks include crystal shape and granularity. Grains range from about 1mm to 2cm in size. The igneous rocks that formed inside the earth have larger crystals because the cooling time is longer. • What is the composition of igneous rocks? • Igneous rocks are mostly silicate minerals. But on rare occasions they can contain carbon.

  11. Compared to other rocks • Crystal size and cooling rate? • Crystal size is effected by the cooling rate, slower the cooling rate, the greater the size of the crystal • When the magma cools rapidly it forms fine-grained rocks, these are called aphanite igneous rocks

  12. Works cited Igneous Rocks 101. http://www.archaeology.ncdcr.gov/ncarch/GeoArcheo/ IgneousA.htm. N.d. Web. January 6 2010. ”IGNEOUS ROCKS." Geological Sciences. Web. 15 Mar. 2012. <http://geology.csupomona.edu/drjessey/class/gsc101/igneous.html>. Kusky, Timothy. "igneous rocks." Science Online. Facts On File, Inc. Web. 12 Mar.2012.<http://www.fofweb.com/activelink2.asp?ItemID=WE40&SID=5&iPin=EESS0128&SingleRecord=True>. “Types of Igneous Rocks”. RajibSingha. Buzzle. http://www.buzzle.com/articles/igneous-rock-uses.html. Web. January 6 2010. "Igneous Rocks." Geology.com: News and Information for Geology & Earth Science. Web. 15 Mar. 2012. <http://geology.com/rocks/igneous-rocks.shtml>. "igneous rock." Encyclopedia Britannica. Encyclopedia Britannica Online Academic Edition Encyclopedia Britannica Inc., 2012. Web. 14 Mar. 2012. <http://www.britannica.com/EBchecked/topic/282318/igneous-rock>. Gates, Alexander E. "Igneous Rocks." Science Online. Facts on File inc, n.d. Web. 15 Mar. 2012. <http://www.fofweb.com/Science/default.asp>. Spaulding, Nancy, E, and Samuel Namowitz, L. "Igneous Rocks." Earth Science.

  13. Works cited "igneous rock." Encyclopedia Britannica. Encyclopedia Britannica Online Academic Edition Encyclopedia Britannica Inc., 2012. Web. 14 Mar. 2012. <http:// www.britannica.com/EBchecked/topic/282318/igneous-rock>. Gates, Alexander E. "Igneous Rocks." Science Online. Facts on File inc, n.d. Web. 15 Mar. 2012. <http://www.fofweb.com/Science/default.asp>. Wyman, Bruce, and L. Harold Stevenson. "batholiths." Science Online. Facts On File, Inc. Web. 12 Mar. 2012. <http://www.fofweb.com/activelink2.asp?ItemID=WE40&SID=5&iPin=DEST0 473&SingleRecord=True>. Gates, Alexander E., and David Ritchie. "felsic." Science Online. Facts On File, Inc. Web. 12 Mar. 2012. <http://www.fofweb.com/activelink2.asp?ItemID=WE40&SID=5&iPin=EEV03 50&SingleRecord=True>. Gates, Alexander E., and David Ritchie. "mafic." Science Online. Facts On File, Inc. Web. 12 Mar. 2012. <http://www.fofweb.com/activelink2.asp?ItemID=WE40&SID=5&iPin=EEV0599&SingleRecord=True>. Evanstom: McDougal Littell, 2005. 121-126. Print.
