Redesign and Analysis of Mechanical Options at Research & Development Complex “X”

This report outlines the mechanical options and redesign analyses for the Research & Development Complex "X", located in the Baltimore/DC area. The facility, which includes five buildings covering 1.5 million square feet, is focused on innovative office and laboratory spaces. The analysis covers mechanical systems such as VAV setups, underfloor air distribution, and a central utility plant featuring combined heat and power systems. The potential impacts on costs, lifecycle, indoor air quality, and environmental factors are discussed, along with strategies for optimizing energy efficiency and operational schedules.

melita
Télécharger la présentation

Redesign and Analysis of Mechanical Options at Research & Development Complex “X”

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Outline Research & Development Complex “X” Background Redesign Analysis Office Airside Jim Gawthrop - Mechanical Option CUP Analysis CHP Analysis Power Distribution Background Construction Impact Conclusion Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  2. Facility Information Background Research & Development Complex “X” Jim Gawthrop - Mechanical Option Location: Baltimore/DC Area Complex Size: 5 Buildings (3-5 Stories) 1.5 million SF Total Cost: $477 million Occupancy type: Office and Laboratory Delivery Method: Design-Build Joint venture Construction Period: 6/2008 – 8/2010

  3. Facility Mechanical Information Background Research & Development Complex “X” Jim Gawthrop - Mechanical Option Office Space: VAV Lab Space: VAV + CRAC Units CRAC Units coupled with UFAD Plants: Four distributed Plants C & D Share a plant AHUs: Provide 15% OA

  4. Facility Chilled Water Background Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  5. Facility Hot Water Background Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  6. Redesign Analysis Background Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  7. Redesign Analyses Redesign Analysis Research & Development Complex “X” Jim Gawthrop - Mechanical Option Reduce the Loads on the Plant Centralize the Plant Investigate Combined Heat & Power

  8. Redesign Analyses Redesign Analysis Research & Development Complex “X” Jim Gawthrop - Mechanical Option Initial Cost Lifecycle Cost Indoor Air Quality Environmental Impact Schedule Impact Operation and Maintenance

  9. Redesign Analysis Office Airside Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  10. Plant Load Reduction Office Airside Research & Development Complex “X” Jim Gawthrop - Mechanical Option Proposed: Underfloor Air Distribution (UFAD) Hydronic Radiant Ceiling Panels (RCP) Active Chilled Beams (ACB)

  11. UFAD Office Airside Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  12. Initial Cost Office Airside Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  13. Lifecycle Cost Office Airside Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  14. Office Airside Central Utility Plant Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  15. Central Plant: Location Central Utility Plant Research & Development Complex “X” Jim Gawthrop - Mechanical Option Near Warehouses Noise not a problem Not interrupting view Easy access from two sides Space for a Chilled Water Storage system

  16. Central Plant: Schematic Central Utility Plant Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  17. Central Plant: TES Central Utility Plant Research & Development Complex “X” Jim Gawthrop - Mechanical Option 900,000 gal Tank Diameter: 65ft Height: 35 ft

  18. Central Utility Plant Combined Heat & Power Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  19. CHP: Payback Combined Heat & Power Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  20. CHP: Chilled Water Schematic Combined Heat & Power Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  21. Plant Strategies: Initial Cost Plant Strategies Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  22. Plant Strategies: Lifecycle Cost Plant Strategies Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  23. Plant Strategies Power Distribution Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  24. Power Distribution Power Distribution Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  25. Power Distribution Power Distribution Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  26. Power Distribution: As Designed Power Distribution Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  27. Power Distribution: CUP Power Distribution Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  28. Power Distribution: CHP Power Distribution Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  29. Power Distribution Schedule Impact Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  30. Schedule Impact Schedule Impact Research & Development Complex “X” Jim Gawthrop - Mechanical Option Positive Impact: All Large Equipment in one Location Less time spent on mechanical Equipment in the other buildings. Negative Impact: More Complicated Systems Less common systems Larger Equipment Extra Buildings to be Constructed More Piping to be laid out

  31. Schedule Impact: Airside Systems Schedule Impact Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  32. Schedule Impact: Plants A B Schedule Impact D E Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  33. Schedule Impact Conclusion Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  34. Conclusion: Airside Conclusion Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  35. Conclusion: Plant Strategies Conclusion Research & Development Complex “X” Jim Gawthrop - Mechanical Option

  36. Conclusion: Plant Strategies Conclusion Research & Development Complex “X” Jim Gawthrop - Mechanical Option • Chilled Beams will be best option if first cost decreases • UFAD is best selection considering delivery method • CHP has best payback and Environmental effect, but is very complicated • CUP with TES is the best solution, all factors considered

  37. Acknowledgements Research & Development Complex “X” Jim Gawthrop - Mechanical Option Special Thanks to: all of the AE Faculty [Especially the Mechanical Faculty] Friends and Family for Their Support Joseph DiIenno, PE at SOM for answering A LOT of random questions

  38. Questions Research & Development Complex “X” Jim Gawthrop - Mechanical Option ?

  39. M.A.E. Coursework Research & Development Complex “X” Jim Gawthrop - Mechanical Option AE 557 – Central Cooling AE 558 – Central Heating AE 551 – Combined Heat and Power AE 552 – Indoor Air Quality AE 596 – CFD Independent Study
