  1. O’Shea Computer Network Wireless (OSHEA) Channel 1 – Mixed (OSHEA2) Channel 2 – Mixed 192.168.1.2 SAPPHIRE Wireless (OSheaFios) Channel 6 192.168.1.1 173.66.54.143 VerizonFios 35MB/35MB Windows 7 - SAPPHIRE Workgroup - OSHEA Connection - HAWK IP: 192.168.1.XX EMERALD USB Verizon Modem HAWKExtender 192.168.1.3 Windows 7 Prof - EMERALD Workgroup - OSHEA Connection HAWK IP: 192.168.1.XX USB ROGUE OPAL EBONY Iomega Network Drive 2 TB 192.168.1.4 Sony DXP-550 Photo Windows 7 Home OPAL Workgroup - OSHEA Connection - HAWK IP: 192.168.1.XX Windows 7 Prof 64- ROGUE Workgroup - OSHEA Connection - Ethernet IP: 192.168.1.XX Windows 7 Prof - Ebony Workgroup - OSHEA Connection - HAWK IP: 192.168.1.XX Konica-Minolta 2300DL Samsung 4326WX

  2. O’Shea Computer Network – Verizon Modem Verizon IP: 173.66.54.143 www.potgold.com Gateway IP: 192.168.1.1 MAC: Wireless G - Channel 6 – OSheaFios Ethernet 10/100 Mbps Coax: Connected to Verizon FIOS Box WAN: Not used Etherport 1: Etherport 2: Cisco 3000 N Router Etherport 3 Etherport 4: IPv4 MI424WR

  3. O’Shea Computer Network – N-Router Cisco Linksys E3000

  4. O’Shea Computer Network - Rogue ROGUE

  5. O’Shea Computer Network - Emerald

  6. O’Shea Computer Network - EBONY

  7. O’Shea Computer Network – Sapphire

  8. O’Shea Computer Network - OPAL
