Signals. Signals can be analog or digital. Analog signals can have an infinite number of values in a range; digital signals can have only a limited number of values . In data communication, we commonly use periodic analog signals and aperiodic digital signals.

Signals - slide 1
01 / 15Signals
1 / 17

Télécharger la présentation

Signals
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Signals

  2. Signals can be analog or digital. Analog signals can have an infinite number of values in a range; digital signals can have only a limited number of values. In data communication, we commonly use periodic analog signals and aperiodic digital signals.

  3. Frequency and period are inverses of each other. If a signal does not change at all, its frequency is zero. If a signal changes instantaneously, its frequency is infinite. Phase describes the position of the waveform relative to time zero. Frequency is the rate of change with respect to time. Change in a short span of time means high frequency. Change over a long span of time means low frequency.

  4. An analog signal is best represented in the frequency domain.

  5. A single-frequency sine wave is not useful in data communications; we need to change one or more of its characteristics to make it useful.

  6. According to Fourier analysis, any composite signal can be represented as a combination of simple sine waves with different frequencies, phases, and amplitudes.

  7. The bandwidth is a property of a medium: It is the difference between the highest and the lowest frequencies that the medium can satisfactorily pass.

  8. Example If a periodic signal is decomposed into five sine waves with frequencies of 100, 300, 500, 700, and 900 Hz, what is the bandwidth? Draw the spectrum, assuming all components have a maximum amplitude of 10 V.

  9. B = fh-fl = 900 - 100 = 800 Hz The spectrum has only five spikes, at 100, 300, 500, 700, and 900

  10. A digital signal is a composite signal with an infinite bandwidth.

  11. Transmission of digital signals • Transmission of digital signals • Baseband transmission • Broadband transmission using modulation

  12. Transmission impairment • Attenuation • Distortion • Noise

  13. Performance • Data rate limits • Shannon capacity BitRate ≤ bandwidth x log2(1+SNR) • Throughput = transmitted bits per unit time • Latency = propagation time + transmission time + queueing time + processing delay • propagation time = distance / propagation speed • transmission time = message size / bandwidth’

  14. Bandwidth-Delay Product • B-D product defines the number of bits that can fill the link (or the network)
