  1. Chapter 2 Mathematical Preliminaries

  2. Contents • Relations • Functions • Partial orders • Induction • (Formal) Language • Trees

  3. Cartesian products • A, B: two sets • AxB (Cartesian Product of A and B) is the set of all ordered pairs {<a,b> | a Î A and b Î B }. • Examples: A= {1,2,3}, B= {4,5,6} => AxB = ? • A1,A2,...,An (n > 0): n sets • A1xA2x...xAn = {<a1,a2,...,an> | aiÎ Ai }. • Example: 1. A1={1,2},A2={a,b},A3={x,y} ==> |A1xA2xA3| = ? 2. A1= {}, A2={a,b} => A1xA2 = ?

  4. Binary Relation • Binary relation: • A,B: two sets • A binary relation R between A and B is any subset of AxB. • Example: If A={1,2,3}, B ={4,5,6}, then which of the following is a binary relation between A and B ? R1 = {<1,4>, <1,5>, <2,6> } R2 = {} R3 = {1,2,3,4} R4 = {<1,2>, <3,4>, <5,6> }

  5. Basic terminology about relation • R: a binary relation between A and B (I.e., a subset of AxB), then • The domain of R: dom(R) = {x Î A |  y Î B s.t. <x,y> Î R} • The range of R: range(R) ={y Î B, |  x Î A, s.t., <x,y> Î R} • <x,y> Î R is usually written as x R y. • If A = B, then R is simply called a relation over(on) A. • An n-tuple relation R among A1,A2,...,An is any subset of A1xA2...xAn, n is called the arity of R • If A1=A2=...=An=A => R is called an n-tuple relation (on A).

  6. Examples about relations • A = the set of All human beings = {...,蔣中正, 蔣經國, 蔣緯國, ...} • the-father-of (父子關係) = {<x,y> | x,y are human and x is the father of y } is a binary relation over humans. • the-brother-of (兄弟關係) = {<x,y> | x and y are human and x is the brother of y } So, <蔣中正,蔣經國>,<蔣中正,蔣經國>Î the-father-of and<蔣經國, 蔣緯國>,<蔣緯國, 蔣經國>Î the-brother-of

  7. (Partial) Functions • A relation R between A and B is functional iff, for all x Î A and y,z Î B, x R y and x R z implies y = z. (I.e., for each x in A, there is at most one y in B, s.t., x R y.) • A partial function is a triple f=<A,B,G> where A and B are sets and G is a functional relation between A and B. • A is called the domain of f • B is called the codomain of f and • G is called the graph of f. Notation:1. f : A  B; 2. A= dom(f); B=Codom(f); G=graph(f) • Note: Dom(f) ¹ Dom(G) in general. • For every element x ∈ A, the unique y in the range of f with (x,y)  G is denoted f(x).

  8. (partial) functions • If Dom(f) = Dom(G), (I.e., for all x in A, there is y in B, s.t., x G y), then • call f a (total) function • f and its graph G are usually identified. range(G) or imgae(G) A=Dom(f) G B=Codom(f) Dom(G) f is a total function iff Dom(f) = Dom(G) Note: In the following, if not stated otherwise, all functions are assumed to be total function.

  9. Classification of (total) functions • f:AB a (partial) function; X a subset of A, Y a subset of B; then • f(X) : the image of X under f = {y Î B | there is x in X s.t., f(x) = y } • f-1(Y):the inverse image of Y under f = {x Î A | there is y  Y s.t., f(x) = y } • f is surjective(onto) iff f(A) = B • f is injective(1-1) iff for each y in B, there is at most one x in A, s.t., f(x) =y. • f is bijective (or a bijection) iff f is 1-1 and onto. • If f is 1-1 and onto then there exists a unique function g:B A s.t., g(y)=x iff f(x) = y. • g is called the inverse of f and is denoted f-1.

  10. g2 1 2 3 4 5 6 1 2 3 4 5 6 g4 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 Example: g1 g3 • A= {1,2,3}  B= {4,5,6} • Let fi = <A,B,gi>. then • dom(gi) = ?; range(gi) = ? • which are total functions? • which are 1-1 functions? • which are surjective, bijective? g5

  11. Operations on relations (and functions) • R Í AxB; S Í B x C: two relations • composition of R and S: • R · S = {<a,c> | there is b  B s.t., <a,b>  R and <b,c>  S }. • Identity relation: IA = {<a,a> | a  A } • Converse relation: R-1 = {<b,a> | <a,b>  R } • f:A  B; g: BC: two functions, then g·f:AC defined by g·f(x) = g(f(x)). • Note: function and relation compositions are associative, I.e., for any function or relation f,g,h, f· (g·h) = (f·g) ·h

  12. Properties of binary relations • R: A binary relation on S, 1. R is reflexive iff for all x in S, x R x. 2. R is irreflexive iff for all x in S, not x R x. 3. R is symmetric iff for all x, y in S, xRy ⇒ yRx. 4. R is asymmetric iff for all x,y in S, xRy ⇒ yRx. 5. R is antisymmetric iff for all x,y in S, xRy and yRx ⇒ x=y. 6. R is transitive iff for all x,y,z in S, xRy and yRz ⇒ xRz. Graphical realization of a binary relation and its properties. rule: if xRy then draw an arc from x on left S to y on right S. x x y y s s

  13. Examples • The relation £ on the set of natural numbers N. What properties does £ satisfy ? • ref. irref, or neither ? • symmetric, asymmetric or antisymmetric ? • transitive ? • The relation > on the set of natural numbers N. • The divide | relation on integers N ? • x | y iff x divides y. (eg. 2 | 10, but not 3 | 10) What properties do > and | satisfy ? • The BROTHER relation on males (or on all people) • (x,y) BROTHER iff x is y’s brother. • The ANCESTOR relation in a family. • (x,y)  ANCESTOR if x is an ancestor of y. What properties does BROTHER(ANCESTOR) have?

  14. Some special relations • R: a binary relation on S 1. R is a preorder iff it is ref. and trans. 2. R is a partial order (p.o.) iff R is ref.,trans. and antisym. (usually written as £ ). 3. R is a strict partial order (s.p.o) iff it is irref. and transitive. • usually written <. 4. R is a total (or linear) order iff it is a partial order and every two element are comparable (i.e., for all x,y either xRy or yRx.) 5. R is an equivalence relation iff it is ref. sym. and trans. • If R is a preorder (resp. po or spo) then (S,R) is called a preorder set (resp. poset, strict poset). • What order sets do (N, <) , (N, £ ) and (N, |) belong to ?

  15. Relationship between properties of relations • R: a nonempty binary relation on a nonempty set S . 1. If R is ref., then it is not irref. (ref. ⇒ not irref.) 2. irref. and antisym.  asym. 3. If £ is a partial order, then the relation < defined by “x < y iff x£ y and x¹ y” is a strict partial order. 4. If <is a strict partial order, then the relation £ defined by “x £ y iff x < y or x = y” is a partial order. 5. According to 3 and 4, basically there is no difference b/t partial order and strict partial order. Note: In the literature, 1. if £ is given first, then x < y means x£y /\ x ¹ y. 2. If < is given first, then x £ y means x < y \/ x = y. 3. x > y means y < x; x ³ y means y £ x.

  16. Properties of ordered set • (S, £): a poset, X: a subset of S. 1. b  X is the least (or called minimum) element of X iff b £ x for all x  X. 2. b  X is the greatest (or called maximum or largest) element of X iff X £ b for all x  X. • Least element and greatest element, if existing, is unique for any subset X of a poset (S, £ ) pf: let x, y be least elements of X. Then, x£ y and y£ x. So by antisym. of £, x = y. 3. X is a chain iff (X,R) is a linear order(, i.e., for all x, y  X, either x£y or y£x) . 4. b  S is a lower bound (resp., upper bound) of X iff b £ x (resp., x £ b) for all x  X. • Note: b may not belong to X.

  17. Properties of ordered sets • (S, £) : a poset, X: a nonempty subset of S. 5. b in X is minimal in X iff there is no element less than it. • i.e., there is no x ∈ X, s.t., (x < b), • or “for all x, x £ b ⇒ x =b.” 6. b in X is amaximal element of X iff there is no element greater then it. • i.e., there is no x ∈ X, s.t., (b < x), • or “for all x, b £ x ⇒ x=b.” • Note: 1.Every maximum element is maximal, but not the converse in general. 2. Maximal and minimal are not unique in general.

  18. well-founded set and minimum conditions • (S,£) : a poset (偏序集). 1. £ is said to be well-founded (良基性) iff there is no infinite descending sequence. (i.e., there is no infinite sequence x1,x2,x3,.... s.t., x1 > x2 > x3 >... ). • Note: x > y means y < x (i.e., y£ x and y  x) • if £ is well-founded => (S,£) is called a well-founded set. 2. (S,£) is said to satisfy the minimal condition iff every nonempty subset of S has a minimal element. • (S, £ ): a total ordered set (全序集). 3. £ is said to be a well-ordering(良序) iff every nonempty subset of S has a least (or equivalently, minimal) element. • If £ is well ordered, then (S,£) is called a well-ordered set.

  19. Examples of ordered sets • Among the relations (N,£ ), (N,³ ), (N, |), (Z, £), (Z,³), (Z,|) and (R, £), 1. Which are well-founded ? 2. Which are well-ordered ?

  20. Equivalence of well-foundness and minimal condition • (S,£) is well-founded (w.f.) iff it satisfies the minimum conditions (m.c.). pf: scheme: (1) not w.f => not m.c. (2) not m.c. => not w.f. (1) Let x1,x2,... be any infinite sequence s.t. x1 > x2 > x3 >... . Now let X={x1,x2,...}. Then X has no minimal element. Hence, S does not satisfy m.c. (2) Let X be any nonempty subset of S w/o minimal elements. Now (*) chose arbitrarily an element a1 from X,let X1 = {x | x  X and a1 > x } (i.e. the set of elements in X < a1 ) since a1 is not minimal, X1 is nonempty and has no minimal element, too. So we can repeat the procedure (*) infinitely to find a2, X2, a3, X3,... and obtain the infinite descendingsequence a1 > a2 > a3 > ... So S is not w.f. Q.E.D.

  21. Equivalence of w.f. and w.o. • If (S,£) is linear ordered then S is well-founded(or equ., satisfies the m.c.) iff S is well-ordered. pf: (1): w.f. => well-ordered. In total ordered set, every minimum element is a least element. x: minimal in X, let y ¹ x be any element in X => either y < x (impossible!) or x£ y. Hence x is least in X. Existence of minimum elements is implied by m.c. (2) well-ordered => w.f. Trivial. Since every nonempty subset have a least element, which is a minimal element. qed

  22. Variants of Inductions • Mathematical Induction: • To prove a property P(n) holds for all natural number n Î N, it suffices to show that (1)P(0) holds --- (base step) and (2) For all n Î N, p(n) => p(n+1) --- (induction step) • P(n) in (2) is called induction hypothesis (h.p.) • Well-order induction: • (S,£ ) a well-ordered set; P(x): a property about S. • To show that P(x) holds for all x in S, it suffices to show (1) P(x) holds for the least element x of S. --- (base step) (2) for all x in S, (for all y in S y < x => P(y)) => p(x) ---(ind. step) • (1) is a special case of (2) [i.e., (2) implies (1)] • (for all y in S y < x => P(y)) in (2) is called the ind. hyp. of (2).

  23. Variants of inductions • Well-founded induction: • (S, £ ) a well-founded set. P(x) a property about S. • w.f. induction says that to prove that P(x) holds for all x in S, it suffices to show that (1) P(x) holds for all minimal elements x of S --- base step, and (2) for all x in S, (for all y in S y < x => P(y)) => p(x) ---ind. step • (1) is already implied by (2) • (for all y in S y < x => P(y)) in (2) is the ind. hyp. of the proof. • Facts: • w.f. Ind. => well-ordered ind. => math ind. • (I.e., If w.f ind. is true, then so is well-ordered ind. and if well-ordered ind. is true , then so is math. ind.)

  24. relationship between types of inductions • Show that w.f. Ind. => well-ordered ind. If 1. (S,£ ) is any well-ordered set, and 2. for all x in S (for all y in S, y < x => P(x)) => P(x) holds, then for all x Î S, P(x) holds. Pf: Since (S, £) is well-ordered, (S, £) is well-founded. By condition 2, (w.f. ind and w.o. ind. have the same form) for all x in S (for all y in S, y < x => P(x)) => P(x) holds Hence (by w.f. induction) P(x) holds for all x in S. • Show that math ind. is implied by well-order ind. pf: left as an exercise.

  25. Correctness of w.f. induction • (S,£) : a well-founded set. P(x) : a property about S. Then P(x) holds for all x Î S, if (1) P(x) holds for all minimal elements x Î S --- base step, and (2) for all x Î S, (for all y Î S y < x => P(y)) => p(x) ---ind. step pf: Assume NP = { x | x Î S and P(x) is not true } is not empty. ==> Let x be any minimal element of NP. case (1): x is minimal in S. --> impossible! (violating (1) ) by (1), P(x) holds and x Ï NP. case (2): x is not minimal. --> impossible, either! (hence NP has no minimal element and NP is empty, ie. P(x) holds for all x in S) x not minimal ==> L = {y | y Î S /\ y < x} is not empty. ==> L Ç NP = { } (o/w x would not be minimal in NP.) ==> (ind. hyp. holds for x , i.e., for all y Î S, y < x => p(y)is true) ==> (by (2).) p(x) holds ==> x Ï NP. qed

  26. Definition by induction (or recursion) • Consider the following ways of defining a set. 1. the set of even numbers Even = {0,2,4,...}: • Initial rule : 0 Î Even. • closure rule: if x Î Even then x +2 Î Even. 2. The set of strings S+ over an alphabets S = {a,b,c,...,z} • Initial: if x ÎS, then x ÎS+. • closure: If x ÎS and aÎS+, then xaÎS+. 3. The set of lists of numbers. • Initial: [ ] is a (empty) list, • closure: If x is number and L is a list, then [x | L] is a list. • [x | L] is the result of inserting x into the head position of L. • e.g., [ 5 | [2,3,4]] = [5,2,3,4] • Problem:All definitions well-defined? What’s wrong?

  27. Problems about recursive definition • The above definitions are incomplete in the sense that there are multiple sets satisfy each definition • Example: • Let Ni = {0,2,4,6,...} U { 2i+1, 2i+3, ...}. • Then {0,2,4,6,...} and Ni (i > 0) all satisfy Def. 1. • Among {0,2,4,6,...} and Ni (i > 0) , which one is our intended set ? • How to overcome the incompleteness ? • Relationship between {0,2,4,...} and the collection of sets satisfying the definitions? • {0,2,4,...} is the least set among all sets. • {0,2,4,...} is equal to the intersection of all sets. • Every other set contains at least one element which is not grounded.

  28. General form of inductively defining a set (or domain) • W: a set, Init: a subset of W F: a set of functions on W, • we define a subset D of W as follows: 1. Initialization: Every element of Init is an element of D. (or simply Init D) 2. closure: If f:Wn->W in F and t1,...,tn are members of D, then so are f(t1,...,tn) 3. plus one of the following 3 phrases. 3.1 D is the least subset of W with the above two properties. 3.2 D is the intersection of all subsets of W with property 1,2. 3.3 Only elements obtainable by a finite number of applications of rules 1 and 2 are elements of D. • Note: Although phrase 3. is necessary, it is usually replaced by an adv. “inductively” or “recursively” before “define”, and sometimes even totally omitted if it is understood in mind.

  29. Define functions on recursively defined domains • Consider the following function: Na : S+ N with Na(x) =def number of a’s in string x. • Now we can define Na as follows: • Initial: specify the value Na(x) of x for each x in Init = S. • ==> Na(a) = 1 ; Na(x) = 0 if x ¹ a. • recursion: specify the value Na(f(t1,...,tn) of element f(t1,...,tn) for each f ∈ F and t1,...,tn ∈ D = S+. • ==> for any y S+ , Na(ay) = 1 + Na(y) and Na(xy) = Na(y) if x is any symbol ¹ a. • Such kind of definitions are well defined. why ? • sufficient condition: The recursively defined domain is not multi-defined. [I.e., There is exactly one way to form (or derive ) each element in the domain. ]

  30. - x x - 5 2 3 5 2 3 Example of a multi-defined Domain • Arithmetic expression (Ar1 ⊆ S*) : • Init:Constants a,b,c,… and variables x,y,z,… are arithmetic expressions • Closure: If a and b are arithmetic expressions then so are a+b, a-b, -a, a xb and a/b. • ambiguous arithmetic expressions: • 2 – 3 x 5 ; x – y + 2 • two ways to form “ 2 – 3 x 5 “: • 1. 2, 3, 2-3, 5, 2-3 x 5. • 2. 2, 3, 5, 3x5, 2- 3x 5.

  31. Structural induction(SI) • D: an inductively defined domain P(x): a property on D. • To show that P(x) holds for all x in D, it suffices to show • Base step: P(x) holds for all x ∈ Init. • Ind. step: P(t1),...,P(tn) ⇒ P(f(t1,...,tn)) for all f ∈ F, and for all t1,...,tn ∈ D. • Example: show P(x) º “Na(x) ³ 0” holds for all x. • Base step: x Î Init = (S = {a,b,c,...}) • x = a => Na(x) = 1 ³ 0. • x ¹ a => Na(x) = 0 ³0 • Ind. step: x: any element in S, y: any element in S+. Assume (ind. hyp.) Na(y) ³ 0. then • if x = a => Na(x y) = 1 + N(y) ³0 • if x ¹ a => Na(x y) = N(y) ³ 0.

  32. Correctness of structural induction (SI) • Structural induction is a special case of well-founded induction. Why? • Let D be an inductively defined domain. • We can define a (strict) partial ordering < on D as follows: • [All elements of Init are minimal in <.] • ti < f(t1,...,tn) i=1,..,n, for each f in F and for all t1,..,tn ∈ D. • moreover, if s < t and t < u then s < u for all s,t,u ∈ D. • Notes: 1. < may not be a s.p.o. 2. However, if every element of D is not multi-defined, then < must be a s.p.o. Ex of multi-defined set: Even = 0 Î E | x + 2, x - 4 Î E. 3. If < is a spo, then structural ind. is just w.f. ind. on the ordered set (D, <). 4. Even if < is not a spo, SI still holds. (a more complicated ordering then < is needed to show its correctness)

  33. Correctness of recursively defining a function on a recursively defined domain without ambiguous elements. • D: a recursively defined domain s.t. every element has exactly one form. • g:D T defined as follows: • (1) Init: g(i) = ci is given explicitly for each i ∈ Init. • (2) recursion: for each operation f of arity n and for all t1, t1,…,tn ∈ D, g(f(t1,…,tn)) = h(g(t1),…,(tn)) is given in terms of g(t1),..,g(tn). Then there is exactly one function from D to T satisfying conditions (1) and (2). pf: (I) : Existence: Assume the set N = { y ∈ D | y cannot be assigned value by (1) and (2)} is not empty. =>let x be any element minimal N. • (1) x ∉ Init. • (2) let x = f(t1,…,tn) for some f and some t1,…,tn.

  34. (by ind. hyp.,) t1,…,tn can be assigned values g(t1),…,g(tn) • by closure rule x can be assigned value h(g(t1),…,g(tn). • x ∉ N, a contradiction!. (II) : Uniquess: Assume there are two distinct functions g1, g2: D  T satisfying condition (1) and (2). Let N = {y ∈ D | g1(y) ≠ g2(y) } and let x be any minimal element ∈ N. ⇒ (1) x ∉ Init. [since both g1(x) and g2(x) must equal to cx.] • (2) let x = f(t1,…,tn) for some f and some t1,…,tn∉ N • (g1(t1),…,g1(tn)) = (g2(t1),…,g2(tn)) • by closure rule g1(x) = h(g(t1),…,g(tn). = h(g(t1),…,g(tn)=g2(x). • x ∉ N, a contradiction!.

  35. More example: • Define the set of labeled binary trees as follows: • S: a set of labels = {a,b,c,..} • G = S U {(, )}, G* = the set of strings over G. • TS is a subset of G* defined inductively as follows: • Init: () is a tree. • closure: if x is a label, and L and R are trees, then (x L R) is a tree. • Examples: • (), (a ()()), ((a), (b),()), • For each tree T, lf(T) = # of “(“ and lb(T) =# of labels in T; e(T) = number of empty subtrees “()”, can be defined as • Init: l(()) = 1; lb(()) = 0; e(()) = 1. • recursion: lf((x LR)) = 1+ l(L) + l(R) ; lb((x L R)) = 1 + lb(L) +lb(R) ; e((x L R)) = e(L) + e(R).

  36. more example(cont’d) • Use structural ind. to prove properties of trees. • Show that for all tree T ∈ TS, P(T) =def “ lf(T) =lb(T) + e(T)” holds for all tree T. • Base step: lf(()) = 1, lb(())=0, e(())=1. OK. • ind. step: x: any label, L, R: any trees. assume (ind.hyp.:) lf(L) = lb(L) + e(L) and lf(R) = lb(R) + e(R), then lf((x L R)) = 1 + lf(L) + lf(R) = 1 +lb(L) +lb(R) + e(L) +e(R) e((x L R)) = e(L) +e(R) lb((x L R)) =1 + lb(L) + lb(R) ==> lf((X L R)) = lb((X L R)) + e((X L R)). qed

  37. math. induction revisited • Math. ind. is a special case of structural ind. why? • Inductively define N={0,1,2,...}. • Init: 0 is a natural number. • closure: if n is a natural number, then n’ (called the successor of n, ie., n+1) is a natural number. • Example of natural numbers and non natural numbers: • 0, 0’, 0’’, 0’’’,... --- unary representation of numbers. • 00, 0’0, 0’’00 --- not numbers. • Now applying structural Ind. on N based on the above def. • To prove p(x) holds for all natural number x, it suffices to show: • Base step: P(0) • Ind. step: Let x be any number, If P(x) then P(x’). ---- This is just the math. ind.

  38. More Example • Let N = {0, s0,ss0,sss0,…}. • Define + : N2  N by recursion: for all x in N • Basis: +(x, 0) = x, • Recursion: for all y in N, +(x, y’) = +(x,y) + 1 =s . +(x,y) • Prove by SI that for all x, y ∈ N • 1. x + (y + z) = (x+y) + z • 2. x + y = y + x

  39. Languages • S : any arbitrary set (called alphabet, or set of symbols) • any finite sequence of symbols in S is called a string over S. Ex: S = {0, 1} => e , 000, 10, 1111,... are strings over {0,1}. • Concatenation of strings: x= x1x2...xm ; y = y1...yn => xy = x1x2...xm y1...yn • Definitions • S* is the set of all strings over S. • S+ = S* \ {e} is the set of strings of positive length. • Any subset G of S* is called a language over S. Ex: {},{e}, {0,1}, {0,1}*, {0,00,000,...}, {e, 10,1010,1010,...} are all languages over {0,1}.
