Understanding Lumber: Types, Grades, and Purchase Procedures in Construction

rasia avatar
rasia
16 diapositives · 302 Views · Oct 22, 2014

This guide outlines essential procedures for purchasing and calculating construction materials, focusing on lumber types and grades. It distinguishes between hardwood and softwood, with examples such as oak, pine, and cedar. Learn about rough versus dressed lumber, including sizing discrepancies, and the differences between select and common lumber grades. Additionally, delve into plywood, OSB, and particle board, exploring their composition and uses. Understand key measurements like board feet and square feet to streamline your construction projects effectively.

#understanding lumber: types, grades, and purchase procedures in construction #understanding lumber: types, grades, and purchase procedures in construction ppt #powerpoint #presentation
Understanding Lumber: Types, Grades, and Purchase Procedures in Construction - slide 1
01 / 16Understanding Lumber: Types, Grades, and Purchase Procedures in Construction
1 / 17

Télécharger la présentation

Understanding Lumber: Types, Grades, and Purchase Procedures in Construction
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Ag. Productions I Agricultural Mechanics 26.00-Apply procedures used to purchase and calculate construction materials

  2. Grades of Lumber • Hardwood or Softwood? • Hardwood comes from deciduous trees • Oak, birch, walnut, maple, and hickory • Softwood comes from evergreen conifers • Pine, cedar, cypress, fir, and redwood

  3. Roughed or Dressed? • Rough or nominal sized lumber us the actual size of full dimension. • A 2” X 4” is actually that size with rough surfaces • Dressed or surfaced on all four sides lumber is small than rough lumber and is smooth. • A dressed 2” X 4” is actually 1 ½” X 3 ½” • 1” thick boards are actually ¾”

  4. Select or Common? • Select lumber is free of knots and blemishes • Grades A, B, C, or D • Common lumber us general purpose wood that may have knots or blemishes • Grade No. 1- may have sound smooth knots up to 2” in diameter • Grade No. 2- used for flooring and framing and has large knots or blemishes • Grade No. 3- has loose knots and is used for shelving • Grade No. 4 and No. 5- poor quality used for temporary structures

  5. Plywood is made by gluing odd numbers of veneers (layers) of wood to make 4’X8’ or 4’X12’ sheets of different thickness

  6. Plywood • Hardwood or softwood outside layers • Exterior has waterproof glue • Interior may or may not have waterproof glue • Veneer grades • A-best, smooth, and paintable • B- solid, some tight knots or splits • C- tight knots up to 1 1/2’” and up to 1” splits • D-knots and knotholes and up to 2 ½” splits

  7. AC is exterior plywood with A face and C back • AD is interior plywood with A face and D back

  8. OSB is Oriented Strand Board • It is made from strands, flakes, or wafers sliced from small diameter logs and boned with exterior glue under heat and pressure • OSB is engineered so that the wood strands are oriented, not randomly placed like wafer board

  9. Particle board • Manufactured sheets or wood made from group up scrap wood, sawdust, and glue

  10. Shiplap • Board with a rabbet cut on each edge

  11. Tongue and groove boards • Have a tongue or lip on one edge and a groove on the other edge so that the lip of one side sits into the groove on another board

  12. Board Feet • Board foot is a piece of lumber • One inch thick • 12 inches wide • One foot long

  13. Formula • BF= T” X W” X L’ 12 • Note: Thickness and width are in inches. Length is in feet.

  14. If there is more than one piece, multiply by number of pieces of lumber of the same size

  15. Most construction lumber is priced per thousand board feet

  16. Square Feet • Many building materials are sold by the square foot or in units that combine square footage such as a square or sheet • Square foot is 12” X12” or 144 square inches
