  1. Sales Guide 400/460DX -3 Large Format Display AUG. 2010

  2. Contents I. Market Inside II. Product Outline III. Target Customer IV. Sales Point V. Product Comparison VI. Specification

  3. Market Inside • Market Demand Forecast K units Source : D.Search 2010.Q1

  4. Market Inside • W/W Market Share 2008 (W/W : 16%) 2009 (W/W : 18.5%) Source : D.Search 2010.Q1 (Revenue based)

  5. Market Inside • Focus on mainstream market 40” and 46” 50”+ Portion : 3% 50”+ Portion : 15%

  6. Narrow Bezel Powerful Networking Capability Lower Maintenance Cost Easy Installation Slide In Modular Design Product Outline • 400DX-3/460DX-3 is designed to deliver the largest image display area possible with its super-narrow bezel.

  7. Product Outline • Basic Features Narrow Bezel designed for multi-display: about 22mm Highly reliable with P-DID panel: 24/7 usage High brightness 700cd/m2 suitable to digital Signage Powerful remote controlling with RJ45, newly added, and RS232C Slide in Modular design : Network PC function expandable Front Back Terminal

  8. Product Outline • Comparison table

  9. Product Outline • Network PC option - SIM-Network • 400/460DX-3 DO NOT have Built-in PC model. NO550DXn ONLY 550DX!! • Instead, SIM (Slide In Module) design available + SIM 550DX • Prepare SIM-Network and Insert into 400/460DX-3. • SIM-Network : optional product (sold separately)

  10. Product Outline • How to USE SIM-Network • Slot on the right side of the product from back view • Remove metal cover and Insert SIM-Network

  11. Who is our Target Customer ? Hospital Control Center Bus Stop Vending Market Stock Market Stadium / Concert Hall Airport / Subway / Shopping Mall Casino

  12. Sales Point 1) Professional DID Panel • High brightness（1.5 times brighter than LCD TV) • High Contrast Ratio

  13. Sales Point 2) RJ45 / RS232C remote control • RJ45 port utilization for remote control with no spacial limits

  14. Sales Point 3) DVI out • Utilization without a separate video signal distributor, • for easy content sharing with nearby displays, • Max. 100 units with equal picture quality

  15. Sales Point 4) SIM – Network Option • Variable PC Slot option : High End : Quad Core(2.2G) + DDR3 2GB + HDD 80GB + External Graphic : Mid. End : Dual Core(2.7G) + DDR3 1GB + HDD 40GB Internal Graphic : Low End : Plug and Play Media Player • WHY SIM ? - Easy upgradeable, Fast service time, Various SIM type to be available - Design your own module : Third party’s various options available

  16. Sales Point 5) Display Port - Higher Performance up to WQXGA(10bits) - Multiple Display without distributor .Multi DP output Graphic Card(6~9 ports) - Longer cable support - Interoperability with DVI, VGA, and HDMI Adapter DVI IN - Smaller size 1 2 VGA IN 3 4 HDMI

  17. Sales Point 6) Smart Scheduling • Scheduling functionality with power ON/OFF control for designated times by day of the week, • and support for volume, input source and holiday designation • Convenient OSD settings for up to 3 schedule items consisting of day of the week and time.

  18. Sales Point 7) Power Save, Cost Save, and Earth Save! • Through DPMS system, 400/460DX-3 achieved lower than 250W power consumption at operation mode and 2W at stand-by mode • Energy Star 5.0 compliant >250W(46”) >220W(40”) >210W(46”) >170W(40”) 2W Max Typ Stand By

  19. Sales Point 8) Various Connectivity Port List • Display Port • D-SUB • DVI • CVBS • HDMI1 • HDMI2

  20. Sales Point 9) Narrow Bezel Narrow Bezel designed for multi-display: 22mm Simple & Slim Appropriate for multi-display Optimized to establish all types of video wall (1 x 1~ 10 x 10)

  21. Product Comparison(550DX vs Competitors)

  22. Product Comparison 1) SAMSUNG DX-3 : Optimized PC features • Superior PC module option (SIM) - Fully equipped with optimized features for Video wall NEC P551

  23. Product Comparison 2) SAMSUNG DX-3 vs NEC P551 • Powerful Digital Daisy Chain more than 50 units

  24. Specification

  25. Specification

  26. Specification

  27. Specification

  28. Specification (option) - Accessories Combination - Slide In Module : Network
