  1. KX-MB1500 Series Sales Guide 2011/7/12 Ver1.01

  2. 5 8 4 3 2 1 9 6 Glossary Panasonic MCC Functions Key Features for KX-MB1500 series Panasonic SOHO-AIO/MCC Comparison Frequently Asked Questions Premium Quality Panasonic System Networks Panasonic is a Leading Electronics Manufacturer Solution for Home Business Space Saving Versatility Easy Operation Comparison with KX Series Scanner Features Copier Features Fax Features Printer Features PC Software Comparison with Competitors Maintenance Features Consumables The Key word for each “Premium Quality” Model Variation of KX-MB1500 series 2011 SOHO-AIO/MCC Full Line up Printer Copier Scanner Fax Network Terminology Others Table of Contents

  3. 1 Panasonic System Networks Panasonic is a Leading Electronics Manufacturer Panasonic is Globally Recognized for Quality As a comprehensive electronics manufacturer, Panasonic has earned global brand recognition. People equate Panasonic with quality in both consumer and professional products. Over 30 Years in Imaging and 60 years in Communications Panasonic has accumulated knowledge for more than 30 years in imaging and 60 years in Communications products such as copy machines, fax machines, telephones and PBX. We have also developed extensivecommunication technologies for new infrastructure applications, and key devices for imaging processes.

  4. = Colour LCD = Colour AIO = B&W AIO NEW 2 Panasonic SOHO-AIO/MCC ●Product lineup may vary depending on the sales area. 2011 SOHO-AIO/MCC Full Line-up 2010 2011 A4 Colour AIO KX-MC6000 Series • 20PPM*1, Colour Printing KX-MC6260 KX-MC6040 KX-MC6020 A4 B&W MCC KX-MB2060 Series • 24PPM*2, DECT KX-MB2062 KX-MB2061 KX-MB2060 KX-MB2051 A4 B&W AIO KX-MB3000 Series • 32PPM*1, Duplex Printing KX-MB3150 KX-MB3030 KX-MB3020 KX-MB3010 KX-MB2000 Series • 24PPM*2 KX-MB2030 KX-MB2025 KX-MB2020 KX-MB2010 KX-MB2000 KX-MB1900 • 18PPM*1 KX-MB1500 Series KX-MB1520 KX-MB1500 *1: A4 size *2: A4/Letter

  5. 2 Panasonic SOHO-AIO/MCC ●Product lineup may vary depending on the sales area. Model Variation of KX-MB1500 series for Americas KX-MB1520 KX-MB1500 USA Canada Argentine Brazil Italy only OtherSouth America

  6. 2 Panasonic SOHO-AIO/MCC ●Product lineup may vary depending on the sales area. Model Variation of KX-MB1500 series forEuro / Russia / Mid-East / Asia / China KX-MB1520 KX-MB1500 Western Europe Eastern Europe Russia Middle East Africa Asia (KX-MB1528) (KX-MB1508) China

  7. 3 Premium Quality The key word for each “Premium Quality” Reason for Top Share Quality Content Grand Concept Easy to understand and use, by anyone, anywhere. Multifunctional design, convenience, and quality are better than the competition. Gentle on the environment. High Panasonic quality ensures reliable communication. Easy-to-understand benefits must be thoroughly promoted.

  8. 4 Key Features for KX-MB1500 series Solution for Home Business Smallest size in its class ・Easy to place on shelves or racks ・Can be placed right against the wall ① Space Saving ② Easy Operation ③ Versatility KX-MB1500 Easy operation whether standing or seated ・Slanted operation panel based on ergonomic design ・Easy to operate Convenient All-in-one ・4-in-1 for KX-MB1520 ・3-in-1 for KX-MB1500

  9. 4 Key Features for KX-MB1500 series 1. Space Saving New Printer Engine New engine of KX-MB1500 series does not need the outer tray. Therefore the paper tray doesn't project, and the small footprint is realized. Also new engine is front operation. Front Access New printer engine with Inner Tray Manual paper input Replace toner cartridge

  10. 4 Key Features for KX-MB1500 series 1. Space Saving The smallest body size in the class SCX-4600 41% Down SCX-4300 SCX-4623 21% Down 49% Down ＫＸ-ＭＢ1520 46% Down 36% Down MFC-7440 DCP-7030

  11. 203 360 380 MB1500 ３60 MB2000 SCX4300 ４０５ ６１５ 4 Key Features for KX-MB1500 series 1. Space Saving Slim Back Design The power inlet is inserted from the side of the unit. So, KX-MB1500 series can be placed directly against the wall. Small Installation space Can be placed in tight places yet easy to operate

  12. 4 Key Features for KX-MB1500 series 2. Easy Operation Slanted operation panel based on ergonomic design

  13. 4 Key Features for KX-MB1500 series 2. Easy Operation

  14. 4 Key Features for KX-MB1500 series 3. Versatility ●Product lineup may vary depending on the sales area. KX-MB1520 KX-MB1500 3 in 1 4 in 1 Print Print Copy Copy Scan Scan Fax Speaker Phone *1 USA is “8 in 1”

  15. 5 Panasonic MCC Functions Basic Functions PC Software Printer Copier Fax Scanner Maintenance Consumables

  16. 5 PC Software Multi-Function Station Easy Print Utility - Integrated Printing Software

  17. 5 PC Software Multi-Function Station Multi-Function Station is launcher of PC applications to use KX-MB1500 series completely. • Scan to Viewer, File, Email, OCR*1 or Custom on your computer • Sending, receiving fax documents using your computer (KX-MB1520 only) • Programming features / Editing Phonebook*2 • Saving Journal*2 and Caller ID*2 to a computer • Viewing journal report*2 and Caller ID list*2 on a computer • Start Viewer software • Start Device Monitor • Start OCR software*1 Easy installation - just load the provided CD-ROM. *1 Requires OCR software (KX-MB1500 series doesn’t include OCR software) *2 KX-MB1520 only

  18. 5 PC Software Easy Print Utility The Easy Print Utility is an integrated printing tool that lets you merge and print files created using different applications, such as Microsoft Word and Excel. Word data Excel data Merge Print data and Edit Layout Network or USB You can check the final image on a PC before printing, or editing the layout by rearranging pages or changing the pages to a 2 in 1, or all the way up to a 16 in 1 format. You can also add a header, footer or watermark to documents before printing. After editing the layout, you can save the image as a PDF file. These functions greatly reduce the number of trial prints and misprints.

  19. 5 Printer Features HighSpeed Printing ( B&W ) - B&W: 19 ppm (Letter), 18 ppm (A4) Up to 600 x 600 dpi Print Resolution High Performance Printing ( B&W ) -Custom Paper size setting, Water Mark, N in 1, Zoom, Overlay, Poster, Profile Save

  20. 5 Printer Features NEW Custom Paper size setting If Legal paper size in your country cannot match on the printer driver, you can adjust paper size*1 as Custom size, and the adjusted size can be saved. *1 Width: 210.0 - 216.0mm, Length: 279.4 - 356.0mm

  21. 5 Printer Features High Performance Printing ( B&W ) Watermark N in 1 Zoom Overlay High-performance printer driver handles a wide range of printing requirements.

  22. 5 Printer Features High Performance Printing ( B&W ) Watermark Feature Watermark Watermark Setting + USB Specified watermarks such as “Confidential” or “Draft” can be automatically added when printing. Character size and angle can be adjusted as desired.

  23. 5 Printer Features High Performance Printing ( B&W ) N in 1 Feature N in 1 Printing 4 in 1 2 in 1 N in 1 Setting 16 in 1 8 in 1 USB Since a two or more pages document can be printed on one sheet of paper, paper cost can be saved.

  24. 5 Printer Features High Performance Printing ( B&W ) Overlay Feature Overlay Printing Overlay Setting + Print data Overlay file Printout data USB You can register some overlay files such as company logo beforehand and choose one file when you make overlay printing.

  25. 5 Printer Features High Performance Printing ( B&W ) Zoom Feature Zoom Printing Upper Left Upper Right Zoom Setting Lower Right Center USB You can specify a specific section of the document and enlarge or reduce that portion by 25%-400%.

  26. 5 Printer Features High Performance Printing ( B&W ) Poster Feature Poster Printing 3 x 3 Poster Setting 2 x 2 USB It becomes printing like a poster by printing 1-page data by 1x2/2x2/3x3/4x4, and combining later.

  27. 5 Printer Features High Performance Printing ( B&W ) Profiles Save Profiles Save Feature Printer Driver Setting A setup can be saved and called when a user's original setup is carried out combining various functions. A complicated setup is OK only by carrying out once. A call can also be simplified.

  28. 5 Printer Features Device Monitor Device Monitor starts automatically USB When the toner is low, users could notice it in theDevice Monitor.It will be indicated by ared image with message.

  29. 5 Copier Features High-Speed Laser copy 19 cpm (Letter) , 18 cpm (A4) *1 Enhanced Copier Functions N in 1 Copy Quick ID Copy Image Repeat Separate N in 1 Copy Poster 1x2/2x2/3x3 Edge/Margin *1 Multiple copies of the same original

  30. 5 Copier Features Enhanced Copier Functions N in 1 copy 2 in 1 Brother* supports 2 in 1. Samsung* supports 2 in 1 and 4 in 1. 4 in 1 8 in 1 You can copy multiple originals of onto a single sheet of paper. It increases your productivity and reduces paper consumption. *Competitor Model (Apr 2011) Samsung SCX-4300 Brother DCP7440N/7840W

  31. 5 You can copy both sides of the card original to a single sheet, allowing you to save paper. Especially convenient for copying business cards, driver's licenses or ID cards, etc. Copier Features Enhanced Copier Functions Max 8 in 1 copy Quick ID copy 2 in 1 Both-side printed card Brother doesn't have this feature. Samsung offers "2 in 1" only.* Card Front 4 in 1 8 in 1 Card Back *Competitor Model (Apr 2011) Samsung SCX-4300 Brother DCP7440N/7840W does not have this function.

  32. 5 Copier Features Enhanced Copier Functions Max 8 in 1 copy Image Repeat 2 in 1 Brother doesn't have this feature. Samsung is fixed by document size and paper size.* 4 in 1 8 in 1 Card Front You can make multiple copies of a specified document repeatedly on a single sheet. Convenient for multi-copying of business cards, etc. *Competitor Model (Apr 2011) Samsung SCX-4300 Brother DCP7440N/7840W does not have this function.

  33. 5 Copier Features Enhanced Copier Functions Max 4 in 1 copy Separate N in 1 Copy 2 in 1 2 in 1 Brother and Samsung don’t have this feature.* 4 in 1 4 in 1 N in 1 document can be separated to each pages. (2 in 12 pages, 4 in 14 pages) *Competitor Model (Apr 2011) Samsung SCX-4300 Brother DCP7440N/7840W does not have this function.

  34. 5 Copier Features Enhanced Copier Functions Output Poster Copy Brother doesn’t have this feature. Samsung is fixed 3x3 only. 1 x 2 A4 / LTR original 2 x 2 3 x 3 Available A3/LDR size output *Competitor Model (Apr 2011) Samsung SCX-4300 Brother DCP7440N/7840W does not have this function.

  35. 5 Copier Features Enhanced Copier Functions Output Edge / Margin Edge Brother and Samsung don’t have this feature. Original Margin No Print Area Easy filing *Competitor Model (Apr 2011) Samsung SCX-4300 Brother DCP7440N/7840W does not have this function.

  36. 5 Fax Features PC-Fax included in Multi-Function Station Software Super G3 Fax (33.6kbps) • - 100 Stations Phonebook • 3.5MB Memory Size (TX:2MB RAM, RX:1.5MB F-ROM) Built-in Speaker Phone

  37. 5 Reception Sends and receives data from PC. Transmission Fax Features PC-Fax included in Multi-Function Station Software Phone network Destination Fax PC-Fax Transmission: You can send documents directly from your PC without printing them out. PC-Fax reception: Incoming fax is forwarded to PC automatically where you can view it on your PC.

  38. 5 Fax Features 33.6 kbps Super G3 Fax High-Speed Super G3 Fax Transmission - For reduced communication cost - For high-volume / long-distance About 1/2 Transmission Time Reduced Cost Total approx 40 sec. A4 5pg.* G3 Fax 14.4 kbps Total approx 20 sec. A4 5pg.* Super G3 Fax 33.6kbps With 33.6 kbps Super G3 Fax, you can send a document in approx. 4 seconds* (Letter), half the time it takes conventional 14.4 kbps faxes, reducing communication costs for long-distance calls.* ITU-T No.1 Test chart. *Communication time may vary depending on the condition of the telephone line and destination machine.

  39. 5 Fax Features Built-in Speaker Phone Reliable Faxing with Voice Communication Phone Call reservation after Faxing Feature. *1 1. Press SP-Phone button while sending or receiving a fax. 2. After faxing, ring a machine then lift a handset MIC *1 The default setting of this feature depends on Suffix. RU: ON Except RU: OFF You can talk to the other party after sending or receiving a fax. This will save the added expense and time of making another call.

  40. 5 Scanner Features Easy Scanning (Colour scan) Various Scanning Formats - Multi-Function Viewer Software

  41. 5 x1 Scanner Features Easy Scanning USB Cable *1 It’s easy to send data to your PC. Select SCAN mode and press “Set” key , then press the “Start” key.

  42. 5 BMP JPEG PDF TIFF Scanner Features Various Scanning Formats Scanned data Scanned data can be saved to 4 different file formats: PDF/TIFF/JPEG/BMP. You can select the file format on the MFP or from the PC.

  43. 5 Maintenance Features Comfortable Posture - Slanted Operation Panel Easy to access to maintain machine - Front Access

  44. 5 Maintenance Features Comfortable Posture • Slanted Operation Panel Angle The Operation Panel is tilted based on ergonomics for easy use whether standing or sitting.

  45. 5 Maintenance Features Easy to access to maintain machine • Front Access For easy maintenance in a comfortable posture replacing consumables is done at the front side.

  46. 5 Competitive running costs New Genuine Hologram (3-D type ) Consumables ●Product lineup may vary depending on the sales area. New Toner Cartridge Toner Cartridge NEW All-in-One Cartridge KX-FAT410 / 407: 2,500-sheet*1 KX-FAC408 (for China) : 2,500-sheet*1 *1 ISO/IEC 19752 standard NEW New Genuine Hologram is 3-D type. Therefore customers can distinguish genuine consumables easily without special tool.

  47. 6 Comparison with Competitors Confrontation：KX-MB1520/1500 ⇒ Samsung, Brother *1 Continuous copy of a single original *2 Interpolated

  48. 6 Comparison with KX Series ●Product lineup may vary depending on the sales area. Panasonic A4 SOHO-AIO Basic Lineup 2 *1 A4 size

  49. 6 Comparison with KX Series ●Product lineup may vary depending on the sales area. Panasonic A4 SOHO-AIO Basic Lineup 1 *1 A4 size *2 Cordless handsets may not be available for purchase in some regions. *3 Main Unit – DECT Handset / DECT Handset – DECT Handset *4 Main Unit – DECT Handset / DECT Handset – DECT Handset (Requires Optional handset) *5 Main Unit – DECT Handset (Requires Optional handset) / DECT Handset – DECT Handset (Requires Optional handset)

  50. 6 Comparison with KX Series ●Product lineup may vary depending on the sales area. Panasonic A4 SOHO-AIO Basic Lineup 2 *1 A4 size
