  1. SYSTEMS

  2. Pumps Systems • Our systems are identified as follows • Example: model D-CPS-HT-1000-VFD • D is for Duplex units • CPS is for Constant Pressure System • HT is Hydro-Pneumatic Tank (optional) • 1000 is for pump series • VFD is variable frequency drive (optional) All Systems will have the similar example series and model

  3. Condensate unit systems, Series CVC Units consist of the following • Simplex S-CVC or Duplex D-CVC • Series GV6 or series 1000 pump (s) • 15, 25,35,45 70 or 120 gallons Cast receivers • Gauge glass and stop-cocks • Float switch • Dial Thermometer • Control panel with electric alternator • Voltages available 115/220/460/575 • Factory Mounted & Pre-wired & Tested • Optional Stainless steel Receiver • Optional Steel Receivers • Optional ASME code • Optional Larger Receiver

  4. Boiler feed Units Series BFC Units consist of the following • Simplex S-BFCE or Duplex D-BFCE • Series EVMU or series 1000 pump (s) • Steel receivers 50, 70, 120, 210, 300, 500, 750, 1000, 1500, and 2000 gallons • Gauge glass and stop-cocks • Ball valve (s) and Strainer (s) • Mc Donnell Miller no 21 feed water • Stem or Dial Thermometer • Voltage available 115/220/460/575 • Factory Mounted & Pre-wired & Tested • Optional Stainless steel Receiver • Optional ASME code • Optional Larger Receiver • Optional Control panel with electric alternator • Optional Steam injector

  5. Fuel Transfer Systems, Series FOM Units consist of the following • Simplex S-FOM or Duplex D-FOM • Series CYB rotary vane positive displacement pump (s) • Basket Strainer “P” or “Y” strainer (s) • Gauge glass and stop-cocks • Ball and check valves • Liquid filled pressure gauges • Separate Relief valve (s) • Control panel with electric alternator • Factory Mounted & Pre-wired & Tested • Steel fabricated base plate • Voltages available 115/220/460/575 • Optional other type of pumps

  6. Glycol Fill Systems, Series GLY Units consist of the following • Simplex S-GLY or Duplex D-GLY • Series CYB rotary vane positive displacement pump (s) • Low level shut off float • Hose filling valve (HN050) • Ball and check valves • Liquid filled pressure gauge • Relief valve (s) • Surge absorber • Control panel & pressure switch • Factory Mounted & Pre-wired & Tested • Polyethylene fabricated base plate • Polyethylene 53 gal tank with cover • Voltages available 115/220/460/575 • Optional 25, 106 or 200 gallon tank • Optional Triplex or Quadruple units

  7. Heating and Cooling Systems, (HC) Units consist of the following • Simplex S-HC or Duplex D-HC • Series 880RI pump (s) • Pumps mounted vertically • Ball , Butterfly and check valve (s) • Multi-Function Valve (shown) • Liquid filled pressure gauges • P1 usually runs continuously • Suction & Discharge Stainless Steel or steel Headers • Control panel with pressure switch (es) • Factory Mounted & Pre-wired & Tested • Steel fabricated base late • Voltage available 115/220/460/575 • Optional Triplex or Quadruple Units • Optional Pressure reducing and check valve (s)

  8. Duplex Primary / Secondary Boiler Pack Duplex Control Panel SECONDARY LOOP PRIMARY LOOP

  9. Duplex Pump / Single Boiler PrimarySecondary Boiler Pack (DS-PSB-HT)

  10. The DS-PSB-HT unit installed on the roof top

  11. Duplex 880 VFD Heating pack Glycol Fill VARIABLE FREQUENCY DRIVES Chemical Pot Feeder

  12. Duplex Pump / Duplex Boiler Primary Secondary Boiler Pack (DD-PSB-HT) Secondary Loop Primary Loop Chemical Pot Feeder Expansion Tank

  13. Simplex Heat Transfer pack Shell & Tube Heat Exchanger Series 2000 Pump Expansion Tank

  14. Simplex Heat Transfer pack Plate Heat Exchanger Multifunction Valve Expansion Tank Series 2000 Pump Suction Diffuser

  15. Duplex Heat Transfer Module Plate Heat Exchanger Shell Tube Heat Exchanger Two Expansion Tank Glycol Fill

  16. Duplex Heat Transfer Module

  17. Duplex Heat Transfer Module

  18. Duplex Heat Transfer Module Bill of Material

  19. Duplex Cooling pack (D-HC)

  20. Duplex Pump / Single Boiler PrimarySecondary Boiler Pack (DS-PSB-HT)

  21. Duplex Primary / Secondary Boiler Pack Boilers Circulating Pump Expansion Tank Flow-Switch Chemical Pot Feeder Air Release Valve Low-Water Cut-Off Pump Series 1000 Pressure Relief Valve Air Separator Primary / Secondary Loop

  22. Duplex Primary / Secondary Boiler Pack

  23. Duplex Primary / Secondary Boiler Pack Bill of Material

  24. Series PSB Primary/Secondary Hydronic Boiler Systems Flo Fab packaged systems are designed to reduce time, cost and problems associated with the installation and start-up of a Hydronic heating system. Our pre-engineered system gives you total confidence that Flo Fab will provide you with top quality components that meet your system requirements. If your system requirement does not fit one of our pre-engineered packages, our expertise allows us to design and manufacture the right one for your application. Our philosophy is to provide superior products with outstanding customer service.

  25. Series PSB Primary/Secondary Hydronic Boiler Systems Benefit for Contractors • Compact footprint than otherwise with all components installed separately. • Speeds start-up on Hydronic heating system. • Easier project management; time savings, less chance of misplacing components until actual installation. • Fixed cost, not variable cost as with field installed components. • Our systems are pre-tested, assuring all components function properly together. • Complete custom support from a single source.

  26. Series PSB Primary/Secondary Hydronic Boiler Systems Benefit for Engineers and Owners • One selection, one time. • Guaranteed system performance. • Complex system design brought down to simple component arrangement. • All components assured to work together. • Equipment manufactured to ASME / ANSI standards. • NEMA rated control panels. • Pre-engineered packages for selection. • Custom configuration possible to accommodate existing systems. • Complete custom support from a single source.

  27. Series PSB Primary/Secondary Hydronic Boiler Systems System Standards • Stand-by pump. • Pressure and temperature gauges. • Auto stand-by pumps starts on lead pump failure. • Automatic pump alternation. • Isolation valves to facilitate changing or maintenance of components. • Balancing valves to maintain system equilibrium. • Expansion tank. • Air separator. • Chemical pot feeder. • Suction diffusers. • Boiler protection: flow switch cut-off, low water cut-off, and pressure relief valve. • System drain valves and air vents. • Electrical control panel. • Glycol filled package system. • Prepiped and pretested skid mounted system.

  28. Series PSB Primary/Secondary Hydronic Boiler Systems System Options • Indoor or Outdoor Installation. • Fuel supply: natural gas or propane. • Boiler by-pass to maintain minimum inlet temperature. • Some system packages maybe broken down to be able to fit through conventional door sizes.

  29. Duplex Boiler Domestic Hot Water Pack (D-DHW)

  30. 880RI Cooling Tower PackWith Plate Heat Exchanger

  31. THANK YOU VERY MUCH FOR YOUR ATTENDENCE
