  1. LPR Solution & Integration Strategies Aug 9, 2010

  2. Company Overview • Customer Deployments Overview • Technology Overview • Integration Overview

  3. Company Overview Mark Windover CEO

  4. Company Background • Market Leader in LPR Technology, established 5 years ago. • Technology Leadership key to Mission Growth. • Well capitalized division of Finmeccanica a $28B Aerospace Co. • 900+ Agencies in all 50 states - 20 State Police Organizations • Industry leading 24/7 Mission Support • Proudly Made in the USA at our Greensboro, NC Facility • Mission Support Center in Brewster, NY

  5. COMPANY CONFIDENTIAL Key Deployments • NYPD • NYC “Ring of Steel” LMSI • DEA • Secret Service • DC National Capitol Region (220 Units) • Ft. McHenry Tunnel and Bay Bridge • FBI • U.S. Marshalls • Boston • Washington DC • New York State Police (103 Units Deployed) • Pennsylvania State Police (27 Units) OVER 650 ELSAG FIXED CAMERAS SOLD SINCE 2004

  6. Customer Deployments Overview Todd Child

  7. EOC Operations Center is able to coordinate hundreds of fixed and mobile LPR devices in real time at a customer agency.

  8. ELSAG Operations Center [EOC] Main Menu Select Category (default is ALL) To search for any plate starting in ABC enter ABC% in the “License Plate” area. @=Any letter in this position #=Any number in this position

  9. The ELSAG Operations Center Searching for plates by plate, partial, geography or class

  10. Current EOC Architecture Groups of units (cars or fixed cameras) send data to “Peripherals” which consolidate data and send to the BackOffice. Peripheral Process Group 1 Primary Site . Mapping Service Web Query Interface Car System Camera Peripheral Process Group 2 Car System DB Server Camera Car System SQL Camera Camera Customer Email Server Back Office Processes Car Systems… Peripheral Process(es) Peripheral Process(es) Camera FCUs Peripheral Process(es) Camera Image Store Camera Camera Camera Fixed Camera

  11. Camera Mounting

  12. ELSAG Fixed Cameras Convenient Mounting

  13. ELSAG Fixed Cameras at Ft. McHenry Tunnel

  14. ELSAG Fixed Cameras in NYC

  15. Camera Aiming

  16. Technology Overview Chris Theet

  17. ELSAG Fixed Cameras • Digital Progressive Scan ALPR Cameras • Color Overlay camera to capture the vehicle image • High End Infrared Illumination • Cameras come in all focal lengths up to 50MM • 96%+ Accuracy with ELSAG’s industry leading algorithms • Tailored to regional needs i.e. New York has 4 different protocols; Upstate, Downstate, NYC, MA/VT Border

  18. WHAT WE DO: We Automatically Read License Plates… Any Kind, Anywhere, Anytime • All License Plates are NOT Created Equal • The Magic is in the Details that Can Make All the Difference in the Results • High performance levels of the OCR algorithms achieved through customization using both proprietary software development and parameter optimization .

  19. The Digital Difference ELSAG is the only fixed ALPR camera provider that uses digital cameras to capture plates.

  20. Integration Overview Chris Theet

  21. Integration Paths Field Control Unit (FCU) LPR Cameras Database Field Control Unit (FCU) LPR Cameras

  22. LPR Core Service Windows Service XML Public LPR Web Service Sensor (LPR Camera) HTTP, HTTPS LPR Core Module (Record Creation Logic) Internal Sensor Driver API TCP, RS-232, A/D Relay, Etc… Sensor (LPR Camera) Sensor Driver Library Sensor (IP Megapixel Camera) Sensor (Laser) Admin GUI Private Service LPR Core Diagnostics Module (System/Sensor Health Messaging) Sensor (Radiation) .Net Binary Data over TCP

  23. ENA Protocol

  24. Message Sample Message POST /<configurable url> HTTP/1.1 Host: www.example.com Content-Length: <Length in bytes of Soap Messaging data> <Soap Messaging data goes here> Sample Response HTTP/1.1 200 OK Content-Length: 0 An error will have response code 500 instead of 200 SOAP Messaging Ensure that the username and password are configurable.

  25. SDK • Documentation • Examples including sample code • XSD (XML Schema file)
