Validation Activities for Jason-1 and TOPEX/Poseidon Precise Orbits

This document presents the results of validation activities for Jason-1 and TOPEX/Poseidon precise orbits as discussed during the OSTST Meeting in Hobart, March 2007. Significant findings include the reduction of the ALT-B bias of TOPEX/Poseidon and its impact on different ITRF versions (2000 and 2005). The new ALT-B bias series based on TVG orbits reveals notable drift compared to previous data. The POSEIDON-2 biases showed minimal changes with a consistent drift identified in the time series. GPS Reduced Dynamic orbits from JPL have also been considered.

sally
Télécharger la présentation

Validation Activities for Jason-1 and TOPEX/Poseidon Precise Orbits

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Validation Activities for Jason-1 and TOPEX/Poseidon Precise Orbits P. Bonnefond(1), P. Exertier(1), O. Laurain(1), P. Berio(1), D. Coulot(2) (1)OCA/GEMINI, Grasse (2)IGN, Marne la vallée OSTST Meeting, Hobart, March 2007

  2. IMPACT OF ORBIT TOPEX/Poseidon ALT-B bias (at epoch 2002.0) is decreased by 11.3 and 8.1mm for TVG ITRF2000 and TVG ITRF2005-rescaled respectively. The new ALT-B bias time series based on TVG orbits exhibit a drift relatively to the one based on the GDR orbit of -1.7mm/yr and -1.2mm/yr for TVG ITRF2000 and TVG ITRF2005-rescaled respectively. Jason-1 POSEIDON-2 bias (at epoch 2002.0) is not significantly changed for both TVG ITRF2000 and TVG ITRF2005-rescaled . The new POSEIDON-2 bias time series based on TVG orbits exhibit a drift relatively to the one based on the CNES GDR-B orbit of -1.4mm/yr and -0.8mm/yr for TVG ITRF2000 and TVG ITRF2005-rescaled respectively. GPS Reduced Dynamic orbits from JPL have been recently released (07a version, not shown on the Figure). As for TVG orbits POSEIDON-2 bias at epoch 2002.0 is not significantly changed but the time series exhibits an opposite drift of+0.9mm/yr relatively to the one based on the CNES GDR-B orbit. And what about the LRA correction… OSTST Meeting, Hobart, March 2007
