  1. Skeletal System Spring 2010

  2. Adult Skeleton

  3. Skeletal System • Functions • Structural framework for body • Protection of organs • Levers • Mineral storage • Blood cell production

  4. Skeletal System • 350 bones at birth. • 206 at 25 years of age • Bones and joints are included in the skeletal system. • Each bone is an organ.

  5. Bone Shapes • Long bones • Longer than wide • Short bones • As broad as they are long • Flat bones • Thin, flat, usually curved • Irregular • Combination • Sesamoid • Found in tendons, near joints

  6. Long Bones • Shaft of bone aka Diaphysis • Outer part is compact bone • Inner part is spongy bone • Contains medullary cavity • Lined with endosteum • Filled with yellow bone marrow • Stores fat

  7. Long Bones • Ends of long bones are called epiphysis • Point of connection to other bones through ligaments, cartilage and muscles • Cartilage protects against friction and rubbing of bones • Inner part is spongy bone • Proximal and distal epiphysis • Bone covering is called periosteum.

  8. Short Bones • Cube shaped

  9. Flat Bones • Flat, curved • Areas of protection and muscle attachment

  10. Irregular Bones

  11. Sesamoid Bones • Form in a tendon near a joint in response to friction, tension and physical stress. • Only 1 named sesamoid bone, patella.

  12. Bone Cells Osteogenic cellOsteoblast (builds) Osteocyte (maintains)

  13. Bone Cells • Osteogenic cell • Bone stem cell • Located in the endosteum and periosteum • Osteoblast • Blast = Immature cell capable of reproduction • Builds bone • process is ossification • Osteocyte • Maintains bone matrix

  14. Bone Cells Osteoclast (reabsorbs bone) Osteoclasts formed by fusion of 2 monocytes.

  15. Bone Extensions • Extensions are called processes • Serve as points of muscle attachment (tendon) • Serve as points of articulation with other bones (ligament)

  16. Trochanter

  17. Bone Depressions • Shallow hollowed space or a groove or opening.

  18. Bone Marrow • Red is contained in long and flat bones in adults; most bones in infants. • Red • Site of blood cell production. • Yellow • Replaces red as a person ages. • Site of fat storage.

  19. The Skeleton • Axial Skeleton • 80 Bones • Skull (counting 6 auditory ossicles and 1 hyoid bone) (29) • Vertebral Column (26) • Vertebrae • Ribs & sternum (25)

  20. Skull

  21. Skull

  22. Skull

  23. Skull

  24. Auditory Ossicles

  25. Hyoid Bone

  26. Spine

  27. 5 Regions of the Spine • Cervical • 7 vertebrae • Thoracic • 12 vertebrae • Lumbar • 5 vertebrae • Sacral • 51 bone • Coccygeal • 41 bone

  28. Rib Cage

  29. The Skeleton • Appendicular Skeleton • 126 bones • Pectoral Girdle (4) • Upper limbs (60) • Pelvic Girdle (2) • Lower limb (60)

  30. Pectoral Girdle

  31. Upper Extremity

  32. Pelvic Girdle

  33. Ways To Tell Male From Female Pelvis • Spines farther apart vs. more straight “up-and-down” in male. • Obturator foramen: oval in female vs. rounded in male. • Pubic arch: less than 90°, more sharply angled in male; greater than 90°, more rounded in female.

  34. Joints • Points where bones connect. • Bones are held to bones by ligaments. • Classified according to degree of movement and according to whether they contain a joint space. • If they have a joint space, they are called synovial.

  35. Classified by Movement • Diarthrosis: • Freely moveable. • All are synovial.

  36. Classified by Movement • Amphiarthrosis: • Slightly moveable. • All are cartilaginous, not synovial. • Cartilaginous disc between bones.

  37. Classified by Movement • Synarthrosis: • Immoveable joint. • All are fibrous, not synovial. • Bones are held together by tough fibrous tissue.

  38. Fractures • Simple aka closed: • bone breaks cleanly, not through skin. • Includes hairline frx in which parts are not separated.

  39. Fractures • Open aka compound • Ends of broken bone pierce the skin. • Includes dislocation of bone parts called complex frx.

  40. Fractures • Greenstick aka incomplete. • Usu in a child.

  41. Fractures • Comminuted • Bone is shattered or splintered.

  42. Fractures • Colles’ Frx • Fracture of distal radius with posterior displacement of distal portion.

  43. Fractures • Impacted • Broken portions are forcefully pressed together. • In the skull, this is called a depression fracture.

  44. Fractures • Compression frx. • Occurs when vertebrae are forced into each other.

  45. Fractures • Spiral frx. • The bone is twisted apart. • Often occurs in skiing accidents as shown here.

  46. Disorders • Osteoporosis • Porous bones: demineralization of bones • Starts around age 35.

  47. Disorders • Osteomyelitis • Bacterial infection of the bone. • Case History: This 13 y.o. healthy teenager sustained a both bones (radius and ulna) forearm fracture, grade I open, playing football at summer camp. It was washed out and plated 3 days later. • Clinical Course: He developed fever, chills, and drainage of the wound several weeks after treatment. He was referred shortly after given oral antibiotics, 6 weeks after injury, with the following presentation.
