  1. Support Vector Machines Presented by: Yasmin Anwar

  2. Outlines • Introduction • Support Vector Machines • SVM Tools • SVM Applications • Text Classification • Conclusion

  3. Introduction • Proposed by Boser, Guyon and Vapnik in 1992. • SVMs are one of the best classification methods. • Supervised learning • Non-probabilistic binary linear classifier

  4. Find a linear hyperplane (decision boundary) that will separate the data Support Vector Machines

  5. One Possible Solution Support Vector Machines

  6. Another possible solution Support Vector Machines

  7. Other possible solutions Support Vector Machines

  8. Which one is better? B1 or B2? How do you define better? Support Vector Machines

  9. Find hyperplane maximizes the margin => B1 is better than B2 Support Vector Machines

  10. Support Vector Machines Support Vectors

  11. Support Vector Machines

  12. Support Vector Machines x2 • Noisy data, outliers, etc. • Slack variables ξi x1

  13. Nonlinear Support Vector Machines • What if the problem is not linearly separable?

  14. Nonlinear Support Vector Machines

  15. Nonlinear Support Vector Machines • The kernel function transforms the data into a higher dimensional space to make it possible to perform the separation.

  16. SVM tools • SVM software: • LibSVM(C++) • SVMLight(C) • The complete machine learning toolboxes that has SVMs: • Weka(Java) • RapidMinar

  17. SVM Applications • SVMs are currently among the best performers for a number of classification tasks: • Text classification • Image classification • Microarray Gene Expression Data • Database Marketing

  18. Text Classification • Step 1—text pre-processing • to pre-process text and represent each document as a feature vector • Step 2—training • to train a classifier using a classification tool (e.g. Weka, SVM-light) • Step 3—classification • to apply the classifier to new documents

  19. Text Pre-Processing • Tokenization • Stop word removal: “a”, “the”, “I”, “he”, “she”, “is”, “are”, etc. • Stemming: teacher  teach • Feature extraction: • To use TF (term frequency) as feature value • To use TF*IDF (inverse document frequency) as feature value • IDF = log (total-number-of-documents / number-of-documents-containing-t)

  20. Text Pre-Processing • Tokenization Example

  21. SVM-light • SVM-light: a command line C program that implements the SVM learning algorithm • Classification, regression, ranking • Download at http://svmlight.joachims.org/ • Documentation on the same page • Two programs • svm_learn for training • svm_classify for classification

  22. SVM-light Examples • Input format 1 1:0.5 3:1 5:0.4 -1 2:0.9 3:0.1 4:2 • Output format • Positive score  positive class • Negative score  negative class

  23. Conclusion • SVM • Large Margin gives Better generalization ability and less over-fitting • Non-Linear SVM • Kernel function maps the data points to higher dimensional space in order to make them linearly separable.

  24. References [1] P. H. Chen, C. J. Lin, and B. Schölkopf, A tutorial on ν-support vector machines, Appl. Stoch. Models. Bus. Ind.2005, 21, 111-136. [2] http://svmlight.joachims.org/ [3] http://www-users.cs.umn.edu/~kumar/dmbook/index.php [4] https://agora.cs.illinois.edu/download/attachments/9642083 /Text+Categorization+using+SVM-light.ppt?version=1& modificationDate=1212615247000 [5] http://www.cs.waikato.ac.nz/ml/weka/ [6] http://www.clopinet.com/isabelle/Projects/SVM/applist.html [7] http://www.dtreg.com/svm.htm
