Model-Based Stereo Approach for Robustly Handling Occlusions in 3D Morphable Models

sheena avatar
sheena
21 diapositives · 341 Views · Sep 03, 2014

This paper discusses a sophisticated model-based stereo approach that effectively handles occlusions in 3D Morphable Models (3DMMs). The method integrates shape and texture fitting through stereo vision techniques, ensuring improved accuracy even under challenging conditions like varying illumination, pose variations, and occlusions. The advantages of this approach include its self-occlusion capability and robustness against foreign body interferences. The research presents quantitative results from extensive experiments using stereo face databases, demonstrating significant advancements in accuracy and reliability.

#model-based stereo approach for robustly handling occlusions in 3d morphable models #model-based stereo approach for robustly handling occlusions in 3d morphable models ppt #powerpoint #presentation
Model-Based Stereo Approach for Robustly Handling Occlusions in 3D Morphable Models - slide 1
01 / 21Model-Based Stereo Approach for Robustly Handling Occlusions in 3D Morphable Models
1 / 17

Télécharger la présentation

Model-Based Stereo Approach for Robustly Handling Occlusions in 3D Morphable Models
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Model-Based Stereo with Occlusions Fabiano Romeiro and Todd Zickler TexPoint fonts used in EMF. Read the TexPoint manual before you delete this box.: AAAAAAAAA

  2. Introduction Varying illumination Varying pose Occlusions Varying expressions

  3. Introduction Past Work: Image-based For example: Eigenfaces [Turk and Pentland, 1991] Fisherfaces [Belhumeur et al, 1997]

  4. 3D Morphable Models (3DMMs) 2D+3D AAMs 2D AAMs [Cootes et al, 1998; Baker et al, 2004; Mathews et al, 2004; Gross et al, 2006] [Xiao et al, 2004] [Blanz et al, 1999; Blanz et al, 2003; Blanz et al, 2005; Smet et al, 2006] Introduction Past Work: Model-based

  5. 3D Morphable Models (3DMMs) Pros • - Self-occlusion handled by model itself • - Allows direct modeling of illumination Cons - Difficult and expensive fitting process [Blanz et al, 1999; Blanz et al, 2003; Blanz et al, 2005; Smet et al, 2006] Introduction Past Work: 3DMMs

  6. - Stereo based cost [Fransens et al, 2005] • Stereo fitting with both shape and texture • →Robust to foreign-body occlusions Introduction Past Work: Stereo 3DMMs - Texture model not needed Our work • → Improved Accuracy

  7. Outline • 3DMM Background • Joint Shape and Texture Stereo Fitting • Handling Occlusions • Conclusions

  8. Basis for shape - Basis for texture Background 3DMMs Vectorization of laser scans: PCA performed: [Blanz and Vetter, 1999]

  9. [Blanz and Vetter, 1999] Background 3DMMs Representation of face shape and texture: Prior probabilities on the coefficients:

  10. Stereo Match

  11. Texture Match

  12. Joint Shape and Texture Stereo Fitting of 3DMMs

  13. Robust Stereo Fitting of 3DMMs

  14. Optimization Procedure Initial fit - Fit Shape, Pose to minimize reprojection error on selected feature points - Rough initial estimates of Shape and Pose Optimization procedure 4 experiments Stereo and texture Stereo Robust Stereo and texture Robust Stereo

  15. Results First 2 experiments: Stereo and Texture vs. Stereo 480 recovered shape models (60 individuals, 8 poses) K.U. Leuven Stereo face database [Fransens et al, 2005]

  16. Results Qualitative Results Stereo and Texture Stereo

  17. Results Qualitative Results Stereo+texture Stereo

  18. Results Quantitative Results

  19. Results Under Occlusions Half-Occlusion Full Occlusion near Full-Occlusion far

  20. Robust Stereo Robust S+T Results Under Occlusions Input Robust Stereo Robust S+T Shape Estimate Occlusion Map

  21. Conclusions Robust stereo fitting of 3DMMs - Uses both stereo constraint, texture information • Increased accuracy of fit - Ability to handle occlusions Future Work - More sophisticated stereo matching term - Different feature spaces - Break model into segments respecting occlusion boundaries
