Essential Parts of a Microscope for Beginners

Learn about the key components of a microscope including body tube, arm, base, nose piece, stage clips, diaphragm, light source, stage, and adjustment knobs. Understand their functions and how to use them effectively for better observation and analysis.

shiloh
Télécharger la présentation

Essential Parts of a Microscope for Beginners

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. The Microscope

  2. 1. Body Tube – Sends light to the Eyepiece • 10. Arm – Holds up the magnification apparatus • 14. Base – Supports entire apparatus • 2. Nose Piece – Allows you to change lens. • 6. Stage Clips – Holds Slide in place • 7. Diaphragm – Controls the amount of light • 8. Light source – Provides light for viewing • 11. Stage – Holds the specimen • 12. Coarse Adjustment Knob – Moves the focus in large amounts, quickly. • 13. Fine Adjustment Knob – Moves the focus in small amounts, slowly. • 9. Ocular Lens (Eyepiece) – Provides final image for viewing • 5. High Power – 25 Times. USE FINE ADJUSTMENT KNOB ONLY. Most Detail • 3. Low Power – 4 times. Used to locate specimen. Uses Coarse Knob • 4. Medium Power – 10 times. USE FINE ADJUSTMENT KNOB. More Detail
