  1. Max Knor Developer Evangelist Microsoft Österreich .NET MicroFramework Embedded Development mit .NET oder „Small Is Beautiful“

  2. Thin Clients Windows Mobile Smartphone Industrial Automation ATMs / Kiosks Windows Mobile Pocket PC Phone Sensor Networks Windows Automotive Office Automation Retail Point-of-Sale Tablet PC AuxiliaryDisplays Portable Media Centre Medical Devices VoIP Phones Windows-based Terminals Mobile Handhelds Remote Controls Set-top Boxes Entertainment Devices Notebook PC Gateways Set-top Box WearableDevices .NET Micro Framework Windows XP Embedded Windows CE Windows Vista Functionality

  3. Embedded Devices • Embedded Devices are tiny platforms • Remote Controls • Data loggers • Device Controllers • Single Purpose Device • The processor is there just to drive the device • High volume/ Low cost • No need for an operating System

  4. Writing Embedded Code the „old“ way • C or C++ with low abstraction level • Different tools and device drivers • Debugging ?! • Emulation / Testing ?! • Reusability ?!

  5. .NET Micro Framework • „.NET way of dev“ for Embedded Devices • Same language: C# • Managed environment • Familiar APIs • Visual Studio IDE • Hardware Emulators

  6. What’s the .NET Micro Framework? • .NET on a “TINY Footprint” device • <400 KB of RAM • No memory management hardware • No Operating System • Applications run from Flash memory (EEPOM) • Subset of the full .NET Framework

  7. .NET Micro Framework Context

  8. Special in execution • C# codecompiledto MSIL code • MSIL codecompressedto .PE file (MetaDataProcessor.exe) • MSIL codegetsinterpretedatruntime • (NOT JIT compiled!) • Forcode: normal .NET assembly

  9. Hardware Access • No strange bitmasks or control registers • .NET MF provides abstraction • Object Model with classes, events, …

  10. Reading from a pin // Which pin to connect Cpu.Pin pin = Cpu.Pin.GPIO_Pin3; // Create a port connected to a pin InputPort port = new InputPort( pin, //CPU pin false, //no glitch filter Port.ResistorMode.PullUp //resistor mode is up ); // Read from the pin If (port.Read()) Debug.Print(“signal high”);

  11. Switch on thelight demo

  12. No Operating System ?! • .NET Micro Framework works without OS • Native execution using bootable runtime system

  13. .NET Micro Framework Architecture

  14. Runtime Features • Serialization • ~60% smaller than .NET Framework • Reflection • Remote Procedure Call (RPC) • Invoke methods on remote objects (.NET Micro Framework custom implementation ) • Security • XTEA (symmetric), RSA (asymmetric) • Exception handling • Delegates / multicast delegates • Typed Function pointers • Enables events dispatching and event driven programming vs. poll driven • Networking • Support for wired and wireless Ethernet • Sockets from System.Net namespace • Managed Drivers • C# implementations of GPIO, PWM, VTU32, I2C, SPI bus and USART

  15. .NET Framework System.Web System.Windows.Forms • UI Controls • HTML • Web • Services • Description • Discovery • Protocols Design Component model System.Drawing Drawing 2D Printing Cache Security Imaging Text Configuration Session state System.Data System.XML XML Document Serialization ADO.NET SQL Client Xslt/XPath Reader/writers Design SQL ServerCE System Collections IO Configuration • Runtime • Interop • Remoting • Serialization Security Net Service process Text Reflection Diagnostics Globalization Resources Threading

  16. .NET Compact Framework System.Web System.Windows.Forms • UI Controls • HTML • Web • Services • Description • Discovery • Protocols Design Component model System.Drawing Drawing 2D Printing Cache Security Imaging Text Configuration Session state System.Data System.XML XML Document Serialization ADO.NET SQL Client Xslt/XPath Reader/writers Design SQL ServerCE System Collections IO Configuration • Runtime • Interop • Remoting • Serialization Security Net Service process Text Reflection Diagnostics Globalization Resources Threading

  17. .NET MicroFramework System.Web System.Windows.Forms • UI Controls • HTML • Web • Services • Description • Discovery • Protocols Design Component model System.Drawing Drawing 2D Printing Cache Security Imaging Text Configuration Session state System.Data System.XML XML Document Serialization ADO.NET SQL Client Xslt/XPath Reader/writers Design SQL ServerCE System Collections IO Configuration • Runtime • Interop • Remoting • Serialization Security Net Service process Text Reflection Diagnostics Globalization Resources Threading

  18. Emulator Architecture Microsoft.SPOT.Emulator.dll EmulatorNative.dll Microsoft.SPOT.Hardware.pe Microsoft.SPOT.Native.pe EmulatorComponents Microsoft.SPOT.Graphics.pe x86 HAL / PAL SpiDevice SpiDevice MFApplication.pe SpiDevice GpioPort SpiDevice SpiDevice SpiDevice GpioPort TinyCLR (x86) ConfigurationEngine MyEmulator.exe UI my.config MyComponent

  19. Versus Actual Hardware Microsoft.SPOT.Hardware.pe Microsoft.SPOT.Native.pe Microsoft.SPOT.Graphics.pe HAL / PAL MFApplication.pe TinyCLR

  20. Device Emulator„SWITCH(!) on thelight“ demo

  21. Graphical Display Facilities • Two levels of display provision • Simple bitmap support • Images, shapes, simple text rendering and wrapping • Windows Presentation Foundation • WPF based display elements • No XAML/Just Object Model

  22. Persistent Storage • No file system for Micro Framework • Store information in memory using standard .NET objects and value types • Microsoft.SPOT.ExtendedWeakReference • Maintain data between sessions • Priority levels • ID value = “filename”

  23. WPF UIPersistence demo

  24. Code Challenges • Power Requirements • Only execute code when necessary • Reduce Thread.Sleep: use interrupts/events • Debugging and Performance Tuning • Debug.Print uses approx. 30ms of CPU time • Aggregate statistics • Subtract Debug.Print time

  25. Summary • .NET Platform for Embedded Devices • No operating system necessary • Customizable Emulator Environment • WPF subset for LCD displays
