  1. Joints AS Level Anatomy and Physiology

  2. Lesson Outcomes By the end of today’s lesson you will understand: • The 6main types of synovial joints • The structure of synovial joints • The type of movementjoints can perform

  3. Synovial joints • Freely moveable • Found in the appendicular skeleton Structure There are several important structures common to all synovial joints…

  4. Structure and Function of Synovial Joints (Important!) • FOUR features • Articular/Hyaline Cartilage Smooth cartilage at the end of bones at the joint • Two-Layered Joint Capsule Outer Layer – Tough fibrous capsule Inner Layer – Synovial Membrane • Synovial Fluid Slippery fluid in joint capsule (like egg white!) • Ligament A band of strong fibrous tissue Structure Structure Structure Structure

  5. Structure and Function of Synovial Joints (Important!) • FOUR Functions • Articular/Hyaline Cartilage Prevent friction between articulating bones • Two-Layered Joint Capsule Outer Layer – Strengthen joint Inner Layer – To secrete synovial fluid • Synovial Fluid Reduce friction between articular cartilages Nourish articular cartilage Rid the joint of waste • Ligament To connect one bone to another

  6. Types of Synovial Joint • There are six main types of synovial joint found in the body • Can you name them and give examples?

  7. The 6 Types • Hinge Knee, Elbow • Condyloid Wrist • Gliding Articulating surfaces of the vertebrae • Pivot Radio-ulna, atlas/axis • Ball and Socket Shoulder, Hip • Saddle Thumb

  8. Movements at Joints • All movements start from the anatomical position (AP) – see picture of skeleton • Flexion– movement forward from AP (except knee joint) • Extension – movement backward from AP (except knee joint)

  9. Practice these movements for the following joints….Wrist, elbow, shoulder, spine, hip, knee TASK Info:The knee joint is the only exception where flexion moves backwards and extension moves forwards

  10. Abduction – movement away from midline of body Occurs at wrist, shoulder, hip • Adduction – movement towards midline of body Occurs at wrist, shoulder, hip • Rotation and circumduction– what is the difference? To recognise the difference: Rotation: the long axis of the moving part would draw a dot if a pen was held at the end Circumduction: the pen would draw a circle

  11. Specialist Movements • Supination – radio-ulna joint – palms up • Pronation – radio-ulna joint – palms down • Dorsi-flexion – ankle joint – toes up • Plantar-flexion– ankle joint – toes down Point to the floor • Practise these movements then complete worksheet 1.3 (labelling an upper/lower joint)

  12. Homework! Complete the crossword Hint For 3 down the pelvis is also called the illium!
