  1. Bad Design By: William Nash

  2. Road Runner Gig Bag for Electronic Drum Set

  3. Flaw • Tips over very easily when transporting drum set.

  4. Dimensions 38 inches 14 inches 12 inches Volume: 14 x 38 x 12 = 6384 cubic inches

  5. Wheels Radius: 1 inch Width: 7/8 inch

  6. Proposed Solution Old New New Width: 1.5 inches New Radius: 1.5 inches

  7. Negatives to New Design Cost? Weight?

  8. References • All pictures and measurements were taken by me.
