Understanding Dimensional Analysis: Converting Units Made Simple

toshi avatar
8 diapositives · 333 Views · Aug 14, 2014

Dimensional analysis is a powerful technique used to convert units from one form to another. The process involves three essential steps: first, identify the starting unit; next, determine the end unit; and finally, find the appropriate conversion factors. A conversion factor relates the two units and is always equal to one, allowing for seamless transitions. This guide offers practical examples, such as converting miles to feet or gallons to liters, and provides a straightforward method for performing these calculations accurately.

Understanding Dimensional Analysis: Converting Units Made Simple - slide 1
01 / 8Understanding Dimensional Analysis: Converting Units Made Simple
1 / 17

Télécharger la présentation

Understanding Dimensional Analysis: Converting Units Made Simple
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation
  1. Dimensional Analysis

  2. The objective is to convert one unit to another unit

  3. Three steps to get started: 1. Determine the starting unit. 2. Determine the end unit. 3. Determine the conversion factor(s) required.

  4. Conversion Factor • The conversion factor is always equal to one. • A conversion factor can be written either way depending what needs to be converted. • Examples • - 100 pennies = 1 dollar 100 pennies or 1 dollar 1 dollar 100 pennies • - 1000 grams = 1 kilogram 1000 grams or 1 kilogram 1 kilogram 1000 grams

  5. Remember…. 1. Write the given or known (home base) in the first block over 1 2. Use the appropriate conversion factor(s) to make the unit change needed. Make sure you alternate so that matching units can cancel out 1 mile 1 5280 ft. 1 mile

  6. 3. Do the math by multiplying across the • top then across the bottom. • 4. Keep up with the remaining unit. • 5. Simplify to a decimal. • 3. Circle the answer.

  7. Convert 23 miles to feet 23 miles 1 5280 ft. 1 mile 23 x 5280 ft = 121440 feet = Convert 36000 feet to miles 1 mile 5280 ft. 36000 ft. 1 36000 x 1 = 6.82 miles = 5280

  8. Convert 3 gallons to liters 3.79 l 1 gal 11.37 l 1 3 gal 1 = = 11.37 l Convert 1.7 kilograms to grams 1.7 kg 1 1000 g 1 kg 1.7 x 1000 g = 1700 g =
