Temporal Energy Gain in Global Reflection of Snow and Water Surfaces
DESCRIPTION
Explore reflection examples of snow and water surfaces, utilizing the albedo factor and transmission values. Analyze the global effects on energy gain over time under clear sky conditions.
Download
1 / 1
Télécharger la présentation
Temporal Energy Gain in Global Reflection of Snow and Water Surfaces
An Image/Link below is provided (as is) to download presentation
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.
E N D
Presentation Transcript
Multi-Reflection Examples (a = 0.5, t = 0.5): Snow (A=0.85): Global = 1.67 * S Water (A=0.10): Global = 1.05 * S Examples (a = 0.5, t = 0.5): Snow (A=0.85): Global = S * t * 1.74 = 0.870 Water (A=0.10): Global = S * t * 1.05 = 0.525 S Stratus-Cloudwith Transmission: t , Bottom Side Albedo: a S*t*(A*a) S*t*(A*a)3 S*t*A S*t*(A*a)2 S*t S*t*(A*a)4 S*t*(A*a)5 S*t*(A*a)6 Surface Albedo: A Global = S *t + S*t*(A*a) + S*t*(A*a)2 + S*t*(A*a)3 + … = Temporal Energy Gain Clear Sky
