  1. Shape Memory Alloys(SMA’s) By Chris Bomersbach MEEN 3344

  2. Major Developments • Buehler’s discovery of an NiTi alloy (Nitinol) in 1962, formed the basis for commercial use. Before then shape memory alloys had been observed but where not affective enough for practical use. • SMA’s have seen commercial use since the late 1980’s when they where first used for coupling on oil pipes.

  3. Types • One way SMA’s are the most common type and can be deformed when cool, but upon heating, they return to their trained shape. • Two way SMA’s can be trained to have a cool shape as well as a hot one. • Different types include • Ag-Cd 44/49 at.% Cd • Au-Cd 46.5/50 at.% Cd • Cu-Al-Ni 14/14.5 wt.% Al and 3/4.5 wt.% Ni • Cu-Sn approx. 15 at.% Sn • Cu-Zn 38.5/41.5 wt.% Zn • Cu-Zn-X (X = Si, Al, Sn) • Fe-Pt approx. 25 at.% Pt • Mn-Cu 5/35 at.% Cu • Fe-Mn-Si • Pt alloys • Co-Ni-Al • Co-Ni-Ga • Ni-Fe-Ga • Ti-Pd in various concentrations • Ni-Ti (~55% Ni http://en.wikipedia.org/wiki/Shape_memory_alloy

  4. Ni-Ti • This video of one way Nitinol can give you an idea of just how effective it can be compared to conventional metals. • http://www.youtube.com/watch?v=fsBHF_j2FJ4&feature=related • Nitinol can also be returned to it’s original shape by sending an electric current through it. As it resists the electricity, it becomes heated.

  5. Pseudo Elasticity • The most common commercial application involves the pseudo-elastic property during it’s high temperature state. • This includes eye-glasses, cell phone antennas, and so on, which are experiencing their high temperature state at room temperature.

  6. Future Applications • In the future, if significant steps can taken in cost reduction, SMA’s will be used for almost every metal object. Mail boxes could pop back into shape on a sunny day. That slinky you had as a child would have lasted longer then thirty minutes. • Imagine getting into a car wreck, then only needing to hold a torch to your vehicle to repair the damage. • There are endless new uses for Biomedical applications, such as surgical equipment and mechanical devices. • There could also be morphing airplanes and submarines that could increase efficiency at different speeds.

  7. References • http://www.bio-medicine.org/biology-technology-1/Re-Shaping-the-Future-with-Shape-Memory-Alloys---SMA-Starter-Kit-10282-1/ • http://www.prudentpressagency.com/modules/news/article.php?storyid=8180 • http://smart.tamu.edu/ • http://www.stanford.edu/~richlin1/sma/sma.html
