  1. Computer Design Weber

  2. Motherboard • Motherboard Specs • Model: ASUS SABERTOOTH Z77 • Supported Processor(s): List All • 2nd generation Intel® Core™ i3 • 2nd generation Intel® Core™ i5 • 2nd generation Intel® Core™ i7 • Intel 3rd Generation Core i3 Processor • Intel 3rd Generation Core i5 Processor • Intel 3rd Generation Core i7 Processor • Processor Interface: LGA1155 • Memory Supported: (List type and fastest speed supported) • DDR3 1333MHz • DDR3 1600MHz • DDR3 1866MHz • Number of Memory Slots: 4 • Maximum Memory Supported:32 GB • Form Factor: ATX

  3. Motherboard • Expansion Slots (Number) 6 • PCIe x 1:3 • PCIe x 16: 3 • ATX Power Connectors:1 x 24-pin ATX Main Power Connector • PC Power Connectors: 1-8pin • 3 GB/s Serial ATA Headers: 4 • 6 GB/s Serial ATA Headers: 2 external • Built In Sound Card: Y/N Yes • Built In Network Card (LAN): Y/N Yes • USB 3.0: Y/N Yes • Price:$249.99

  4. CPU (Processer) • Brand: Intel • Processor Class: LGA 1155 • Processor Interface: core I7 • Processor Speed (GHz): 3.5 • Price: $319.99

  5. Processor Fan (included with processor)

  6. RAM • Type: DDR 3 • Size (GB): 16 • Speed (MHz): 1600MHz • Quantity:2 • Price:102.99 x 2 = $205.98

  7. Hard Drive • Brand: Seagate • Capacity: (GB or TB) 3 TB • Interface: SATA • Buffer Memory: 64 MB • Speed: 7200 RPM • Price:$139.99

  8. Blueray Drive • Type and Description:LG UH12NS29 12X Internal Blu-Ray Player - 3D Playback, M-Disc Support, Silent, Jamless Play, SATA Interface • Interface: SATA • Read/Record/Rewrite Speeds: Blue ray 12x DVD 16X CD 48 X • Price:49.99

  9. Video Card • Brand / Type: ATI • GPU: ATI Fire GL • Video Memory: 2GB • Memory Type: GDDR4 • Interface (PCIe, PCIe 2.0): PCI Express x16 • Connectors (VGA, DVI, HDMI,S-Video…): DVI • Price:$374.99

  10. Case • Brand / Type: Thermaltake • Form Factor: ATX • External 5.25” Bays:4 • External 3.5” Bays: • Internal 3.5” Bays:6 • Price:149.99 before rebate 129.99 after

  11. Power Supply • Power (Watts): 850 • SATA Connectors: 7 • 4-Pin Peripheral Connectors:7 • 6-Pin PCI-E Connectors:2 • 8-Pin PCI-E Connectors:2 • Motherboard Connector:20+4 pin • 4-Pin P4 Connector: • 8-Pin EPS Connector:2 • Price:$109.99

  12. Monitor • Brand / Type: Benq • Size: 55” • Interface/Connector(s): • DVI • S-Video • Component Video • HDMI • VGA • Composite • Maximum Resolution: 1920 x 1080 • Price:$4499.99

  13. Keyboard and Mouse • Description: SMK Link VP6324 RemotePoint Wireless Presentation Desktop Suite - Rechargeable Media Keyboard & Laser Mouse with Presentation Remote Control, Up to 100' Wireless Range • Price:299.99

  14. Total Price • Motherboard  $ 249.99 • CPU  $ 319.99 • RAM  $ 205.98 • Hard Drive  $ 139.99 • Blue ray Drive  $ 49.99 • Video Card  $ 374.99 • Computer Case  $ 129.99 • Power Supply  $ 109.99 • Monitor  $4499.99 • Keyboard  $ 299.99 • Total  $6380.89
