  1. Your first block-diagram (soil association) project

  2. From your syllabus: GEO 408 students will do research and write a report on two soil landscapes (aka soil associations), using NRCS Soil Survey data as their main source of information. Each project is an application of the skills learned in class, to a soil landscape. Each report will center on a major soil association, initially depicted in a county soil survey but much expanded upon in the report. YOU choose the soil association (which cannot be from Michigan), with my guidance and approval.

  3. From the Houghton County NRCS report

  4. Each project must contain at a minimum: 1. a block diagram of the soil association (using the one in the survey is acceptable; drafting a new one or editing an existing one is viewed as a plus). 2. typical profile descriptions and classifications for the major soils of the association, with an explanation of the reasons why the soils have the morphology that they do (why they are different from each other, etc). 3. soil and/or topographic maps (DEMs are OK) of typical landscapes in which this soil association dominates, appropriately annotated and explained. 4. an in-depth discussion of the soil parent materials and their pedogenesis, and how the pedogenic state factors have come together to form this association. See your syllabus for additional, optional components to your report

  5. Trimountain: well drained soils formed in a loamy eolian mantle underlain by gravelly loamy or sandy glacial till on ground moraines and end moraines. TAXONOMIC CLASS: Coarse-loamy, mixed, superactive, frigid Ultic Fragiorthods Oa--0 to 1 inches E--1 to 5 inches; dark reddish gray (5YR 4/2) cobbly fine sandy loam Bhs--5 to 11 inches; dark reddish brown (5YR 3/3) fine sandy loam Bs--11 to 27 inches; reddish brown (5YR 4/4) gravelly fine sandy loam 2E/Bx--27 to 34 inches; reddish brown (5YR 5/3) gravelly loamy sand (E); occupies about 60% of the horizon, surrounding peds of reddish brown (2.5YR 4/4) gravelly fine sandy loam (Bt) 2Btx--34 to 46 inches; reddish brown (5YR 4/4) gravelly loamy sand 2C1--46 to 56 inches; reddish brown (5YR 4/4) gravelly fine sand 3C2--56 to 80 inches; reddish brown (5YR 4/4) extremely gravelly coarse sand Net: very deep, somewhat poorly drained soils formed in modified loamy eolian material and in the underlying gravelly loamy sand or gravelly sandy loam glacial till on ground moraines and end moraines. TAXONOMIC CLASS: Coarse-loamy, mixed, superactive, frigid Typic Fragiaquods A--0 to 3 inches; very dark brown (10YR 2/2) stony silt loam E--3 to 6 inches; brown (7.5YR 5/2) gravelly silt loam Bhs--6 to 7 inches; dark reddish brown (5YR 3/3) gravelly loam Bs1--7 to 15 inches; brown (7.5YR 4/4) gravelly silt loam 2Bs--15 to 23 inches; brown (10YR 4/3) gravelly fine sandy loam 2Bx--23 to 39 inches; dark grayish brown (2.5Y 4/2) gravelly sandy loam 2C--39 to 60 inches; dark grayish brown (2.5Y 4/2) gravelly sandy loam

  6. Witbeck: very deep, poorly drained soils formed in loamy deposits on ground moraines and end moraines. TAXONOMIC CLASS: Coarse-loamy, mixed, semiactive, nonacid, frigid Histic Humaquepts Oa--0 to 6 inches; black (5YR 2/1) muck A--6 to 10 inches; black (10YR 2/1) silt loam Bg--10 to 22 inches; gray (5Y 5/1) fine sandy loam Cg1--22 to 30 inches; dark gray (5Y 4/1) very fine sandy loam Cg2--30 to 39 inches; brown (10YR 5/3) very fine sandy loam Cg3--39 to 60 inches; dark gray (N 4/0) gravelly fine sandy loam Paavola: moderately well drained soils formed in gravelly or cobbly, sandy, wave washed glacial drift underlain by gravelly loamy or sandy till on ground moraines, end moraines, and till floored lake plains. TAXONOMIC CLASS: Sandy-skeletal, mixed, frigid Alfic Oxyaquic Fragiorthods Oe--0 to 2 inches; moderately decomposed hardwood and coniferous leaf litter A--2 to 6 inches; dark reddish brown (5YR 2/2) gravelly coarse sandy loam Bhs--6 to 15 inches; dark reddish brown (5YR 3/3) extremely gravelly loamy coarse sand Bs1--15 to 21 inches; dark reddish brown (5YR 3/4) extremely gravelly coarse sand Bs2--21 to 31 inches; brown (7.5YR 4/4) extremely gravelly coarse sand 2(E/B)x--31 to 38 inches; dark reddish gray (5YR 4/2) gravelly loamy fine sand (E); occupies about 60% of the horizon surrounding peds of reddish brown (5YR 4/4) gravelly fine sandy loam (Bt) 2Btx--38 to 59 inches; reddish brown (5YR 4/4) gravelly sandy loam 2Cd--59 to 72 inches; reddish brown (5YR 4/4) very gravelly sandy loam

  7. Due date: Nov 8th at 5:00 pm This gives you two weeks to complete the project. • Other information: • Many paper surveys are in the soils lab. PLEASE RETURN them if you use one of these for your project. • You can also find block diagrams by using the NRCS block diagram web site. • I will look at and edit one draft of your project. Paper or digital – either is fine. • I will answer questions and try to help, in my office, at any time.
