Presentation Transcript


  1. Hydrography Event Management Tools Dana Baker Tim Smith

  2. HEM Overview Event Data Tools Application Integration What’s Next? Overview Geospatial 2007 Conference

  3. What are the HEM Tools? ArcGIS tools for the creation, management, and refresh of event data that is referenced to stream data in the NHD format Developed by the Pacific Northwest Hydrography Framework Adapted from the Forest Service EventMaker Tools Geospatial 2007 Conference

  4. HEM History • PNWHF Partners begin planning for an LLID to NHD transition. Event editing tools recognized as a need for partners. (Late 2005) • Requirements Gathering Phase (Late 2005 – Spring 2006) • Application Development Phase (June 2006 – April 2007) • Additional requirements accepted from NHD Partners (Oct 2006) • Tools released for User Acceptance Testing (March 2007) • First Release of Tools (April 2007) Geospatial 2007 Conference

  5. Overview HEM Overview Event Data Tools Application Integration What’s Next? Geospatial 2007 Conference

  6. What are Events? “Event tables contain information about assets, conditions, and events that can be located along route features. Each row in the event table references an event and its location is expressed as measurements along named linear features.” ESRI, ArcGIS Desktop Help Geospatial 2007 Conference

  7. HEM Event Featureclasses Featureclasses with geometry Records contain route and measure attributes Linear events can span multiple routes (Multi-Route Linear Events) Traditional event tables can be generated from the HEM Event Featureclasses Geospatial 2007 Conference

  8. Point Events Data Structure Geospatial 2007 Conference

  9. Linear Events Data Structure – Single Route Events Geospatial 2007 Conference

  10. Linear Events Data Structure – Multi Route Events * ID links to the “M” table

  11. Linear Events Data Structure – Multi Route “M” Table * ID links to the event featureclass Geospatial 2007 Conference

  12. Additional NHD Data Elements * ID links to the event featureclass Geospatial 2007 Conference

  13. Overview • HEM Overview • Event Data • Tools • Application Integration • What’s Next? Geospatial 2007 Conference

  14. The Tools • Managing Data - ArcCatalog Tools • Editing Data - ArcMap Tools Geospatial 2007 Conference

  15. ArcCatalog: Event Table Manager { Event featureclasses in the selected geodatabase { Interface for creating new event featureclasses Geospatial 2007 Conference

  16. ArcMap: HEM Toolbar • Selection Tool • Sketch Tool • Edit Tasks • Edit Targets • Edit Tools Geospatial 2007 Conference

  17. Create Events • Activate HEM Sketch Tool • Set Edit Task • Create Point • Create Line • Set Edit Target • Click on stream to define endpoint(s) Click for downstream point, then shift + click for upstream point Geospatial 2007 Conference

  18. Mouse Information Current route location displayed in the lower left-hand corner of the ArcMap window Geospatial 2007 Conference

  19. Update Events • Set Edit Task • Update Point • Update Line • Activate Select Event Tool • Select Event to Update • Define new endpoint(s) Click for downstream point, then shift + click for upstream point Geospatial 2007 Conference

  20. Copy Events • Set Edit Task • Set Edit Target • Activate Select Event Tool • Select an Existing Event • Event record is copied Identify results after an existing record is copied. Geospatial 2007 Conference

  21. Delete Events • Set Edit Task • Activate Select Event Tool • Select an Existing Event • Selected event record is deleted

  22. Create Multiple Events Upstream • Set Edit Task • Set Edit Target • Activate HEM Sketch Tool • Click at a Point on a Stream • Events will be created from that point upstream

  23. Create Multiple Events Downstream • Set Edit Task • Set Edit Target • Activate HEM Sketch Tool • Click at a Point on a Stream • Events will be created from that point downstream to the pour point

  24. Measure Tools • Measure Linear Distance • Measures the distance along the flowline between two points. • Optionally converts results to a new linear event • Go X Distance • Displays a graphic a user defined distance up or downstream from a user defined point. • Optionally converts results to a new point event Geospatial 2007 Conference

  25. Synchronize Events • Can be run on one or more event featureclasses • Works off of the selected set of records • Compares ReachSMDate • Opens a user interface to facilitate update • Update: Auto-Match or Manual Edit

  26. Check Continuous Events • Checks events for gaps and overlaps between records • Provides an output report Geospatial 2007 Conference

  27. Additional Edit Tools • Clear HEM Elements • Snap Environment • Select by Selected • Import Points Geospatial 2007 Conference

  28. Overview • HEM Overview • Event Data • Tools • Application Integration • What’s Next? Geospatial 2007 Conference

  29. HEM Integration: Scenario #1 Side-by-Side Toolbars • HEM Toolbar for spatial edits • ARIMS Toolbar for BLM OR/WA ARIMS specific functions Geospatial 2007 Conference

  30. HEM Integration: Scenario #2 • Activate HEM Tools Programmatically • Example #1 – Activate HEM Sketch Tool, Change Edit Task & Target Geospatial 2007 Conference

  31. HEM Integration: Scenario #2 • Activate HEM Tools Programmatically • Example #2 - Launch Synchronize Events Geospatial 2007 Conference

  32. Overview • HEM Overview • Event Data • Tools • Application Integration • What’s Next? Geospatial 2007 Conference

  33. What’s Next? • Tools released for ArcGIS 9.2/.NET Framework 2.0 • July 2007 – Gather New Requirements from NHD Partners Geospatial 2007 Conference

  34. For More Information… http://hydro.reo.gov/redesign Bill Kaiser Project Manager USFS wkaiser@fs.fed.us Dan Wickwire Project Manager US DOI - BLM dan_wickwire@blm.gov Dana Baker Application Developer Northrop Grumman dana_baker@blm.gov Tim Smith Application Developer Northrop Grumman t1smith@blm.gov
