Robot Operation

This document provides a comprehensive overview of our robot's operational components, including the flipping arm, sweeper bar, lift system, and drive system. Designed to meet maximum dimensions of 10" height, 12" length, and 8" width, the robot efficiently maximizes ball collection. The sweeper bar functions like a vacuum beater to push balls up a ramp and into a basket. The lift system, featuring two scissor lifts, elevates the basket for dumping, while the drive system incorporates caster front wheels and motor-driven hub wheels for directional movement. Programmed for optimal performance, it features push-button controls for seamless operation.

basil-fry
Télécharger la présentation

Robot Operation

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. By Joseph Repa Robot Operation

  2. Overview: • flipping arm • sweeper bar • lift system • Drive system • Program

  3. flipping arm • our robot was built to fit the maximum dimensions 10 in. as the height with 12 in as the length and 8 as the with. This was to maximize the amount of space and how many balls we could pick up.

  4. sweeper bar • much like the beater bar of a vacuum, was used to push the golf balls up a ramp and into the basket.

  5. lift system • attached to the basket to dump the golf balls this was comprised of two scissor lifts one on both sides of the robot. The mechanism was raised by rubber band compression causing the arms of the scissor lift to come together. Thus, raising the basket to the correct dumping height.

  6. Drive system • Drive system and chassis was comprised of two caster wheels in the front and two hub wheels with rubber tires in the back. The hub wheels were connected to motors to control the directional movement of the robot.

  7. Program • Push button start, drive forward, pick up two balls, turn around, back up, and dump.
