  1. Liquid Crystal Display Felix Erlacher Sang Hun Lee

  2. Inhalt • Aufbau • Physikalische Grundlagen • Serial PeripheralInterface • Beispiele zur Programmierung

  3. Aufbau TwistedNematic TFT

  4. Aufbau eines Bildes

  5. Physikalische Grundlagen • Polarisation des Lichts • Funktion der Flüssigkristalle • Spannung an den Flüssigkristallen

  6. Polarisation des Lichts • Transversalwelle • Nicht an Medium gebunden • Spektrum

  7. Lineare Polarisationsfilter • VertikalerAnteilkommtdurch • HorizontaleAnteilewerdenabsorbiert und reflektiert

  8. Flüssigkristalle • Klärpunkt - Übergang Mesophasen • Nematische Phase in die isotrope Phase

  9. Doppelbrechung • Senkrecht zueinander polarisiert • Ausbreitungsgeschwindigkeit außerordentlicher Strahl von Eintrittsrichtung auf Moleküle abhängig • Nach Addition entsteht elliptische Welle

  10. Flüssigkristalle Licht

  11. TwistedNematic Crystal

  12. TwistedNematic Crystal

  13. Dünnschichttransistoren TFT • Transistor wird direkt auf Glassubstrat aufgedampft

  14. Serial Peripheral Interface • Synchroner serieller Datenbus • Master-Slave-Prinzip • Sehr lockerer Standard

  15. Eigenschaften • Eine oder mehrere low aktive Chip-Select-LeitungenSS – Slave Select

  16. Eigenschaften • Vollduplexfähig • Viele Einstellmöglichkeiten • Taktflanke • Wortlänge • MSB oder LSB zuerst • Taktfrequenzen bis in MHz-Bereich

  17. Protokollablauf • Jede Taktperiode ein Bit • Beliebig viele Slaves, ein Master • Kein festgelegtes Protokoll • Praxis 4 Modi durchgesetzt

  18. Protokollablauf

  19. Pin-Belegung vom Display und Verbindung mit dem Mbed Serial 2.2" TFT LCD Screen Module NOKIA 6100

  20. Beispiel

  21. Beispiel • #include "mbed.h"#include "NokiaLCD.h" NokiaLCDlcd(p5, p7, p8, p9, NokiaLCD::LCD6610); intmain() {lcd.background(0x0000FF);lcd.cls();lcd.fill(2, 51, 128, 10, 0x00FF00);lcd.fill(50, 1, 10, 128, 0xFF0000);lcd.locate(0,3);lcd.printf("Hello World!");for(int i=0; i<130; i++) {lcd.pixel(i, 80 + sin((float)i / 5.0)*10, 0x000000);}}

  22. Code NokiaLCD.h • NokiaLCDlcd(p5, p7, p8, p9, NokiaLCD::LCD6610);NokiaLCD::NokiaLCD(PinNamemosi, PinNamesclk, PinNamecs, PinNamerst, LCDType type) : _spi(mosi, NC, sclk) , _rst(rst) , _cs(cs)

  23. Code NokiaLCD.h • #defineNOKIALCD_ROWS 16 #define NOKIALCD_COLS 16#define NOKIALCD_WIDTH 130 #define NOKIALCD_HEIGHT 130 #define NOKIALCD_FREQUENCY 5000000 • Lcd.background(0x…..)void NokiaLCD::background(int c) {_background = c;}

  24. Code NokiaLCD.h • lcd.fill(int x, int y, intwidth, intheight, intcolour) _cs = 0;_window(x, y, width, height);for (int i=0; i<width*height/2; i++) { int r4 = (colour >> (16 + 4)) & 0xF; int g4 = (colour >> (8 + 4)) & 0xF; int b4 = (colour >> (0 + 4)) & 0xF; int d1 = (r4 << 4) | g4; int d2 = (b4 << 4) | r4; int d3 = (g4 << 4) | b4; 00330 data(d1);data(d2);data(d3);}_cs = 1;

  25. Code NokiaLCD.h • lcd.locate(0,3);voidNokiaLCD::locate(intcolumn, introw) { _column= column;_row = row; } • for (int i=0; i<130; i++) {lcd.pixel(i, 80 + sin((float)i / 5.0)*10, 0x000000);}voidNokiaLCD::pixel(int x, int y, intcolour) {_cs = 0; _window(x, y, 1, 1); _putp(colour); _cs = 1;}

  26. Vielen Dank für eure Aufmerksamkeit!
