  1. Chapter 9 Logic Families and Their Characteristics 1

  2. Objectives You should be able to: • Analyze internal circuitry of a TTL NAND gate for both HIGH and LOW output states. • Determine IC input and output voltage and current ratings from the manufacturer’s data manual. • Explain gate loading, fan-out, noise margin, and time parameters. 2

  3. Objectives (Continued) • Design wired-output circuits using open-collector TTL gates. • Discuss the differences and proper use of the various subfamilies within both TTL and CMOS ICs. • Describe the reasoning and various techniques for interfacing between the TTL, CMOS, and ECL families of ICs. 3

  4. The TTL Family • Bipolar transistors • Physical model • Symbol • Diode equivalent 4

  5. The TTL Family • Two-input NAND gate • Multi-emitter transistor • Totem-pole output stage • HIGH level output typically 3.4 V • LOW level output typically 0.3 V 5

  6. The TTL Family • 7400 two-input NAND gate 6

  7. TTL Voltage and Current Ratings • Input/output current and fan-out • Source current – IOH • Sink current – IOL • Low-level input current – IIL • High level input current – IIH 7

  8. TTL Voltage and Current Ratings • Example of TTL gate sinking input currents from two gate inputs using logic symbols 8

  9. TTL Voltage and Current Ratings • Example of TTL gate sinking input currents from two gate inputs using schematic symbols 9

  10. TTL Voltage and Current Ratings • Example of TTL gate sourcing current to two gate inputs using logic symbols 10

  11. TTL Voltage and Current Ratings • Example of TTL gate sourcing current to two gate inputs using schematic symbols 11

  12. TTL Voltage and Current Ratings • Summary of I/O current and fan-out: • Low-level input current IIL = 1.6 mA (-1600 μA) • High level input current IIH= 40 μA • (The minus sign indicates current leaving the gate) • IOL– low-level output current = 16 mA (16,000 μA) • IOH – high-level output current = -400 μA (-800 μA for some) • (Max capability of a gate to sink or source current) • Fan-out is max number of gate inputs that can be connected to a standard ttl gate output. • Typically fan-out = 10. 12

  13. TTL Voltage and Current Ratings • Input/Output Voltages and Noise Margin • Noise margin: The difference between high level voltages and low level voltages 13

  14. TTL Voltage and Current Ratings • Input/Output Voltages and Noise Margin (graphical representation) 14

  15. Discussion Point • Locate the voltage and current ratings covered so far on the typical data sheet given in Figure 9-8. 16

  16. 17

  17. 18

  18. 19

  19. Other TTL Considerations • Pulse-Time Parameters • Rise Time – Measured from 10% level to 90% level 20

  20. Other TTL Considerations • Pulse-Time Parameters • Fall Time – Measured from 90% level to 10% level 21

  21. Other TTL Considerations • Pulse-Time Parameters • Propagation Delay (tPLH and tPHL) 22

  22. Other TTL Considerations • Power dissipation • Total power supplied to the IC power terminals • Open-collector outputs • Upper transistor removed from totem-pole • Can sink current • Can not source current • Pull-up resistor used 23

  23. Other TTL Considerations • Wired-output operation • Outputs from two or more gates tied together • Wired-AND logic 24

  24. Figure 9–16 Wired-ANDing of open-collector gates for Example 9–4: (a) original circuit and (b) alternative gate representations used for clarity.

  25. Figure 9–13 (continued) TTL NAND with an open-collector output: (a) circuitry; (b) truth table.

  26. Figure 9–13 TTL NAND with an open-collector output: (a) circuitry; (b) truth table.

  27. Figure 9–14 Using a pull-up resistor with an open-collector output. (a) Adding a pull-up resistor to a NAND gate. (b) When Q4 inside the NAND is on, Vout ≈ 0 V. (c) When Q4 is off, the pull-up resistor provides ≈ 5 V to Vout.

  28. Other TTL Considerations • Disposition of unused inputs and unused gates • Open inputs degrade noise immunity • On AND and NAND – tied HIGH • On OR and NOR – tied LOW • Unused gates – force outputs HIGH 25

  29. Other TTL Considerations • Power supply decoupling • Connecing 0.01 to 0.1 F capacitor between VCC and ground pins • Reduces EMI radiation • Reduces effect of voltage spikes from power supply 26

  30. Improved TTL Series • 74HXX series • Half the propagation delay • Double the power consumption • Schottky TTL • Low-power (LS) • Advanced low-power (ALS) • 74FXX • Reduced propagation delay 27

  31. Figure 9–17 Schottky-clamped transistor: (a) Schottky diode reduces stored charges and (b) symbol.

  32. The CMOS Family • MOSFETs • Metal oxide semiconductor field-effect transistors • PMOS and NMOS type substrates 28

  33. The CMOS Family • MOSFETs • Higher packing densities than TTL • Millions of memory cells per chip • See Table 9-2 in your text 29

  34. Table 9–2 Basic MOSFET switching characteristics.

  35. Figure 9–19 CMOS inverter formed from complementary N-channel/P-channel transistors.

  36. The CMOS Family • Handling CMOS devices • Avoid electrostatic discharge • CMOS availability • 4000 series - original CMOS line • 40H00 series - faster • 74C00 series - pin compatible with TTL • 74HC00 and 74HCT00 series • Speedy, less power, pin compatible, greater noise immunity and temperature operating range 30

  37. Figure 9–21 Wearing a commercially available wrist strap dissipates static charges from the technician’s body to a ground connection while handling CMOS ICs.

  38. The CMOS Family • CMOS availability • 74- biCMOS series - low power and high speed • 74-low voltage series • See appendix B • Nominal supply voltage of 3.3 V • 74AHC and 74AHCT series • Superior speed • Low power consumption • High output drive current 31

  39. The CMOS Family • 74AVC advanced very-low-voltage CMOS logic • Faster speed • Very low operating voltages • 3.3 V, 2.5 V, 1.8 V, 1.5 V and 1.2 V 32

  40. Emitter-Coupled Logic • Extremely fast • Increased power dissipation • Uses differential amplifiers Figure 9-22 33

  41. Emitter-Coupled Logic • Newer technologies • Integrated injection logic (I2L) • Silicon-on-sapphire (SOS) • Gallium arsenide (GaAs) • Josephson junction circuits 34

  42. Comparing Logic Families • Performance specifications 35

  43. Comparing Logic Families • Propagation delay versus power 36

  44. Comparing Logic Families • Power supply current versus frequency 37

  45. Interfacing Logic Families • TTL to CMOS 38

  46. Interfacing Logic Families • TTL to CMOS • Pull-up resistor 39

  47. Interfacing Logic Families • CMOS to TTL 40

  48. Interfacing Logic Families • CMOS to TTL 41

  49. Interfacing Logic Families • Worse-case values • See Table 9-4 in your text. 42

  50. Interfacing Logic Families • Level Shifting • Level-shifter ICs: 4049B and 4050B 43
