side view

Dissection of the Fetal Pig ( Sus scrofa ). place where latex paint was injected into the jugular vein and the carotid artery. side view. 1.umbilical cord- Connection to placenta. peritoneum/umb arts/liver. 2.liver-produces bile, etc. peritoneum (smooth inner lining of abdominal cavity).

coty
Télécharger la présentation

side view

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Dissection of the Fetal Pig (Sus scrofa) place where latex paint was injected into the jugular vein and the carotid artery side view 1.umbilical cord- Connection to placenta

  2. peritoneum/umb arts/liver 2.liver-produces bile, etc peritoneum (smooth inner lining of abdominal cavity) umbilical arteries

  3. liver/spleen/stomach separate lobes of the liver stomach 3. spleen- Breaks down old rbc’s

  4. intestine sm/lge 5. large intestine- Re-absorbs water and compacts feces 4. small intestine- Digests and absorbs nutrients

  5. gall bladder 6. gall bladder- Stores bile (fat detergent) bile duct (to duodenum)

  6. bile duct (closeup) gall bladder bile duct

  7. stomach/duodenum/spleen 7.stomach- Begins protein digestion spleen duodenum

  8. pyloric sphincter/bile duct bile duct (to duodenum) 8. pyloric sphincter (=valve) Controls flow of chime into duodenum 9. Pancreas- Secretes enzymes And makes insulin

  9. pancreas duodenum stomach pancreas spleen

  10. rectum 10. rectum– Feces stored before being expelled

  11. abdominal aorta (zoom) 12. inferior vena cava- Returns blood to heart from lower extremities 11. aorta- Biggest artery of body

  12. kidneys 13. kidneys- Filter wastes (urea) from blood ureter (tube to urinary bladder)

  13. diaphragm 14. Diaphragm- Separates chest cavity from abdomen. Main muscle of respiration.

  14. larynx larynx trachea (=windpipe)

  15. trachea 16. trachea- “windpipe” Allows O2 and CO2 to move from throat to lungs

  16. lungs 17. lungs- Bring oxygen into bloodstream, Excrete CO2 into air right lung left lung

  17. pericardial sac 18. heart- Pumps blood through blood vessels pericardial sac (encloses the heart)

  18. heart ventricles 20. left ventricle (pumps blood to the entire body – except the lungs) 19. right ventricle (pumps blood to lungs)

  19. right atrium 21. right atrium (receives de-oxygenated blood from the body)

  20. left atrium 22. left atrium (receives oxygenated blood from the lungs)

  21. pulmonary artery right atrium left atrium 23. pulmonary artery (sends de-oxygenated blood to the lungs)

  22. aorta right lung pulmonary artery coronary artery 24. aorta (sends oxygenated blood to the entire body under high pressure)
