Presentation Transcript

  1. 2. CL TOTALCRYPT UE • Ultimate security level • Government systems • Security agencies • Intelligence agencies • Special users • Defense

  2. 3. CL TOTALCRYPT+ • Advanced security level • Bank systems • Stock exchange • Hi-tech business • Municipality • Police

  3. 4. CL TOTALCRYPT • Standard security level • Personal use • Working groups • Social networks • Small and medium size business

  4. 5. CL FINANCIAL APPLICATIONS • Database • Remote personnal banking • Remote corporative banking • Interbank communication • Automatic teller machines (ATM) • Credit card reader (POS-EFT) • Stock – broker communication • Broker – investor communication

  5. 6. CL COMPUTER APPLICATIONS • Cloud computing • File encryption • Protocol encryption • Folder encryption • USB flash encryption • Hard drive encryption • Optical drive encryption • Encryption processors

  6. 7. CIFF APPLICATIONS WORLDWIDE • Raw & JPEG camera transcoding • MPEG-2 & Mini DV transcoding • Faster satellite transmission • Faster editing / postprocessing • 3D & UDTV Cable & Mobile TV • Low-cost video encoders • Low-cost set-top boxes • EDTV, UDTV, HDTV & SDTV now! • True low-cost IPTV

  7. 8. CIFF + CL VIDEO APPLICATIONS • Internet image and video delivery • IPTV • Cable TV • Satellite TV • Digital terrestrial TV • Video editing / postprocessing • Movie edit master & archive • Mobile TV (4G, 3G) • Personal video recorder

  8. 9. CIFF + CL MEDICAL APPLICATIONS • MAMMOGRAPHY • COMPUTERIZED TOMOGRAPHY • MAGNETIC RESONANCE IMAGING • ULTRASONOGRAPHY • X-RADIOGRAPHY • TELEMEDICINE • Mammography • Computerized tomography • Magnetic resonance imaging • Ultrasonography • X-Radiography • Telemedicine

  9. 10. CIFF + CL DEFENSE APPLICATIONS • Unmanned & manned vehicles • Warfighters • Satellites • Surveillance • Telemedicine • Smart weapons • Loitering weapons • Face recognition for laser-guided bullets • EO, IR, SAR & Hyperspectral sensors

  10. FAST PROCESSING HIGH ERROR RESILIENCE LOW LATENCY SMALL WEIGHT & SIZE LOW POWER & HEAT INTEROPERABILITY 11. CIFF + CL UAS NETWORK UAV CIFF ENCODER CL CIPHER EO IR SAR NETWORK UDP LINK PC PDA GROUND STATION DECIPHER CL + CIFF DECODER DECIPHER CL + CIFFDECODER STORAGE DECIPHER CL + CIFF DECODER VIDEO PLAYER VIDEO PLAYER VIDEO PLAYER

  11. 12. DISTRIBUTION OF DIFFERENT RESOLUTIONS WITH DIFFERENT KEYS KEY 1 HDTV 1920x1080 KEY 5 ¼ QCIF 120x68 KEY 4 QCIF 240x135 KEY 3 CIF 480x270 KEY 2 SD 960x540

  12. 13. CIFF + CL WIRELESS HDMI NET DVR FUNCTION ON THE ROAD

  13. 14. CIFF + CL HDMI CONNECTION HDMI HDMI HDMI CL Tx HDMI CL Rx HDMI CL Rx HDMI CL Tx INSTEAD OF CLASSIC WIRED HDMI CRYPTO LOGICA P2P WIRELESS HDMI LINK CRYPTO LOGICA ROUTED WIRELESS HDMI LINK

  14. 15. CIFF + CL HDMI NODE TRANSMIT CL Node RECEIVE CL Node HDMI Rx CIFF Video Encoder CL cipher 802.11g 802.11g CL decipher CIFF Video Decoder HDMI Tx • Wireless HDMI IEEE802.11g/n • Wired HDMI 10/100/1000 Base-T • Transmitter powered by HDMI out port • Receiver powered by HDMI in port • CRYPTO LOGICA 4096-bit encryption • Single chip without external memory

  15. 16. CIFF + CL HARDWARE • Lowest cost • No dividers • No multipliers • Ultralow power • Integer arithmetic • Very low complexity • Small integrated memory • Ultrafast encryption and compression • Easy radiation hardening

  16. 17. TWO POSSIBLE CIFF + CL DELIVERYSYSTEM ARCHITECTURES Fixed bandwidth (Fiber optic, ADSL2, wireless, satellite) VIDEO SERVER W CIFF VIDEO SET-TOP BOX / CIFF DECODER Dynamic bandwidth (Fiber optic, ADSL2, wireless) VIDEO SERVER W CIFF VIDEO CIFF DECODER ENCODER SET-TOP BOX / CIFF DECODER

  17. 18. FIBER-OPTIC & ADSL2+ PROBLEMS • Video server typically utilizes fixed bandwidth and quality for near and far homes. HOME CLOSE TO SERVER HOME FAR FROM SERVER

  18. 19. CIFF HELPS FIBER OPTIC & ADSL2 • Video server with CIFF can vary bandwidth and quality for near and far homes. HOME CLOSE TO SERVER HOME FAR FROM SERVER

  19. 20. CIFF PROVIDES HIGHER AVERAGE BANDWIDTH FOR ALL HOMES CIFF H.264, MPEG-2, VC1

  20. SDTV SDTV HDTV HDTV 21. CIFF PROVIDES DYNAMIC ALLOCATION OF BANDWIDTHFOR HDTV, SDTV, INTERNET CIFF HDTV ONLY CIFF HDTV+2xSDTV
