  1. M5 Multibanked Cache Jiayuan Meng jm6dg@virginia.edu

  2. Behavior • A bank accommodates several sets, but a set cannot spread across several banks • Requests can be responded in parallel as long as they are for different banks • Requests to the same bank are queued and served in FIFO order • A new requests are rejected if its corresponding bank has its queue full.

  3. Parameters • numBanks: # of banks a cache has • maxBankPendReqs: # of packets each bank can queue • propagateLatency: time to distribute a packet to a bank • lookupLatency: time to lookup a block within a bank

  4. Parameters The MultiBanks class is a derivative of one of the existing Tag classes: • template <class Repl = LRU> • class MultiBanks : public Repl • { • CacheBank *banks; • // modified interface for latency modeling • BlkType* findBlock(Addr addr, int &lat); • // perserved interface • BlkType* findReplacement(Addr addr, PacketList &writebacks); • BlkType* findBlock(Addr addr) const; • }

  5. Latency Modeling MultiBanks<Repl>::findBlock(Addr addr, int &lat) { unsigned bank = extractBank(addr); // calculate the latency that the request reaches the bank lat = banks[bank].accessBlk(propagateLatency); // see next slide // adding the latency that the request lookup within the bank Repl::hitLatency = lat + lookupLatency; // Repl::findBlock will use existing modules to find the block // and further adjust the latency according to block.whenReady BlkType *blk = Repl::findBlock(addr, lat); return blk; }

  6. Bank Queuing/pipeline Modeling int CacheBank::accessBlk(int propagateLatency) { // delete requests that are already processed up to now updateOccupants(); // calculate the time when the request is propagated to the bank int lat = propagateLatency; Tick time = curTick + lat; // take into account the queueing latency // queueLatency can be less than lookupLatency to model pipelining int n=occupants.size(); // # of waiting requests for this bank if(n>0){ // calculate when the incoming request reaches the head of the queue Tick nextIdle = occupants[n-1]+queueLatency; if(time < nextIdle){ time = nextIdle; lat = time - curTick; } } // record this future request’s process time in the occupant list occupants.push_back(time); return lat; }

  7. Bank Conflict bool Cache<TagStore>::CpuSidePort::recvTiming(PacketPtr pkt) { if (pkt->isRequest() && !pkt->memInhibitAsserted() && (blocked || !myCache()->accept(pkt) ) ) …(reject the request and retry later) … } Cache::accept(pkt)callsBaseTags::accept(pkt),and if it is a multibanked cache: MultiBanks<Repl>::accept(Addr addr) { unsigned bank = extractBank(addr); return banks[bank].tryAccept(); } bool CacheBank::tryAccept() { updateOccupants(); // erase requests that are already processed if( numOccupants()>=maxPendReqs ) return false; // reject if the per-bank queue is full already return true; }
