1. Unique compact design, minimal product size can carry multi-channel current and control signal
2. Gold to Gold contact, excellent digital transmission performance and high working life;
3. In a very compact volume integrated multi-channel fiber and signal, current, to solve the complex system structure needs;
4. The optical fiber and 12-channel control signal transmission is integrated in the minimum volume, which is suitable for precision design of high performance products;
5. Super-thick electroplated layer ensures clear and stable video.

#Signal Slip Ring #ct slip ring #Digital Slip Ring
CCTV Slip Ring - slide 1
01 / 8CCTV Slip Ring
1 / 17

Télécharger la présentation

CCTV Slip Ring
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. JNPAT Production Line www.slipring.cn • Strict quality management system • Good supply chain management • Adopt advanced ERP system • Research staff: 15%, salesperson: 8.5%, quality personnel: 9%

  2. Rotating Speed: 1-10,000 rpm Performance Index www.slipring.cn Temperature: -30℃~+60℃ Warranty: 3 years Operation Lifetime: ≥8 million revolutions (standard product) Ultra-low contact resistance and electrical noise Transmission of various signals (HDMI, Data bus, RS, etc.)

  3. Quality Assurance www.slipring.cn • Strict inspection procedures (incoming inspection, production process inspection, finished product inspection, preshipment inspection) ensures high quality. • Performance tests of electricity, load, video and simulation. • Reliability testing

  4. Product Advantages www.slipring.cn Compact design, low torque Gold to Gold contact All-around technical support 4. Super-thick electroplated layer ensures clear and stable video

  5. LPC Capsule Slip Ring www.slipring.cn • Specifications • Circuits: 1-125 • Rotating Speed: 0-300rpm • Current Rating: 2A per circuit or higher • Contact Material: Gold to Gold • Torque: ≤0.88g·m (for reference) • OD for LPC Series: 22mm or larger • Features • Precious metal contact makes the lifetime over-long • Gold-Gold contact ensures low resistance • Compatible with data bus protocols • Operating smoothly and reliability • Low torque • Compact design • Specific customization design
