  1. Tutorial 8: Add a Wale Beam Deep Excavation LLC DeepXcav 2011 – Advanced course 1

  2. INTRODUCTION DeepXcav is a software program for braced excavations in soils with 2D limit-equilibrium and non-linear analysis methods, and structural verification of all elements (with AISC, ASD, Eurocodes). It offers the ability to analyze walls with multiple braces (tiebacks) in multilayered soils. The non-linear analysis considers elastoplastic behavior for the whole soil-wall-support system. The program also offers the ability to perform traditional limit-equilibrium analyses. The graphical interface is completely interactive and the input is simplified to a great extend. The program utilizes archives of wall types, structural and soil materials, ground anchors etc. The analysis can be performed in either an utlimate state or at a service state (allowable design or LRFD). The program offers the ability to automatically set all critical settings according to the desired design methodology. The program also offers the ability to perform slope stability analyses with soil nails. Corso Paratie, Milano 30 settembre 2009 DeepXcav 2011 – Advanced course 2

  3. Change the Surface Level to 100 m Go to the General Tab and press the Move Model Elevation button Change the Elevation to 100 m and select All Boreholes Press Ok DeepXcav 2011 – Advanced course

  4. Edit Wall Properties Double-click on the wall Change Wall Depth to 16m Press Ok DeepXcav 2011 – Advanced course

  5. Add a new Stage and excavate 3m Go to the Model Tab Click to Add a new Stage Change right Elevation to 97m DeepXcav 2011 – Advanced course

  6. Add a new Stage and add a tieback Click to Add a new Stage Click on the wall and on the soil to add the tieback Select the Add a tieback tool DeepXcav 2011 – Advanced course

  7. Edit Support Data Change tieback elevation to 97.5m Change tieback angle to 20 deg Press Ok DeepXcav 2011 – Advanced course

  8. Add a Wale Beam Click to add a Wale Beam Go to the Loads/supports Tab Click o the support DeepXcav 2011 – Advanced course

  9. Edit Waler Data Click to Edit the Wale Section DeepXcav 2011 – Advanced course

  10. Edit Wale Section Data Specify the clearance between the Beams Select to Auto Rotate the Wale Section Select a Section Select to use Multiple Beams Specify the number of Beams Press Ok DeepXcav 2011 – Advanced course

  11. Choose the Loading Type Choose the Vertical Spacing Choose the Axial Force Press Ok DeepXcav 2011 – Advanced course

  12. Add a new Stage and Excavate 4m Change right Elevation to 94m Click to add a new Stage Change Water Elevation to 94m

  13. Calculate the Design Section Press the Calculate the selected Design Section button

  14. Wale Beam Results Go to the Results and Results for all stages Tabs Double-click on the Waler Click Ok

  15. Add a new Design Section Click to add a new Design Section

  16. Change the Wale Section Click to Edit the Wale Section Double-click to Edit the Wale Data DeepXcav 2011 – Advanced course

  17. Add a concrete Section Select to use a concrete Section Select a Section Add reinforcement properties Press Ok

  18. Calculate the Design Section Press the Calculate the selected Design Section button

  19. Wale Beam Results Double-click on the Waler Go to the Results and Results for all stages Tabs Click Ok
