  1. Version 2014-02-01 Target 3D About of theimplantlibrary Target 3D in DentalWings Software Target 3D

  2. Implant Kit of Target 3D Library When complete the new worksheet appear this screen: Target 3D

  3. Implant Kit of Target 3DLibrary Opens a dropdown with many options ScanBodySystem D= Scanbody ImplantLevel features of the connection E = Engaging Target 3D System D-1101 = Nobel BiocareReplaceSelect Np Target 3D

  4. Implant Kit of Target 3DLibrary Options Target 3D ScanBodySystem SI= Scanbodyon Interfaces D= ScanbodyDirect ImplantLevel Lookingequivalence list attached Features of the connection E = Engaging NE= Non Engaging Zr= Zirconium A= A type B= B type C= C type S= Short VS= Very Short Target 3D

  5. Implant Kit of Target 3DLibrary Detailed Description Engaging connetion Features of the connection E = Engaging NE= Non Engaging Zr= Zirconium A= A type B= B type C= C type S= Short VS= Very Short Heavy duty design for Zirconium Non Engaging connetion Target 3D

  6. Implant Kit of Target 3DLibrary Detailed Description Connection for correct insertion axis Features of the connection E = Engaging NE= Non Engaging Zr= Zirconium A= A type B= B type C= C type S= Short VS= Very Short Connection for bad insertion axis Connection for very bad insertion axis Target 3D

  7. Implant Kit of Target 3DLibrary Normal Height Detailed Description Features of the connection E = Engaging NE= Non Engaging Zr= Zirconium A= A type B= B type C= C type S= Short VS= Very Short Short Height Very Short height Target 3D

  8. Implant Kit of Target 3DLibrary Job completed Target 3D

  9. ThanksforWatching Target 3DSupport support@target3d.com Target 3D
