1. Performing Arts Centre Presentation Diocesan Performing Arts Centre By Olivia Hyland

2. Task Task • To design a Performing Arts centre for Dio and use Google Sketchup to model it.

3. Research

4. East Grand Rapids Performing arts Centre The East Grand Rapids Performing Arts Centre As you can see this centre seats many people so it can be used for many different events. The centre has opera house style balconies which reduces the area of land used for the amount of seats and brings the audience closer to the stage. Backstage there is a scene shop, dressing rooms, make-up room, green room and storage under the stage. There is a professional size stage and orchestra pit. This centre however does not have any classrooms.

5. Lake Stevens high school and blue Springs High School Research Blue springs performing arts centre This centre is a lot like what dio would be wanting, it seats 1005 people and has vocal and instrumental classrooms. It also has been put into an already complex area. The stage has a flying loft stage, 40ft proscenium, 40 channel sound system and other features. It is able to have pro tour groups there. Lake Stevens’ performing arts centre It seats 450 people and is used for both community and school purposes. There is a 900 sqft drama classroom that is also used as a green room for productions. There are tablet arms on the chairs so the centre can also be used for testing.

6. Good ideas from these designs and things that will help me • 900 sqft drama classroom also used as a green room • Tablet arms on chairs so centre can be used for testing • 40 channel sound system • Flying loft stage • Opera house style seating • Storage under the stage • Orchestra pit and professional size stage Ideas

7. Dance • 2 dance rooms with wooden floors and mirrors • Small performance area for classes

8. Drama • 2-3 drama rooms double as green room • Storage for props and costumes • Drama block demolished

9. Music • Orchestra pit • Organ • Sound proofing • Choir room with permentalyteared seating • Orchestra room with adjoining percussion

10. The Grand Revealing of the Dio Performing Arts Centre

11. MY TOUR peforming arts building.skb

12. The foyer Level 2 entrance Level 1 entrance

13. The auditorium Wall art Level 2 seating V.i.p box rising seating stage

14. The Classrooms Toilets Teacher area Dance/Drama Dance room with mini stage Dance/Drama/green room

15. Private teaching rooms 15 music rooms

16. Sides, front, back

17. Thanks for Watching
