  1. Chapter 4 Electricity and Power Supplies

  2. You Will Learn… • How electricity is measured • How to protect your computer system against damaging changes in electrical power • About different form factors and computer cases • How to detect and correct power supply problems • About Energy Star specifications

  3. Electricity: Basic Introduction

  4. Measures of Electricity continued… Page 121

  5. Measures of Electricity

  6. Voltage • Measures potential differences • Electrical force created by the potential difference in electron charge flowing between 2 points • Measured in units called volts • Negative to positive flow • Measures when power is on Voltmeter: Page 122

  7. Voltage

  8. Amps • Ampere = unit of measurement for electrical current • Amps remain constant throughout electrical system • Current: volumn of electrons flowing through an electrical system Ammeter

  9. Relationship Between Voltage and Current • Direct relationship • As the electrical potential difference (voltage) increases, the electrical current increases • As the voltage decreases, the current decreases

  10. Ohms • Standard unit of measurement for electrical resistance • Resistors are devices used in electrical circuits to resist the flow of electricity • As resistance decreases, electricity increases Paragraph Page 124

  11. Relationship Among Voltage, Current, and Resistance • Voltage and current have a direct relationship • When voltage increases, current increases • Resistance has an inverse relationship with voltage and current • As resistance increases, either current or voltage decreases • As resistance decreases, either current or voltage increases (Ohm’s Law) V=I/R or Volts = Amps/Ohms • One volt drives a current of one amp through a resistance of one ohm

  12. Wattage • Total amount of power needed to operate an electrical device • Measured in watts • Calculated by multiplying volts by amps in a system (W = V x A)

  13. AC and DC • AC (alternating current) • Means of sending power over extended distances • Cycles back and forth rather than traveling in only one direction • Most economical way to transmit electricity • DC (direct current) • Travels in only one direction • Type of current required by most electronic devices, including computers • Computer power supplies function as both a transformer and a rectifier Device that changes ratio of current to voltage (reduces voltage to a usable level) Device that converts AC to DC

  14. Computer Power Supply Hertz (Hz):

  15. Power Supply Function Rectifier Chapter questions 2-6

  16. Hot, Neutral, and Ground

  17. Hot, Neutral, and Ground • Hot: inbound current • Neutral: outbound current • Ground: protection for neutral line against short circuits • Short circuit • Occurs when electricity is allowed to flow uncontrolled from hot line to neutral line or from hot line to the ground • Fuse • Designed to prevent too much current from flowing through the circuit • Rated in amps Paragraph 127

  18. Hot, Neutral, and Ground 128

  19. Hot, Neutral, and Ground Receptacle tester

  20. Materials Used to Make Electronic Components • Conductors: easily conducts electricity (gold or copper) • Insulators: resists flow of electricity (glass or ceramic) • Semiconductors: falls between conductors & insulators—ability to conduct electricity when charge is applied (silicon) 129

  21. Some Common Electronic Components Device that can hold electrical charge for period of time & smooth the uneven flow through a circuit Device serves as a gate or switch for electrical signal & can amplify the flow 130

  22. Protecting Your Computer System • General safety precautions • Protecting against electricity • Protecting against electrostatic discharge (ESD or static electricity) and electromagnetic interference (EMI) • Surge protection and battery backup

  23. Protecting Against Electricity • When working inside a computer • Turn off the power • Unplug the computer • Use a ground bracelet 131

  24. Static Electricity • Ground yourself and computer parts, using static control devices or methods • Ground bracelet or static strap • Ground mats • Static shielding bags • Caution: Don’t wear a ground bracelet when working inside a monitor or with high-voltage equipment such as a laser printer

  25. Using a Ground Bracelet

  26. Using a Ground Bracelet and a Ground Mat

  27. Using Static Shielding Bags

  28. Electromagnetic Interference • Caused by the magnetic field produced as a side effect when electricity flows • Radio frequency interference (RFI) can cause problems with radio and TV reception • Use a line conditioner to filter electrical noise causing the EMI 135

  29. Surge Protection andBattery Backup • Devices that filter AC input • Surge suppressors (or surge protectors): protect against sudden changes in power level • Power conditioners • Uninterruptible power supply (UPS) • Also provides backup power Alters power to provide continuous voltage Tips on 136

  30. Uninterruptible Power Supply • Benefits • Condition line for brownouts and spikes • Provide backup power during a blackout • Protect against very high spikes that could damage equipment Spikes: temporary voltage surges Brownouts: temporary voltage reductions

  31. Uninterruptible Power Supply

  32. What to Consider WhenBuying a UPS • Cost • Rating should exceed your total VA or wattage output by at least 25% • Degree of line conditioning • Warranty, service policies, and guarantee

  33. UPS Manufacturers 138

  34. Computer Case and Form Factors • Form factor • Describes the size, shape, and general makeup of a hardware component • Must match for motherboard, power supply, and case

  35. AT ATX (most popular) LPX NLX Backplane systems Most common form factors used on PCs: AT Baby AT ATX Mini-ATX Case, Power Supply, and Motherboard Form Factors

  36. AT Form Factor

  37. ATX Form Factor

  38. NLX Form Factor

  39. Types of Cases • Desktop cases • Tower cases • Minitower • Midsize (most popular) • Full-size • Laptop cases

  40. Desktop Cases

  41. Minitower Cases

  42. Tower and Desktop Cases

  43. Case and Power Supply Vendors

  44. Detecting and Correcting Power Supply Problems • Measuring the voltage of a power supply • Upgrading and installing power supplies • Troubleshooting the power system and power supply

  45. Measuring the Voltage of a Power Supply • Use a multimeter • Before using, tell it three things • Whether to measure voltage, current, or resistance • Whether the current is AC or DC • What range of values it should expect • How to measure voltage • How to measure current • How to measure continuity

  46. A Multimeter

  47. How to Measure the Voltage of a Power Supply • How to measure the power output for AT and ATX motherboards • Procedure for a secondary storage device

  48. Measuring Voltage on an AT Motherboard

  49. Measuring Voltage Output to an AT Motherboard

  50. Measuring Voltage Output to an AT Motherboard
