  1. eLSE Builder Asya Stoyanova-Doycheva University of Plovdiv astoyanova@uni-plovdiv.bg

  2. eLSEBuilder Framework • What is eLSEBuilder? • The eLSEBuilder Application is a framework that allows the creation of dynamic and impressive presentations of business process flow and process interoperation simulation • eLSEBuilder consists of three main modules - eLSEBuilder, eLSERuntimeEngine, and eLSEWebApplication

  3. eLSE Web Application HTML Pages eLSEBuilder JScript P-Code Web Templates eLSE Runtime Engine eLSE Framework Presentation Site eLSEBuilder Modules

  4. eLSEBuilder

  5. eLSEBuilder • Start eLSEBuilder

  6. eLSEBuilder Modules eLSE Web Application HTML Pages eLSEBuilder JScript P-Code Web Templates eLSE Runtime Engine eLSE Framework Presentation Site

  7. eLSE Runtime Engine • JavaScript based (about 2600 lines pure JavaScript code) • Interprets the generated p-code in the Presentation Site • Not a tool, but a library of functions in JavaScript • Uses DHTML

  8. eLSEBuilder Modules eLSE Web Application HTML Pages eLSEBuilder JScript P-Code Web Templates eLSE Runtime Engine eLSE Framework Presentation Site

  9. eLSE Web Application • eLSEWebApplication is the tool that the end-user uses to demonstrate the presentation. It is a Web Application that runs in a HTML browser and uses a prepared by eLSEBuilder presentation site. The eLSEWebApplication displays the presentation in several frames, presenting the user a ControlToolbox to choose, start, stop or run step-by-step each of the simulations, included in the Presentation Site. • Start Generated Web Presentation

  10. eLSEBuilder Export/Import Features • Export/Import - eLSEBuilder supports exporting and importing models, scripts, simulations, presentations and even contents of the entire database. The export creates a SiX-file in XML format. Later this file can be imported in the same or even in another database. The import can be merged with the existing items or it can create new ones.
