  1. J1 (male D-68 connector) J2 (Female D-68 connector) DATA_IN47 67 68 GROUND MDP_ANALOG_OUT 67 68 MDP_ANALOG_GND DATA_IN43 65 66 DATA_IN45 DATA_OUT43 65 66 DATA_OUT45 DATA_IN41 63 64 GROUND DATA_OUT41 63 64 GROUND DATA_IN37 61 62 DATA_IN39 DATA_OUT37 61 62 DATA_OUT39 DATA_IN35 59 60 GROUND DATA_OUT35 59 60 GROUND GROUND 57 58 DATA_IN33 GROUND 57 58 DATA_OUT33 DATA_IN29 55 56 DATA_IN31 DATA_OUT29 55 56 DATA_OUT31 GROUND 53 54 DATA_IN27 GROUND 53 54 DATA_OUT27 DATA_IN23 51 52 DATA_IN25 DATA_OUT23 51 52 DATA_OUT25 DATA_IN21 49 50 GROUND DATA_OUT21 49 50 GROUND DATA_IN17 47 48 DATA_IN19 DATA_OUT17 47 48 DATA_OUT19 DATA_IN15 45 46 GROUND DATA_OUT15 45 46 GROUND GROUND 43 44 DATA_IN13 GROUND 43 44 DATA_OUT13 DATA_IN9 41 42 DATA_IN11 DATA_OUT9 41 42 DATA_OUT11 GROUND 39 40 DATA_IN7 GROUND 39 40 DATA_OUT7 DATA_IN3 37 38 DATA_IN5 DATA_OUT3 37 38 DATA_OUT5 GROUND 35 36 DATA_IN1 GROUND 35 36 DATA_OUT1 DATA_IN46 33 34 GROUND TDP_ANALOG_OUT 33 34 TDP_ANALOG_GND DATA_IN42 31 32 DATA_IN44 DATA_OUT42 31 32 DATA_OUT44 DATA_IN40 29 30 GROUND DATA_OUT40 29 30 GROUND DATA_IN36 27 28 DATA_IN38 DATA_OUT36 27 28 DATA_OUT38 DATA_IN34 25 26 GROUND DATA_OUT34 25 26 GROUND GROUND 23 24 DATA_IN32 GROUND 23 24 DATA_OUT32 DATA_IN28 21 22 DATA_IN30 DATA_OUT28 21 22 DATA_OUT30 GROUND 19 20 DATA_IN26 GROUND 19 20 DATA_OUT26 DATA_IN22 17 18 DATA_IN24 DATA_OUT22 17 18 DATA_OUT24 DATA_IN20 15 16 GROUND DATA_OUT20 15 16 GROUND DATA_IN16 13 14 DATA_IN18 DATA_OUT16 13 14 DATA_OUT18 DATA_IN14 11 12 GROUND DATA_OUT14 11 12 GROUND GROUND 9 10 DATA_IN12 GROUND 9 10 DATA_OUT12 DATA_IN8 7 8 DATA_IN10 DATA_OUT8 7 8 DATA_OUT10 GROUND 5 6 DATA_IN6 GROUND 5 6 DATA_OUT6 DATA_IN2 3 4 DATA_IN4 DATA_OUT2 3 4 DATA_OUT4 GROUND 1 2 DATA_IN0 GROUND 1 2 DATA_OUT0 RELAY CONTROL BOARD OPTOCOUPLER BOARD VCU Section

  2. SIGNAL TERMINALS ON RELAY CONTROL BOARD (1/2) TB15 TB16 GND RC36 RC37 RC38 GND RC39 RC40 RC41 1 2 3 4 5 6 7 8 RC47 RC46 RC45 RC44 GND RC43 RC42 GND 8 7 6 5 4 3 2 1 TB13 TB14 GND RC24 RC25 RC26 GND RC27 RC28 RC29 1 2 3 4 5 6 7 8 RC35 RC34 RC33 RC32 GND RC31 RC30 GND 8 7 6 5 4 3 2 1 uSW_TB GND GND MGV_RELAY2_7 MGV_RELAY1_7 MGV_CK_RELAY_5 MGV_CK_RELAY_7 MGV_DLY_RELAY_7 uSW_IN 1 2 3 4 5 6 7 8 TB11 TB12 GND RC12 RC13 RC14 GND RC15 RC16 RC17 1 2 3 4 5 6 7 8 RC23 RC22 RC21 RC20 GND RC19 RC18 GND 8 7 6 5 4 3 2 1 TB9 TB10 GND RC0 RC1 RC2 GND RC3 RC4 RC5 1 2 3 4 5 6 7 8 RC11 RC10 RC9 RC8 GND RC7 RC6 GND 8 7 6 5 4 3 2 1

  3. SIGNAL TERMINALS ON RELAY CONTROL BOARD (2/2) TB8 TB5 TB4 TB1 GND DATA_IN23 DATA_IN22 DATA_IN21 GND DATA_IN20 DATA_IN19 DATA_IN18 1 2 3 4 5 6 7 8 DATA_IN0 DATA_IN1 DATA_IN2 DATA_IN3 GND DATA_IN4 DATA_IN5 GND 8 7 6 5 4 3 2 1 DATA_IN24 DATA_IN25 DATA_IN26 DATA_IN27 GND DATA_IN28 DATA_IN29 GND 8 7 6 5 4 3 2 1 GND DATA_IN47 DATA_IN46 DATA_IN45 GND DATA_IN43 DATA_IN42 DATA_IN41 1 2 3 4 5 6 7 8 TB6 TB7 TB3 TB2 GND DATA_IN17 DATA_IN16 GND DATA_IN15 DATA_IN14 DATA_IN13 DATA_IN12 1 2 3 4 5 6 7 8 DATA_IN6 DATA_IN7 DATA_IN8 GND DATA_IN9 DATA_IN10 DATA_IN11 GND DATA_IN30 DATA_IN31 DATA_IN32 GND DATA_IN33 DATA_IN34 DATA_IN35 GND 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 GND DATA_IN41 DATA_IN40 GND DATA_IN39 DATA_IN38 DATA_IN37 DATA_IN36 1 2 3 4 5 6 7 8

  4. SIGNAL TTERMINALS ON OPTOCOUPLER BOARD (1/2) A28 TDPV_SW1 A29 TDPV_SW2 A30 MSP_SC A31 TSP_SC 1 2 3 4 5 6 7 8 A32 MSPV_P24V A33 TSPV_P24V A34 MPV_P24V A35 TPV_P24V 1 2 3 4 5 6 7 8 TB28 TB29 TContact_11 TContact_12 TContact_13 TContact_14 uSW_CLOSE uSW_COM A23 A24 1 2 3 4 5 6 7 8 A24 MGV_OS A25 MGV_CS A26 MDPV_SW1 A27 MDPV_SW2 1 2 3 4 5 6 7 8 TB26 TB27 TB30 TTP_REMOTE TTP_REMOTE_OUT_NO TTP_POWER_OUT_NO TTP_POWER TTP_ACCELERATION TTP_ACCELERATION_OUT_NO TTP_BREAK_OUT_NO TTP_BREAK 1 2 3 4 5 6 7 8 TTP_NORMAL_COM TTP_NORMAL_OUT_NO TTP_NORMAL_OUT_NC TTP_NORMAL_COM TTP_ALARM_COM TTP_ALARM_OUT_NO TTP_ALARM_OUT_NC TTP_ALARM_COM 1 2 3 4 5 6 7 8 MDP_ANALOG_GND MDP_ANALOG_OUT TDP_ANALOG_GND TDP_ANALOG_OUT 1 2 3 4 5 6 7 8 TB24 TB25 NC NC MContact_11 MContact_13 NC NC NC NC 1 2 3 4 5 6 7 8 MTP_WANING_COM MTP_WANNING_OUT_NO MTP_WANNING_OUT_NC MTP_WANNING_COM NC MContact_14 MContact_12 NC 1 2 3 4 5 6 7 8 TB22 TB23 MTP_REMOTE MTP_REMOTE_OUT_NO MTP_POWER_OUT_NO MTP_POWER MTP_ACCELERATION MTP_ACCELERATION_OUT_NO MTP_BREAK_OUT_NO MTP_BREAK 1 2 3 4 5 6 7 8 MTP_NORMAL_COM MTP_NORMAL_OUT_NO MTP_NORMAL_OUT_NC MTP_NORMAL_COM MTP_ALARM_COM MTP_ALARM_OUT_NO MTP_ALARM_OUT_NC MTP_ALARM_COM 1 2 3 4 5 6 7 8 TB20 TB21

  5. SIGNAL TTERMINALS ON OPTOCOUPLER BOARD (2/2) TB37 TB35 TB33 TB31 GND DATA_OUT17 DATA_OUT16 GND DATA_OUT15 DATA_OUT14 DATA_OUT13 DATA_OUT12 1 2 3 4 5 6 7 8 DATA_OUT0 DATA_OUT1 DATA_OUT2 DATA_OUT3 GND DATA_OUT4 DATA_OUT5 GND 8 7 6 5 4 3 2 1 DATA_OUT24 DATA_OUT25 DATA_OUT26 DATA_OUT27 GND DATA_OUT40 DATA_OUT41 GND 8 7 6 5 4 3 2 1 GND DATA_OUT41 DATA_OUT40 GND DATA_OUT39 DATA_OUT38 DATA_OUT37 DATA_OUT36 1 2 3 4 5 6 7 8 TB34 TB36 TB32 TB30 GND DATA_OUT23 DATA_OUT22 DATA_OUT21 GND DATA_OUT20 DATA_OUT19 DATA_OUT18 1 2 3 4 5 6 7 8 DATA_OUT6 DATA_OUT7 DATA_OUT8 GND DATA_OUT9 DATA_OUT10 DATA_OUT11 GND DATA_OUT24 DATA_OUT25 DATA_OUT26 DATA_OUT27 GND DATA_OUT28 DATA_OUT29 GND 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 MDP_ANALOG_GND MDP_ANALOG_OUT TDP_ANALOG_GND TDP_ANALOG_OUT DATA_OUT45 DATA_OUT44 DATA_OUT33 DATA_OUT32 1 2 3 4 5 6 7 8

  6. TPG256 Gauge Control Connector (CONN1, Female D-25 Connector) 4 --- 200-ohm pull-down to GROUND 5 --- RELAY-A 6 --- 50-ohm pull-up to VCU_P24V 8 --- 200-ohm pull-down to GROUND 9 --- RELAY-B 10 --- 50-ohm pull-up to VCU_P24V 25 --- VCU_P24V 13 VCU_P24V 25 12 24 11 23 10 VCU_P24V 22 9 RELAY-B 21 8 GROUND 20 7 19 6 VCU_P24V 18 5 RELAY-A 17 4 GROUND 16 3 15 2 14 1 VCU Section

  7. Gate Valve/Arm Switch Connector (CONECTOR 5, FEMALE 9-pole) 1 --- VP 2 --- VN 3 --- uSW_P1 4 --- uSW_P2 5 --- CS 6 --- CS_GND 7 --- VGND 8 --- OS 9 --- OS_GND 6 1 6 7 2 5 9 8 4 3 VCU Section

  8. MAIN MCU-X7 Turbo Pump Control Connector (Female D-37 Connector) MTP_NORMAL_OUT_NC MTP_NORMAL_OUT_NO MTP_ALARM_OUT_NO MTP_ALARM_OUT_NC MTP_WARNING_COM MTP_ACCELERATION MTP_REMOTE MTP_POWER MTP_BREAK MTP_START GROUND 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 MTP_ALARM_COM MTP_BREAK_OUT_NO MTP_NORMAL_COM MTP_ACCELERATION_OUT_NO MTP_POWER_OUT_NO MTP_REMOTE_OUT_NO MTP_WARNING_OUT_NC MTP_WARNING_OUT_NO MTP_RESET MAIN Section

  9. MAIN TC6000 Drag Pump Connector (CONECTOR 6, Female D-15 Connector) MRotation_Speed_Setting_Mode MMotor_Turbopump_on_off MPumping_Station_on_off MOutput_Switchpoint MStandby_on_off MVenting_on_off MTC600_p24V MReset 8 7 6 5 4 3 2 1 15 14 13 12 11 10 9 MContact_13 MContact_12 MContact_11 MGround (MDP_ANALOG_GND) MOutput_Malfunction MContact_14 MDP_ANALOG_OUT MAIN Section

  10. MAIN All Valves Connector (CONECTOR 1, FEMALE 10-pole) 8 1 --- MAIN_GND 2 --- AC_MDPV_L 3 --- AC_MDPV_N 4 --- DC_MDPV_a 5 --- DC_MDPV_b 6 --- DC_MDPV_c 7 --- DC_MDPV_d 8 --- MSPV_P24V 9 --- MPV_P24V 10 --- MAIN_P24V_GND 7 1 6 2 10 9 6 3 5 4 MAIN Section

  11. MAIN Cooling Fans Connector (CONECTOR 3, FEMALE 6-pole) 1 --- AC_MTPCU_l 2 --- AC_MTPCU_N 3 --- MDPCU_P24V 4 --- MDPCU_IN_P24V 5 --- MDPCU_P0V 6 --- MDPCU_IN_P0V 1 5 6 4 2 3 MAIN Section

  12. TRANSFER STP L301 Turbo Pump TB-1 Connector (Female D-15 Connector) TTP_NORMAL_OUT_NO TTP_POWER_OUT_NO TTP_ALARM_OUT_NC TTP_ALARM_OUT_NO TTP_BREAK_OUT_NO TTP_ALAM_COM TTP_POWER TTP_BREAK 8 7 6 5 4 3 2 1 15 14 13 12 11 10 9 TTP_REMOTE_OUT_NO TTP_REMOTE TTP_ACCELERATION_OUT_NO TTP_ACCELERATION TTP_NORMAL_OUT_NC TTP_NORMAL_COM TRANSFER Section

  13. TRANSFER TC6000 Drag Pump Connector (CONECTOR 7, Male D-15 Connector) TRotation_Speed_Setting_Mode TMotor_Turbopump_on_off TPumping_Station_on_off TOutput_Switchpoint TStandby_on_off TVenting_on_off TTC600_p24V TReset 8 7 6 5 4 3 2 1 15 14 13 12 11 10 9 TContact_13 TContact_12 TContact_11 TGround (TDP_ANALOG_GND) TOutput_Malfunction TContact_14 TDP_ANALOG_OUT TRANSFER Section

  14. TRANSFER All Valves Connector (CONECTOR 2, FEMALE 10-pole) 8 1 --- TRAN_GND 2 --- AC_TDPV_L 3 --- AC_TDPV_N 4 --- DC_TDPV_a 5 --- DC_TDPV_b 6 --- DC_TDPV_c 7 --- DC_TDPV_d 8 --- TSPV_P24V 9 --- TPV_P24V 10 --- TRAN_P24V_GND 7 1 6 2 10 9 6 3 5 4 TRANSFER Section

  15. TRANSFER Cooling Fans Connector (CONECTOR 4, FEMALE 6-pole) 1 --- AC_TTPCU_l 2 --- AC_TTPCU_N 3 --- TDPCU_P24V 4 --- TDPCU_IN_P24V 5 --- TDPCU_P0V 6 --- TDPCU_IN_P0V 1 5 6 4 2 3 TRANSFER Section

  16. TRANSFER STP L301 Turbo Pump TB2 Connector (MALE 6-pole) 1 --- TB2-1_P12V 2 --- CONNECT TO PIN 3 3 --- CONNECT TO PIN 2 4 --- TB2-4 (No Use) 5 --- TTP_START 6 --- TTP_RESET 1 5 6 2 4 3 TRANSFER Section
