Sequential circuits

1. Sequential circuits Part 1: flip flops All illustrations 2009-2010, Jones & Bartlett Publishers LLC, (www.jbpub.com)

2. Maintaining values over time • Electronic signals (e.g. clock pulses) are transient • In order for value to survive (be retained by receiving device), must be trapped & held after transient signal/connection broken • So can’t build computer from combinational nets alone – such devices don’t retain info

3. Sequential networks • Distinguishing characteristic: can maintain state, so output not solely dependent on input • Sequential nets built from same gates as combinational • difference is presence in sequential device of feedback loop • output of gate can become input to same gate

4. Stable vs. unstable network • Unstable: remains constant for only a few gate delays • suppose d=0; then a=0, b=1, c=0, d=1 – changed • Stable: state retained indefinitely (or at least as long as power is on) • if c=0, then a=0, b=1, c=0 – no change

5. S-R latch • S-R: Set-Reset • Mechanism for holding signal in a device • bi-stable device: can maintain one of 2 stable conditions • when signal arrives, S-R latch is set – remains set until second signal arrives, making it unset

6. S-R latch • Output depends on both input & state • Normal input position condition for input latch is SR=00 • To set or unset, change S or R to 1, then back to 0 (S & R never 1 at same time) Stable states:

7. Timing diagram for SR latch: 2 cycles • Initial state: Q=0, Q’=1 • S gets 1; Q=1, Q’=0; when S goes back to 0, output doesn’t change • R gets 1; resets Q to 0, Q’ to 1 (initial state) • S gets 1; sets Q to 1 • 1 to 0 transition in S; no change • another reset; back to initial state

8. Clock pulses • Signal sent at regular intervals • Time between pulses called period of clock • Shorter the period, faster the machine

9. Effect of clock pulse • As machine executes Von Neumann cycle, states of all sequential devices change with time • Machine maintains clock to synchronize these state changes (all occur simultaneously) • Clock generates series of pulses • CP: clock pulse • Every sequential device has CP input along with other inputs • S-R latch with CP: Flip-flop

10. Operation of sequential net • t0: initial state • t1: set (1) arrives @ S • passes through OR gate; value true @ point a • signal negated; false @ b • since no signal has arrived @ R, both R & b are false, so c is false • At point 2, signal negated, so Q is true – this result is fed back to lower OR-gate

11. Operation of sequential net • t2: signal @ S ceases • no impact on flip-flop, since Q is true; so regardless of S value, OR-gate produces true @ point a, false @ b, false @ c, true @ Q • output of flip-flop remains available at Q

12. Flip-flop symmetry • Provides mechanism for terminating set state • Reset mechanism • Signal @ R causes change at point c, Q=false • This cuts off support to bottom gate – signal now high @ Q’, low @ Q • If a second signal arrived @ S before signal arrived @ R, no change to outputs

13. Expanded view of clocked SR flip flop SR signals go through AND gates that act as enables: With CP=0, NOR inputs are 0 regardless of SR values, so latch won’t change state With CP=1, S & R pass through enable gates unchanged; device acts like SR described previously

14. Clock effect • Evenly spaced clock pulses force state change to occur only at evenly spaced time intervals • clock makes time digital just as voltage made digital by electronic circuitry • state change can only occur at pulse, not between them

15. Level-sensitive flip-flop • Latch responds to CP only when CP high • Can cause problem when combined with combinational devices in feedback loop: can lead to unstable state every few gate delays • Need: • SR constrained by CP • immune to further changes through feedback connection • sensitive to input for extremely short time period

16. Techniques for addressing level-sensitive flip flop problem • Edge-triggered flip flop: sensitive to input only when clock is making transition from low to high • Master-slave flip flop Diagram at left: timing detail of single clock pulse

17. Master-slave flip flop • Combine 2 level sensitive, clocked SR flip flops • Q’ of master connects to R of slave • Q of master connects to S of slave • CP connects to enable of master • CP’ connects to enable of slave • When slave is clocked, will be set or reset depending on state of master; slave takes state of master • Threshold of gate: input value that causes change in output

18. Timing detail of single clock pulse • t1: isolate slave from master • signal reaches threshold of master; inverter output goes 1 to 0 • slave now shielded from its own SR inputs • t2: connect master to input • signal reaches threshold of master enable gates • master now sensitive to SR inputs, but change in master can’t affect slave

19. Timing detail of single clock pulse • t3: isolate master from input • CP in high to low transition • master becomes insensitive to input • slave still isolated • t4: connect slave to master • CP now below inverter threshold • output goes 0 to 1, slave now connected to master • slave assumes state of master

20. Master-slave flip flop

21. Timing diagram of master-slave SR flip flop • Clock transition not instantaneous; gradually increase from V1 to V2, decreases through V2, V1 • Change occurs in Q (state of slave latch) when slave is connected to master (at time t4 – during CP transition from hight to low

22. Representing flip flop states • Flip flop is sequential, not combinatorial – can’t describe using truth table • Alternatives: • Finite state machine • Characteristic table

23. Characteristic table • Specifies state of device after one clock pulse for given input & initial state • Similar to state transition table for FSM

24. Finite State Machine • SR flip flop is FSM with 2 possible states (Q=0, Q=1) • As FSM can characterize using state transition diagram
