  1. Project Updates

  2. XL7 • Released May 31 • Single Ethernet Port • Single CAN Port • Release July 11 • Dual Ethernet Port • Dual CAN Ports • CAN 1 – CsCAN • CAN 2 – CAN Selectable

  3. RCC972 • Currently Released • CAN Only Model • Full Ethernet Support • Limited Register Support • 2nd Generation • Released Q4 • Battery Backed RAM • Full Register Support

  4. Cscape 9.3 SP6 • Released • Added Support • XL7 • RCC972 • Currently Posted on Update Server • Posted to web week of June 3rd

  5. HE-XHSQ/HE-XHSQ-5 • Release Q2/Q3 • HE-XHSQ • Add On X-Product Module • 2 – 24VDC PWM Outputs • HE-XHSQ-5 • Add On X-Product Module • 2 – 5VDC PWM Outputs

  6. Cscape 9.4 – Release Mid June Integrated Motion Blocks

  7. Future Hardware • Model 106 • Release Q4 • Preliminary Spec. • 4 Digital In • 4 Digital Out • 6 Universal Analog In • 4 Analog Out

  8. Future Hardware • CAN Open Smart Rail Base • Release Mid July • QX Replacement • XL Plus • Early 2014

  9. Future Enhancements • BACNET • Ethernet Slave • Available for Beta • Released End of July • XL4/XL7 HSC Enhancements • Support of 4 counters instead of 2 • Release Mid August

  10. Cscape 9.5 – Q3 Full IEC Tag Based Support (Horner Advanced Ladder to follow)

  11. Cscape 9.5 – Q3 Graphics Editor Update – Background Gradient Support

  12. Cscape 9.5 – Q3 Graphics Editor Update – Button Gradient Support

  13. Cscape 9.5 – Q3 Tool Tips for Graphics Objects – Hovering cursor over object to determine the address

  14. Seamless integration, one software environment • Dynamic auto-tuning • Ease-of-use for experienced & novice users • Streamlined network configuration • Turnkey & custom capabilities • Best-in-class technical support www.hsmotion.com

  15. Automated control solutions • Retrofit solutions • Grid Free www.horneretg.com
