  1. Chapter 7 Introduction to Structured Query Language (SQL) Database Systems: Design, Implementation, and Management, Seventh Edition, Rob and Coronel

  2. In this chapter, you will learn: • The basic commands and functions of SQL • How to use SQL for data administration (to create tables, indexes, and views) • How to use SQL for data manipulation (to add, modify, delete, and retrieve data) • How to use SQL to query a database to extract useful information Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  3. Introduction to SQL • SQL functions fit into two broad categories: • Data definition language • SQL includes commands to: • Create database objects, such as tables, indexes, and views • Define access rights to those database objects • Data manipulation language • Includes commands to insert, update, delete, and retrieve data within database tables Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  4. Introduction to SQL (continued) • SQL is relatively easy to learn • Basic command set has vocabulary of less than 100 words • Nonprocedural language • American National Standards Institute (ANSI) prescribes a standard SQL • Several SQL dialects exist Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  5. Introduction to SQL (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  6. Introduction to SQL (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  7. Introduction to SQL (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  8. Data Definition Commands • Examine simple database model and database tables that will form basis for many SQL examples • Understand data environment Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  9. The Database Model Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  10. The Database Model (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  11. Creating the Database • Following two tasks must be completed: • Create database structure • Create tables that will hold end-user data • First task: • RDBMS creates physical files that will hold database • Tends to differ substantially from one RDBMS to another Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  12. The Database Schema • Authentication • Process through which DBMS verifies that only registered users are able to access database • Log on to RDBMS using user ID and password created by database administrator • Schema • Group of database objects—such as tables and indexes—that are related to each other Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  13. Data Types • Data type selection is usually dictated by nature of data and by intended use • Pay close attention to expected use of attributes for sorting and data retrieval purposes Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  14. Data Types (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  15. Creating Table Structures • Use one line per column (attribute) definition • Use spaces to line up attribute characteristics and constraints • Sql commands are capitalized • NOT NULL specification • UNIQUE specification Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  16. Creating Table Structures (continued) • Primary key attributes indicate both a NOT NULL and a UNIQUE specification • RDBMS will automatically enforce referential integrity for foreign keys • Command sequence ends with semicolon Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  17. SQL Constraints • NOT NULL constraint • Ensures that column does not accept nulls • UNIQUE constraint • Ensures that all values in column are unique • DEFAULT constraint • Assigns value to attribute when a new row is added to table • CHECK constraint • Validates data when attribute value is entered Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  18. Creating Table Structures (continued) • CREATE TABLE CUSTOMER(    CUS_CODE  NUMBER(7) PRIMARY KEY,  CUS_LNAME  VARCHAR2 (20),CUS_ZIP  CHAR (5), AGENT_CODE  NUMBER (3) DEFAULT 412); Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  19. Creating Table Structures (continued) CREATE TABLE AGENT( AGENT_CODE  NUMBER(3) PRIMARY KEY, AGENT_PHONE CHAR (10)); Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  20. Creating Table Structures (continued) CREATE TABLE Product( p_code CHAR(10), /*...*/ p_descript VARCHAR2(35), --... p_indate DATE, p_onhand SMALLINT, p_min SMALLINT, p_price NUMBER(8,2) NOT NULL, p_discount NUMBER(4,2), v_code INTEGER CONSTRAINT v_code_fk REFERENCES Vendor(v_code), CONSTRAINT p_code_pk PRIMARY KEY (p_code)); Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  21. Creating Table Structures (continued) CREATE TABLE Product( p_code CHAR(10) CONSTRAINT p_code_pk PRIMARY KEY, p_descript VARCHAR2(35), p_indate DATE, p_onhand SMALLINT, p_min SMALLINT, p_price NUMBER(8,2) NOT NULL, p_discount NUMBER(4,2), v_code INTEGER CONSTRAINT v_code_fk REFERENCES Vendor(v_code)); Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  22. Creating Table Structures (continued) CREATE TABLE Employee( ssn CHAR(10), salary NUMBER(9,2), title VARCHAR2(20), class NUMBER(1) constraint class_ck CHECK (class BETWEEN 1 AND 4), CONSTRAINT title_uk UNIQUE (title), CONSTRAINT ssn_salary_pk PRIMARY KEY (ssn, salary)); Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  23. SQL Indexes • When primary key is declared, DBMS automatically creates unique index • Often need additional indexes • Using CREATE INDEX command, SQL indexes can be created on basis of any selected attribute • Composite index • Index based on two or more attributes • Often used to prevent data duplication Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  24. SQL Indexes (continued) CREATE [UNIQUE] INDEX indexname ON tablename (column1 [, column2]) CREATE INDEX Emptest on Test (emp_num) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  25. SQL Indexes (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  26. Data Manipulation Commands • Adding table rows • Saving table changes • Listing table rows • Updating table rows • Restoring table contents • Deleting table rows • Inserting table rows with a select subquery Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  27. Adding Table Rows • INSERT • Used to enter data into table • Insert a row each time • Syntax: • INSERT INTO tablenameVALUES (value1, value2, … , valuen); Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  28. Adding Table Rows (continued) • When entering values, notice that: • Row contents are entered between parentheses • Character and date values are entered between apostrophes • Numerical entries are not enclosed in apostrophes • Attribute entries are separated by commas • A value is required for each column • Use NULL for unknown values Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  29. Adding Table Rows (continued) INSERT INTO Product VALUES (‘BRT-345’, ‘Titanium drill bit’, TO_DATE(’18-Oct-05’, ’DD-MON-YY’), 75, 10, 4.5, 0.06, NULL); or TO_DATE (’18/Oct/05’, ’DD/MON/YY’) or TO_DATE(’10/18/2005’, ‘MM/DD/YYYY’) or TO_DATE(‘October 18, 2005’, ‘Month DD, YYYY’) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  30. Saving Table Changes • Changes made to table contents are not physically saved on disk until, one of the following occurs: • Database is closed • Program is closed • COMMIT command is used • Syntax: • COMMIT [WORK]; • Will permanently save any changes made to any table in the database Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  31. Listing Table Rows • SELECT • Used to list contents of table • Syntax: • SELECT columnlistFROM tablename; • Columnlist represents one or more attributes, separated by commas • Asterisk can be used as wildcard character to list all attributes Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  32. Listing Table Rows (continued) SELECT p_code, p_descript, p_indate, p_qoh, p_min, p_price, p_discount, v_code FROM Product; SELECT * FROM Product; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  33. Listing Table Rows (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  34. Updating Table Rows • UPDATE • Modify data in a table • Syntax: • UPDATE tablenameSET columnname = expression [, columname = expression][WHERE conditionlist]; • If more than one attribute is to be updated in row, separate corrections with commas Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  35. Updating Table Rows (continued) UPDATE Product SET p_indate = ’18-Jan-2006’, p_price = 7.6 WHERE p_code = ‘13-Q2/P2’; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  36. Restoring Table Contents • ROLLBACK • Used to restore database to its previous condition • Only applicable if COMMIT command has not been used to permanently store changes in database • Syntax: • ROLLBACK; • COMMIT and ROLLBACK only work with data manipulation commands that are used to add, modify, or delete table rows Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  37. Deleting Table Rows • DELETE • Deletes a table row • Syntax: • DELETE FROM tablename[WHERE conditionlist ]; • WHERE condition is optional • If WHERE condition is not specified, all rows from specified table will be deleted Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  38. Deleting Table Rows (continued) DELETE FROM Product WHERE p_code = ‘BRT-345’; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  39. Inserting Table Rows with a Select Subquery • INSERT • Inserts multiple rows from another table (source) • Uses SELECT subquery • Query that is embedded (or nested) inside another query • Executed first • Syntax: • INSERT INTO tablename SELECT columnlist FROM tablename; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  40. Inserting Table Rows with a Select Subquery (continued) INSERT INTO p SELECT * from Product; Employee(name, address, emp_num, salary) Emp1(addr, sal, empno) INSERT INTO Emp1 SELECT address, salary, emp_num FROM Employee; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  41. Inserting Table Rows with a Select Subquery (continued) • INSERT INTO Emp1 SELECT address, emp_num, salary FROM Employee; (The order of attributes matter in the above) • INSERT INTO Emp1 SELECT * FROM Employee; (The number of attributes are not the same!) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  42. Selecting Rows with Conditional Restrictions • Select partial table contents by placing restrictions on rows to be included in output • Add conditional restrictions to SELECT statement, using WHERE clause • Syntax: • SELECT columnlistFROM tablelist[ WHERE conditionlist ] ; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  43. Selecting Rows with Conditional Restrictions (continued) SELECT p_descript, p_indate, p_price, v_code FROM Product WHERE v_code = 21344; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  44. Selecting Rows with Conditional Restrictions (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  45. Selecting Rows with Conditional Restrictions (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  46. Selecting Rows with Conditional Restrictions (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  47. Selecting Rows with Conditional Restrictions (continued) SELECT p_descript, p_indate, p_price, v_code FROM Product WHERE v_code <>21344; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  48. Selecting Rows with Conditional Restrictions (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  49. Selecting Rows with Conditional Restrictions (continued) SELECT p_descript, p_qoh, p_min, p_price FROM Product WHERE p_price <= 10; Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel

  50. Selecting Rows with Conditional Restrictions (continued) Database Systems: Design, Implementation, & Management, 7th Edition, Rob & Coronel
