  1. Remote Detonation System

  2. Remote Detonation System – RDS System Composition • RDS is a Remote Detonation system for use by Armed Forces, Mining, Road Blasting & Building demolitions etc. • Configuration • (a) One Master Control Unit • (b) Multiple Slave Units • Three Battery Charging Options: • Utility Power Adapter • Vehicle Power Adapter • Solar PV Panel Adapter • Communication Media via Land Line and UHF Link • Water Proof (IP67) & robust field Packing • It is suitable for use at Plain & Hilly areas, having a range of 5Km in vegetation area & more than 25Km at line of site

  3. Remote Detonation System – RDS Basic Configuration MICROWAVE LINK Slave Unit #1 Slave Unit #6 Slave Unit #2 Slave Unit #7 Master Control Unit Slave Unit #3 Slave Unit #8 Slave Unit #4 Slave Unit #9 LAND LINE Slave Unit #5 Slave Unit #10 to #20

  4. Remote Detonation System – RDS Previous Versions 2nd Version : 2010 1st Version : 2008 UHF VHF

  5. Remote Detonation System – RDS Current Versions 2013-14

  6. Remote Detonation System – RDS System Composition Charging Options Master Unit Slave Unit

  7. Remote Detonation System – RDS Operational Specifications & Features • Operational Coverage , three to Five Km in vegetation and 25Km line of sight range • Self Test provisions for both Master & Slave units • Close loop Communication System for Status & Fault monitoring of Slave units • Land line option is provided against RF jamming • Maintenance friendly , User friendly & light weight

  8. Remote Detonation System – RDS Operational Specifications & Features • Day & Night Operation • Intelligent Battery Charger • Message encryption • Cancellation of Preprogramed commands • Indication of Slave Units Identity and status on Master Control unit • Selection of one, multiple or all slave units simultaneously • System is protected against any accidental operation from other similar groups

  9. Remote Detonation System – RDS Operational Specifications & Features • Quick Installation • Robust design for field use • Land Line effective length >2 Km depending upon cable impedance • Maximum line impedance 60 Ohms • Complete indigenous solution and in country source is available for any future up-gradation • Current Technology design
