Presentation Transcript


  1. MOTION

  2. To say something is truly moving, you have to observe how it changes relative to a reference point.

  3. How far an object travels will be measured in meters.

  4. DISTANCE The actual path an object travels The object may turn and curve.

  5. DISPLACEMENT Straight line path from start to finish, shortest distance. Tells how far and gives a direction. Measures the change in an object’s position.

  6. 5 Meters 3 Meters 4 Meters

  7. DISTANCE DISPLACEMENT DIRECTION LENGTH OF ACTUAL PATH METERS STAIGHT LINE

  8. The speed of an object can be determined if we know

  9. The distance an object travels

  10. And the time it takes to go this distance.

  11. If I identify the direction in which that object travels, I am now taking about its velocity.

  12. 3 m/s __________________ speed_ velocity 3 m/s due North __________________ speed 5.6 m/s __________________ velocity 5.6 m/s out the door______________

  13. To calculate how fast an object is moving we need to measure Distance (D) in meters Time (T) in seconds

  14. Velocity = Distance Time V = D T

  15. A wheelchair racer finishes a 132 m race in 18s. What is his speed? K1 1. Rewrite formula K2 2. Put in knowns Uk 3. Do math Formula 4. Write answer

  16. Find the velocity of a swimmer who swims 110 m toward the shore in 72 seconds. K1 1. K2 2. UK 3. Formula 4.

  17. Find the velocity of a baseball thrown 38 m from third base to first base in 1.7s. K1 1. K2 2. UK 3. Formula 4.

  18. Distance (D) Velocity (V) Time (T)

  19. If a cheetah can run at a maximum velocity of 29m/s towards its prey for 28 seconds, how far does it run? K1 1. K2 2. UK 3. Formula 4.

  20. If you can run at a rate of 12 m/s, how far would you go in 3 seconds? K1 1. K2 2. UK 3. Formula 4.

  21. A crow covers a distance of 120 m in 8 seconds. How fast does it fly? K1 1. K2 2. UK 3. Formula 4.

  22. How far can a matchbox car travel in 8 seconds, if it travels at a speed of 2 m/s? K1 1. K2 2. UK 3. Formula 4.

  23. Acceleration

  24. Acceleration refers to a change in one of two things… Speed, or how fast you are moving.

  25. Direction in which you are moving. Centripetal acceleration Occurs during circular motion.

  26. Time (T) seconds, for which the object travels. Initial Velocity (Vi), or starting velocity of an object Final Velocity (Vf), or the ending velocity of the object.

  27. We will use the symbol delta(∆)to indicate the change in velocity of an the object.

  28. If the change in velocity is positive, we will say that the object is speeding up.

  29. If the change in velocity is negative, we will say that the object is slowing down.

  30. We find the change in velocity by subtracting the initial velocity from the final velocity.

  31. ∆ V = Vf – Vi CHANGE = FINAL – INITIAL IN VELOCITY VELOCITY VELOCITY

  32. The unit for acceleration is meter or m/s2 second2

  33. Change in Acceleration = Velocity time A = Vf– Vi A = ∆V t t

  34. Change in Velocity (∆V) Acceleration (A) Time (T)

  35. What is the acceleration of a car that starts at rest and gets to a speed of 29.4 m/s in 45 seconds? K1 1. K2 2. K3 3. UK 4. Formula

  36. What is the acceleration of a toy travelling at a rate of 6 m/s if it comes to a stop in 2 seconds? K1 1. K2 2. K3 3. UK 4. Formula

  37. What is the acceleration of a bird who takes off from a nest and 7 seconds later is travelling at a rate of 9 m/s? K1 1. K2 2. K3 3. UK 4. Formula

  38. How long will it take for a person on bike to accelerate from rest to 15 m/s if the rate of acceleration is 10 m/s2? K1 1. K2 2. K3 3. UK 4. Formula
