  1. Work Plan W. Miller iTi M. Cepeda, S. Dardin, M. Gilchriese, C. Haber, R. Post LBNL February 6, 2007

  2. Prototype Recap • Slightly squashed tube • Requires less development(with CGL adhesive, baseline) • Sufficient for mounting silicon/electronics for critical electrical performance evaluation • Use to debug fabrication and for non-destructive mechanical tests • Round tube with graphite foam • Requires more development to figure out how best to bond foam to tube(and tube size) – see next page • To extent believe CO2 is likely coolant candidate, doing this second works out some of the bugs in fabrication with squashed tube stave

  3. Graphite Foam • Just starting this(last week) • First trial is POCO foam sample machined to current dimensions bonded to round tube • Learning how to machine • More samples in progress • Properties via link on wiki • Very recent thermal calculations indicate can reduce tube OD(eg. 2.8 mm calculated to be OK) • Tradeoff possible between tube OD and foam machining practicalities. Impact on radiation length small. http://phyweb.lbl.gov/atlaswiki/index.php?title=ATLAS_Upgrade_R%26D_-_Mechanical_Studies

  4. Tooling • Vacuum and other tooling for assembly of stave “core” • Design complete(see wiki for models and drawings) • Shop fabrication largely complete. Pictures will appear on wiki • Modifications inevitable as we go through process • “Tooling” and procedures for layup of facings and other parts • Has been some time since we did this(years) • Reconfiguring pixel construction area, finding old tooling • Get autoclave and cutting going again • Just in progress, will take some weeks given other demands • Tooling for silicon detector and hybrid placement and wire bonding • Concepts sketched • Models/drawings just getting underway

  5. Stave Mechanics Fabrication • Qualification and test samples(partial list) • Facing layup samples(remember how to do this) • Honeycomb bonding samples – need trial although similar done before • Foam bonding samples - started • Shear modulus samples • Facings+honeycomb • Facings+honeycomb+tube(squashed) • Facings+honeycomb+tube+graphite foam • Thermal performance samples • Roughly 35 cm long. Parallel tube(not U-tube) • Squashed tube first. Graphite foam-round tube later • Heater configuration and type is TBD. • Production – 3 total full-length • Full-length, squashed tube(1) -> Non-destructive mechanical tests -> Carl for silicon loading • Full-length, round tube(1) -> Non-destructive mechanical tests -> RAL for silicon or ? • 3rd full length(1). Tube type TBD later -> thermal/mechanical tests?

  6. Mechanics Parts - Plan

  7. Electrical Parts - Plan

  8. Overall Plan
