  1. TEQC Editor Mark W. Huber Army Geospatial Center http://teqc.silkwerks.com

  2. TEQC Editor Just a front end on the UNAVCO TEQC Translation, Editing, and Quality Checking http://facility.unavco.org/software/teqc/ http://teqc.silkwerks.com

  3. Browse to file(s) Selected file is shown on the Input Tab http://teqc.silkwerks.com

  4. Browse to file(s) – choose two files to concatenate http://teqc.silkwerks.com

  5. Default output file extension is “.teqc” Ability to split files into segments (useful for OPUS-RS) http://teqc.silkwerks.com

  6. Ability to split files into segments (useful for OPUS-RS) User selects duration of output files http://teqc.silkwerks.com

  7. Choose to echo TEQC message Choose to create a DOS batch file which is useful for troubleshooting http://teqc.silkwerks.com

  8. Enter in new start and stop times using TEQC formatting Double click the textbox to pull up the slider. http://teqc.silkwerks.com

  9. Slide to desired time Session length is displayed http://teqc.silkwerks.com

  10. Specify metadata (i.e. point name/number, agency, observer) User can set defaults http://teqc.silkwerks.com

  11. Delete satellites/systems This function is why this utility was created – useful with OPUS-Projects http://teqc.silkwerks.com

  12. Specify the observables required separated by a '+' (Ex c1+l1+l2+p2) Options L1, L2, C1, P2, P1, D1, and D2 http://teqc.silkwerks.com

  13. Decimate observations to specified interval http://teqc.silkwerks.com

  14. If you are a TEQC techy and you remember the switches, you can enter them here http://teqc.silkwerks.com

  15. [Execute] to preprocess the input file(s) The output RINEX file is displayed on the Output Tab http://teqc.silkwerks.com

  16. [QC] will run the TEQC Quality Check on the selected input file http://teqc.silkwerks.com

  17. [QC] will run the TEQC Quality Check on the selected input file http://teqc.silkwerks.com

  18. The Utilities Tab will gather OPUS results and display them in tabular form Choose either Outlook or Text Files [Get Outlook Mail] will prompt for Inbox Folder [Get Text Files] will browse for folder http://teqc.silkwerks.com

  19. [Copy] puts the output into the paste buffer http://teqc.silkwerks.com

  20. Then you can paste into Excel or other programs http://teqc.silkwerks.com

  21. Questions? mark.w.huber@usace.army.mil http://teqc.silkwerks.com
