  1. Active Harmonic Filters BY Mohit Bat

  2. VisiontekniksAHVsfor harmonic mitigation and reactive power compensation Active Harmonic Filters provide a very effective solution in: Mitigates Harmonic distortion, by injecting current to compensate any unwanted deviations from the standard 50 or 60 Hz supply. Ultimately helping by:

  3. Mitigating harmonics and reducing voltage fluctuations and • Improving the Reliability and Capacity of the existing Electrical system and Reduced operating costs • Deviations can be mitigated in full or partially.

  4. Benefits: • Easy and quick to install with Modular Configuration • Can be combined with passive filters • Harmonic attenuation up to 97% at rated current, preventing possible harmonic resonance • Improvement in True Power Factor • Reduced cable rating (neutral wire size).Mitigates neutral I and N-GV. • Increase electrical network reliability and reduce operating costs • Reduced switchgear, upstream transformer, and generator ratings • Reduced energy bill and utility power factor penalties • Avoids nuisance in tripping circuit breakers and protection relays • Avoids malfunction of automatic control system and inaccuracy of instrument measurement • Erases voltage distortion (flat top) typical in non-linear loads • Avoids capacitordamage due to resonance. • Increased equipment life

  5. Applications • Commercial Buildings • Manufacturing Facilities • Data Center • Food & Beverage • Water Treatment Plants • Automotive Sector • Hospitals
