  1. Audio Visualization DeviceSoftware Presentation Keenan Haines Nicole Samuelson

  2. General System Requirements • MCU: 9S12DP512 • Bus Frequency: 24MHz • Memory Requirements: • 10k bytes Flash EEPROM • 2k bytes EEPROM • 2k bytes RAM • Kernel: MicroC/OS-II • Tick Period: 1ms

  3. Task Priorities • Start Task • Sampling Task • User Interface Task • Display Task

  4. Start Task • Initializes the system • Creates the other tasks • Displays user prompt • Priority: 4 • Period: once (at start-up) • Execution Time: ~ 1 sec

  5. Sampling Task • Sample incoming audio • Determines volume level • Stores data for display • Priority: 5 • Period: 1ms • Execution Time: 200us

  6. User Interface Task • Receives user preferences • Priority: 6 • Period: 20ms(min) • Execution Time: 2ms

  7. Display Task • Cycles through animations • Operates LED drivers • Generates MIDI commands • Priority: 7 • Period: 20ms • Execution Time: 2ms(max)

  8. CPU Load Lmax = 200us + 2ms + 2ms 1ms 20ms 20ms Lmax = 40% Lavg = 10.2%

  9. Modules

  10. Data Flow Diagrams

  11. Questions or Comments?
