  1. Automotive Technology A Systems Approach PowerPoint® Presentation Prepared by René Green

  2. Chapter 4 Shop Tools

  3. Shop Tools • Chapter Overview • This chapter will present some of the more commonly used hand and power tools with which every technician must be familiar. Since units of measurement play such an important part in tool selection and in diagnosing automotive problems, this chapter begins with a presentation of measuring systems. Prior to the discussion on tools, there is a discussion on another topic that relates very much to measuring systems -- fasteners.

  4. Shop Tools • Chapter Objectives • List the basic units of measure for length, volume, and mass in the two measuring systems. • Describe the different types of fasteners used in the automotive industry. • List the various mechanical measuring tools used in the automotive shop. • Describe the proper procedure for measuring with a micrometer.

  5. Shop Tools • List some of the common hand tools used in auto repair. • Describe the use of common pneumatic, electrical, and hydraulic power tools found in an automotive service department. • Describe the different sources for service information that are available to technicians.

  6. Shop Tools • Measuring Systems • Linear Measurements • Square Measurements • Volume Measurements • Weight Measurements • Temperature Measurements • Pressure Measurements • Torque Measurements

  7. Shop Tools • Studs • Setscrews • Fasteners • Bolts • Cap Screws • Nuts

  8. Shop Tools • Bolt Identification • Bolt diameter • Bolt Grades • Bolt shank • Thread pitch

  9. Shop Tools • Tightening Bolts • Washers • Measuring Tools • Machinists Rule • Vernier Caliper

  10. Shop Tools • Dial Caliper • Micrometers

  11. Shop Tools • Reading a Metric Micrometer • Each number on the sleeve of the micrometer represents 5.0 millimeters. • Each of the ten equal spaces between each number, with index lines alternating above and below the horizontal line, represents 0.5 mm. • The beveled edge of the thimble is divided into 50 equal divisions with every fifth line numbered: 0,5,10, . . . 45. • As with the inch-graduated micrometer, the three separate readings are added together to obtain the total reading.

  12. Shop Tools • Using an Outside Micrometer

  13. Shop Tools • Reading an inside Micrometer • Reading a Depth Micrometer • Telescoping Gauge

  14. Shop Tools • Small Hole Gauge

  15. Shop Tools • Feeler Gauge • Screw Pitch Gauge • Dial Indicator

  16. Shop Tools • Torque Indicating Wrench • Beam type • "Click" type • Dial indicator type • Hand Tools • Wrenches • Open-end • Box-end • Combination

  17. Shop Tools • Socket

  18. Shop Tools • Allen wrenches • Standard • Screwdrivers • Phillips

  19. Shop Tools • Pozidriv® • Torx® • Clutch Driver • Sculox® • Pliers • Combination • Adjustable • Needle nose • Locking • Diagonal cutting • Snap or lock ring • Retaining ring

  20. Shop Tools • Hammers • Taps and Dies • Chisels and Punches • Removers • Extractors • Hacksaws • Files • Tubing Tools • Gear and Bearing Pullers

  21. Shop Tools • Power Tools • Impact Wrench • Air Ratchet • Air Drill • Air Chisel or Hammer • Blowgun • Bench Grinder • Trouble Light • Presses

  22. Shop Tools • Service Manuals • Auto Manufacturer's Manuals • Aftermarket Supplier's Guides and Catalogs • General and Specialty Repair Manuals • Flat-rate Manuals • Computer-based Information • Hotline Services
