  1. InauguralEvent Understanding IBC 2009 Schubin Cafe, IBC 2009

  2. Why I Love IBC • Location • Train • Food & Drink • Beach • Content Schubin Cafe, IBC 2009

  3. Things You Don’t See at NAB SquareHead Technology Audioscope: IBC 2007 Schubin Cafe, IBC 2009

  4. Schubin Cafe, IBC 2009

  5. Schubin Cafe, IBC 2009

  6. Higher Frame Rates BBC/EBU simulation from 300- fps video 50 Hz 100 Hz • LG: LCD Trumotion 480 Hz • Compressed rate TBD • less change between frames • sharper for easier estimation Schubin Cafe, IBC 2009

  7. IBC 2009 • 45,547 attendance 7%, 1355 exhibitors 7% • registrations 74,478, visitors 30,708 • Avid & Panasonic return; Sony leaves • 4K no?: cameras, projectors, people • Cameras (25 new HD-or-more models) • not new: GV, Hitachi, Ikegami, JVC, Panasonic • new: Acutelogic HK, ARRI, Astrodesign, Bradley Eng. Camera Corps, FFV, Gigawave, HDAVS, LMP, P+S, (Red), ShenZhen Tiger, Skyline:Views, 3D-One, Vaddio • unusual: Antelope, Dalsa, Darim, Point Grey, Polycom • 3-D in the Home • BBC, conditional access, EPG, health warnings, Sky, test • 2012 Games in 3-D. Not. Yes. Not… Schubin Cafe, IBC 2009

  8. Schubin Cafe, IBC 2009

  9. EBU “10 Things You Needto Know about Loudness” Schubin Cafe, IBC 2009

  10. Schubin Cafe, IBC 2009

  11. Studio Hamburg MCI radarTOUCH Schubin Cafe, IBC 2009 up to 50-m screen (larger possible)

  12. Camera Accessories Camera Corps Q-lite for Q-ball TK-3 Orbiter 270 Soft Lights WiFi Guy-Louis Mier 5K resolution chart Schubin Cafe, IBC 2009 filmotechnic Portocam

  13. HDAVS Dual iVDR storage Hard-Drive or Flash 2x capacity or mirror VTR-like edit-deck HDC-680 E2 DataCam in use at China Central TV Schubin Cafe, IBC 2009 Hitachi iVDR TV?

  14. Production Village Same Set: • ARRI D-21 • GV Viper • HDAVS HDC-680 • JVC 4K (plus 4) • 7 Panasonic • SI-2K • SonyF35&XDCAMEX • Weisscam HS-2 Schubin Cafe, IBC 2009

  15. Acutelogic HK PE-1005 1920x1080 1/2.5-inch sensor 10:1 zoom 10-mm MOD Schubin Cafe, IBC 2009

  16. Other Small Cameras Gigawave wireless 2/3-inch HD camera 8 cameras over keyboard at Darim Bradley Engineering HD 100 100-mm deep FFV HD 2/3-inch USB control Modula Baby 2/3-inch HD 36x36x64 mm Point Grey Grasshopper and Ladybug (all 1.6x1.2k) at 2020 3D Media Dalsa Falcons around GV Viper Lux Media Plan HD 1200 2/3-inch 42x42x38 mm Xensium sensor f/11 2K lx 60 dB SNR Schubin Cafe, IBC 2009

  17. Film & HD IBC 2002 Joe Dunton Company Mitchell HD Magazine (Ikegami electronics) ARRI HD-IVS video assist P+S Technik HD magazine for ARRI 16SR (LMP electronics) Schubin Cafe, IBC 2009

  18. More on image formats at HD World tomorrow 9-10 am For a freeticket, go to www.ccwexpo.com and use “secret” code 29cwe38 Schubin Cafe, IBC 2009

  19. New ARRI Cameras through-the- lens viewfinder ~ $50K recording TBA, CCUs possible 3.5K 4x3 “dual-gain architecture” ~ 1 stop more dynamic range than the D-21 1280x 720 electronic VF Schubin Cafe, IBC 2009

  20. High Dynamic Range Dual Sensors Fuji Super CCD in Still Cameras Schubin Cafe, IBC 2009

  21. 500-watt halogen light Schubin Cafe, IBC 2009

  22. 10,000,000:1 (>23-stop) contrast ratio Xensium lab experiment courtesy of Thomson Schubin Cafe, IBC 2009

  23. Lux Media Plan“high dynamic mode: 120 dB” LP1: minimum interpupillary distance 38 mm Schubin Cafe, IBC 2009

  24. Schubin Cafe, IBC 2009

  25. Schubin Cafe, IBC 2009

  26. Schubin Cafe, IBC 2009

  27. More 3-D Cameras 23 exhibitors listed under “3D Cameras” in IBC directory many 2-camera rigs at multiple vendors 3D-One CP-20, 1 of 4 models 1/2-inch CMOS sensors variable vergence stereoscopic viewfinder also LMP LP1 & Astro SHVC 3ality beamsplitter & side-by-side rigs at EVS (operator training) Schubin Cafe, IBC 2009

  28. Sony’s Single-Lens 3-D Camera unveiled at CEATEC interpupillary-separation issue other questions Schubin Cafe, IBC 2009

  29. 3-D without 3-D Cameras • CRC: color-only basis • JVC, previously shown color, focus, motion • Zero Creative • BBC Schubin Cafe, IBC 2009

  30. Schubin Cafe, IBC 2009

  31. Anaglyph Lives! • Viewfinders • Test Equipment • Viewing • ColorCode • Trioscopics • Plain Blue/Red normally lighting filters Schubin Cafe, IBC 2009

  32. Some 3-D Issues • Doubled cameras • Lens Tracking • Image Differences • Convergence • Viewfinder • Coding • Compression • Graphics Planes • Display Ghosting • Light Levels at the secret 3-D lab? Schubin Cafe, IBC 2009

  33. NEP SS-3D Schubin Cafe, IBC 2009

  34. Other IBC 3-D • EBU Village • www.3D4You.eu • “10 Things to Know” • Test & Measurement • Hamlet VidScope-3D • Home Interfaces • Nagravision EPG • Viaccess CA • Pace STB Schubin Cafe, IBC 2009

  35. Schubin Cafe, IBC 2009

  36. Schubin Cafe, IBC 2009

  37. 3-D TV through the Ages “There are, of course, several possible methods of accomplishing Stereoscopic Television” – Fundamentals of Television, 1930 1928 1953 Business Week headline: “3-D Invades TV” 2009NABDigitalCinemaSummit Dr. Martin Banks, UC Berkeley: “first evidence that a vergence- accommodation conflict can cause fatigue and discomfort.” 1991 2001 Schubin Cafe, IBC 2009

  38. “First Evidence?” “Studies made by Hartridge, Kletzky and others indicate that one of the most common causes of eye-strain consists in an unconscious attempt on the part of the observer to modify the normal coördination of the ocular reflexes of accommodation and convergence.” - Leonard Thompson Troland, Ph.D., The American Journal of Physiological Optics, v. 12, n. 3, p. 381, July 1926 Schubin Cafe, IBC 2009

  39. Accommodation (eye-lens focus) Viewing Distances (in feet) TV: 1-10 Cinema: 30-120 Schubin Cafe, IBC 2009

  40. (Con)Vergence Based on a 2.6-inch interpupillary distance: Feet Degrees • 0.5 12.2 • 1 6.2 • 2 3.1 • 4 1.6 • 8 0.8 • 16 0.4 • 32 0.2 Schubin Cafe, IBC 2009

  41. “The Truth About Stereoscopic Television” Schubin Cafe, IBC 2009

  42. IBC Daily News, September 12 “Conference Today: Wood calls for health warning on 3D television” David Wood, EBU "I plan to concentrate on getting broadcasters to take the issues around eye fatigue seriously," he said. "I want a government health warning on all 3D products and shows, but it won't say that 3D kills like cigarettes do."What this means is that when broadcasters screen 3D content, they should mention up front that there are viewers who cannot fuse left and right images," he added. "Shows should at the very least carry a caution that viewers should not watch 3D for long periods." Schubin Cafe, IBC 2009

  43. ThisIsn’ttheYearof3-DTV(1st1928) • Infinite-distance parallel interpupillary: • Set for 30’ screen, 60’ screen diverges 15’ screen too close TV screenreally close • Except holographic and moving-mirror displays, convergence does not match accommodation Schubin Cafe, IBC 2009

  44. In-Three: “3D in the Home” Schubin Cafe, IBC 2009

  45. Schubin Cafe, IBC 2009

  46. TV Innovation Money, Training, & possible nausea*: • 3-D TV Money & Training: • Sound • Color • Stereo Sound • Widescreen • HDTV • Digital “The last thing you want to do is make your audience hurl.” - Jeffrey Katzenberg, IBC 2008 * investigated by NTSC in 1940 Schubin Cafe, IBC 2009

  47. Schiphol Rijksmuseum Schubin Cafe, IBC 2009 Melchior d'Hondecoeter 1636-1695

  48. Questions? HD World Javits Center free ticket www.ccwexpo.com “secret” code 29cwe38 Schubin Cafe, IBC 2009
