1. NFA To DFA Dr. Shakir Al Faraji

2. a,b a 2+ -1 NFA – without  Convert the following NFA into DFA Dr. Shakir Al Faraji

3. NFA – without  We find transition table for NFA Dr. Shakir Al Faraji

4. NFA – without  Now we construct transition table for DFA TD(1,a) = TN(1,a) = {1,2} TD(1,b) = TN(1,b) = {1} TD({1,2},a) = TN(1,a) U TN(2,a) = {1,2} UØ= {1,2} TD({1,2},b)=TN(1,b)UTN(2,b)={1}UØ={1} Dr. Shakir Al Faraji

5. NFA – without  Ttransition table for DFA Dr. Shakir Al Faraji

6. a b {1,2}+ {1} - b a NFA – without  Dr. Shakir Al Faraji

7. a,b a y2+ -y1 NFA – without -another method Convert the following NFA into DFA Dr. Shakir Al Faraji

8. a,b a,b a a,b y3 y2+ -y1 NFA – without  Convert the following NFA into DFA Dr. Shakir Al Faraji

9. NFA – without  Dr. Shakir Al Faraji

10. NFA – without  Dr. Shakir Al Faraji

11. a Z2+ b Z1- b a a b a Z3+ Z4 b NFA – without  Dr. Shakir Al Faraji

12. a,b a a a,b + - NFA – without  Example: convert the NFA into DFA Dr. Shakir Al Faraji

13. NFA – with  - closure If s is an NFA state, then the lambda closure of s, denoted (s) , is the set of states that can be reached from s by traversing zero or more  edges. We can define (s) inductively as follows forany state s in an NFA. • s (s) • if p(s) and there is a  edge from p to q, then q (s). Dr. Shakir Al Faraji

14.   a,  a b 1- 2 3 4 5+ a NFA with – Examples Dr. Shakir Al Faraji

15. NFA with – Examples We find transition table for NFA Dr. Shakir Al Faraji

16. NFA with – Examples We find - closure for five states of NFA (1) = {1,2} (2) = {2} (3) = {2,3} (4) = {2,3,4,5} (5) = {5} Dr. Shakir Al Faraji

17. NFA with – Examples (S) = ({s1, … , sn}) = (s1) U . . . U (sn) Dr. Shakir Al Faraji

18. NFA with – Examples We construct transition table for DFA TDab start {1,2} {2,3,4,5} TD({1,2}, a) =(TN(1,a) U TN(2,a)) = (ØU{3,4}) = ({3,4}) = (3) U  (4) ={2,3} U {2,3,4,5} ={2,3,4,5} Dr. Shakir Al Faraji

19. NFA with – Examples We construct transition table for DFA TDa b start {1,2} {2,3,4,5} Ø TD({1,2}, b) =(TN(1,b) U TN(2,b)) = (ØU Ø) = Ø Dr. Shakir Al Faraji

20. NFA with – Examples We construct transition table for DFA TDab start {1,2} {2,3,4,5} Ø TD({2,3,4,5}, a) = (TN(2,a) U TN(3,a) U TN(4,a) U TN(5,a) ) = {2,3,4,5} Dr. Shakir Al Faraji

21. NFA with – Examples We construct transition table for DFA TDa b start {1,2} {2,3,4,5} Ø {2,3,4,5} {2,3,4,5} {2,3,4,5} ØØØ Dr. Shakir Al Faraji

22. NFA with – Examples We construct transition table for DFA TDab start 1 2Ø Final 2 22 333 Dr. Shakir Al Faraji

23. a,b a -1 2+ b 3 a,b NFA with – Examples Dr. Shakir Al Faraji

24. b a a -1 4+ a   2 3 c NFA with – Examples Convert the following NFA into DFA Dr. Shakir Al Faraji

25. END Dr. Shakir Al Faraji
